Operation Manual

SAFETY PRECAUTIONS •••••••••••••••••••••• 2

Features

••••••••••••••••••••••••••••••••••••• 3

Terms Used in This Manual

••••••••••••••••••• 4

Using the unit on batteries

••••••••••••••••••• 5

Controls and Functions

•••••••••••••••••••••• 6

Selecting Patches for Play

•••••••••••••••••••• 8

Using the Tuner Function

•••••••••••••••••••• 10

Editing a Patch

••••••••••••••••••••••••••••• 12

Storing/Copying Patches

•••••••••••••••••••• 14

Changing the "Patch Call" Method

••••••••••• 16

Using the Optional Pedal

•••••••••••••••••••• 18

Restoring Factory Defaults

•••••••••••••••••• 19

Linking Effects

•••••••••••••••••••••••••••••• 20

Effect Types and Parameters

•••••••••••••••• 21

Specifications

•••••••••••••••••••••••••••••• 31

Usage Precautions

•••••••••••••••••••••••••• 31

Patch List

Troubleshooting

Contents

Introduction

Thank you for selecting the ZOOM 505 II (hereafter

simply called the "505 II").

Please take the time to read this manual carefully so as to

get the most out of the unit and to ensure optimum

performance and reliability.

Retain this manual, the warranty card and all other

documentation for future reference.

ZOOM 505 II GUITAR

Features

SAFETY PRECAUTIONS

Safety Precautions

Features

About power

• Since power consumption of this unit is

fairly high, we recommend the use of an

AC adapter whenever possible. When

powering the unit from a battery, use

only an alkaline type.

AC adapter operation

• Be sure to use only an AC adapter

which supplies 9 V DC, 300 mA and is

equipped with a "center minus" plug

(Zoom AD-0006). The use of an adapter

other than the specified type may

damage the unit and pose a safety

hazard.

• Connect the AC adapter only to an AC

outlet that supplies the rated voltage

required by the adapter.

• When disconnecting the AC adapter

from the AC outlet, always grasp the

adapter itself and do not pull at the

cable.

• If the unit is not to be used for a long

time, disconnect the AC adapter from

the outlet.

Battery operation

• Use four IEC R6 (size AA) 1.5 V batteries

(alkaline/manganese).

• The 505 II cannot be used for recharging.

Pay close attention to the labelling of the

battery to make sure you choose the

correct type.

• If the 505 II is not to be used for an

extended period of time, remove the

battery from the unit.

• If battery leakage has occurred, wipe the

battery compartment and the battery

terminals carefully to remove all remnants

of battery fluid.

• While using the unit, the battery

compartment cover should be closed.

Environment

Avoid using your 505 II in environments

where it will be exposed to:

• Extreme temperature

• High humidity or moisture

• Excessive dust or sand

• Excessive vibration or shock

Handling

• The 505 II is a precision instrument.

Except for the foot switches, do not

push other parts with your feet or

subject them to strong force.

• Take care that no foreign objects (coins

or pins etc.) or liquids can enter the unit.

• Be sure to turn the power to all

equipment off before making

connections.

• Before moving the unit, turn the power

off, and disconnect all cables and the

AC adapter.

Alterations

Never open the case of the 505 II or

attempt to modify the product in any way

since this can result in damage to the unit.

The 505 II is a sophisticated multi effect processor for guitar with

the following features and functions:

• Top level performance

While similar in price to a compact effect device, the 505 II

incorporates a varied palette of 33 effects. Up to nine effects

(including ZNR and amp simulator) can be combined in a patch.

The memory of the unit holds 36 rewritable patches, providing no-

holds-barred performance.

• Intuitive user interface

The user interface has been thoroughly redesigned. Large switches

and keys and a rotary selector make the unit extremely simple to

operate. Any desired effect can be called up swiftly and without

fuss.

• Built-in auto-chromatic tuner

The integrated tuning function lets you quickly and precisely tune

your instrument on stage.

• Dual power supply enables operation anywhere

The dual power supply principle allows the unit to be powered

either from an AC adapter or from four IEC R6 (size AA) batteries.

Continuous operation time on batteries is 8 hours with manganese

batteries and 28 hours with alkaline batteries.

• Compatible with foot switch and pedals

An optional foot switch (FS01) or expression pedal (FP01/FP02)

can be connected to the CONTROL IN jack. The foot switch is

useful for quickly switching patches, and the expression pedal can

serve to adjust the volume or effect tone in real time.

• Improved successor to 505

While inheriting the sound characteristics of the very successful

ZOOM model 505, the 505 II is even more compact and carries a

lower price tag. And what's more, it incorporates nine new effects,

including distortion effects using sophisticated modeling

techniques, practical stage-use and special effects.

Warning

This symbol indicates explanations about extremely dangerous matters.

If users ignore this symbol and handle the device the wrong way, serious

injury or death could result.

Caution

This symbol indicates explanations about dangerous matters. If users

ignore this symbol and handle the device the wrong way, bodily injury

and damage to the equipment could result.

In this manual, symbols are used to highlight warnings and cautions for you to read so that

accidents can be prevented. The meanings of these symbols are as follows:

Please observe the following safety tips and precautions to ensure hazard-free use of the 505 II.

Warning

Caution
