USAGE AND SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Controls and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Getting Ready to Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Getting connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Quick Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Playing Patches (Play Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Panel display in play mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Selecting a patch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Using the internal tuner (bypass/mute function) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Adjusting the sound of a patch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Using the Rhythm Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Turning Effects On and Off With Your Feet (Manual Mode) . . . . . . . . . . . 16

Changing the Sound of a Patch (Edit Mode) . . . . . . . . . . . . . . . . . . . . . . . 17

Patch configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Basic edit mode steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Changing a patch name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Storing and Swapping Patches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Other Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Changing effects in real time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Using the hold delay function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Using the sampler function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Calibrating the expression pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Resetting the GFX-5 to the factory default condition . . . . . . . . . . . . . . . . . . . . . . . . .27

Effect Types and Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

◆

BOOST module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

◆

ISO/COMP (Isolator/Compressor) module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

◆

DRIVE module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

◆

EQ (Equalizer) module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

◆

ZNR (ZOOM Noise Reduction) module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

◆

CABINET module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

◆

MOD (Modulation) module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

◆

REV (Delay/Reverb) module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

◆

TOTAL module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

GFX-5 Patch List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Operation Manual

Reproduction of this manual, in whole or in part, by any means, is prohibited.

ZOOM GFX-5

SAFETY PRECAUTIONS

In this manual, symbols are used to highlight warnings and

cautions for you to read so that accidents can be prevented.

The meanings of these symbols are as follows:

This symbol indicates explanations about

extremely dangerous matters. If users

ignore this symbol and handle the device

the wrong way, serious injury or death could

result.

This symbol indicates explanations about

dangerous matters. If users ignore this

symbol and handle the device the wrong

way, bodily injury and damage to the

equipment could result.

Please observe the following safety tips and precautions to

ensure hazard-free use of the GFX-5.

Power requirements

Since power consumption of this unit is fairly high,

we recommend the use of an AC adapter whenever

possible. When powering the unit from batteries, use

only alkaline types.

[AC adapter operation]

• Be sure to use only an AC adapter which supplies 9 V

DC, 300 mA and is equipped with a "center minus" plug

(Zoom AD-0006). The use of an adapter other than the

speciﬁed type may damage the unit and pose a safety

hazard.

• Connect the AC adapter only to an AC outlet that

supplies the rated voltage required by the adapter.

•When disconnecting the AC adapter from the AC outlet,

always grasp the adapter itself and do not pull at the

cable.

•When not using the unit for an extended period,

disconnect the AC adapter from the AC outlet.

[Battery operation]

• Use four conventional IEC R6 (size AA) batteries

(alkaline).

• The GFX-5 cannot be used for recharging.

Pay close attention to the labelling of the battery to make

sure you choose the correct type.

•When not using the unit for an extended period, remove

the batteries from the unit.

• If battery leakage has occurred, wipe the battery

compartment and the battery terminals carefully to

remove all remnants of battery ﬂuid.

•While using the unit, the battery compartment cover

should be closed.

Environment

Avoid using your GFX-5 in environments where it

will be exposed to:

• Extreme temperature

• High humidity or moisture

• Excessive dust or sand

• Excessive vibration or shock

Handling

Since the GFX-5 is a precision electronic device,

avoid applying excessive force to the switches and

buttons. Also take care not to drop the unit, and do not

subject it to shock or excessive pressure.

Alterations

Never open the case of the GFX-5 or attempt to

modify the product in any way since this can result in

damage to the unit.

Connecting cables and input and output

jacks

You should always turn off the power to the GFX-5

and all other equipment before connecting or

disconnecting any cables. Also make sure to

disconnect all cables and the AC adapter before

moving the GFX-5.

Usage Precautions

• Electrical interference

For safety considerations, the GFX-5 has been designed to

provide maximum protection against the emission of

electromagnetic radiation from inside the device, and

protection from external interference. However, equipment

that is very susceptible to interference or that emits

powerful electromagnetic waves should not be placed near

the GFX-5, as the possibility of interference cannot be

ruled out entirely.

With any type of digital control device, the GFX-5 included,

electromagnetic interference can cause malfunctioning and

can corrupt or destroy data. Care should be taken to

minimize the risk of damage.

• Cleaning

Use a soft, dry cloth to clean the GFX-5. If necessary,

slightly moisten the cloth. Do not use abrasive cleanser, wax,

or solvents (such as paint thinner or cleaning alcohol), since

these may dull the ﬁnish or damage the surface.

Please keep this manual in a convenient place for

future reference.

arning

Caution

USAGE AND SAFETY PRECAUTIONS

arning

Caution

ZOOM GFX-5

Introduction

Thank you for selecting the ZOOM GFX-5. This product is a sophisticated Guitar Effects Processor with the

following features.

●

Versatile array of effects

The Variable Architecture Modeling System

(VAMS) developed by ZOOM adapts the internal

conﬁguration of the unit to achieve exactly the

desired sound. The GFX-5 provides 74 choices,

ranging from distortion and modulation effects to

booster functions and a cabinet simulator that

duplicates the sound of various guitar amps.

●

Full complement of distortion effects

33 distortion type effects not only recreate the

characteristics of famous vintage amps but also

duplicate the sound and operation of renowned

compact effects and pedals. The [TURBO] key lets

you boost the sound pressure in an instant, and the

[EDGE] key creates a bright treble edge. A wide

variety of drive sounds are only a keypress away.

●

120 ready-to-use patches

Effect module setting combinations can be stored as

patches. The GFX-5 offers 60 user patches which

can be freely modiﬁed, plus 60 preset patches.

Together, these 120 settings let you make great

music straight away.

●

Intuitive operation and key layout

The knobs and keys on the panel of the unit are

designed for maximum usability. Choose distortion

types or adjust equalizer settings in a ﬂash. The

expression pedal is great for controlling effect

parameters in real time. The GFX-5 practically

comes alive during a performance.

●

Newly developed ARRM feature

ARRM (Auto-Repeat Real-time Modulation) is a

fascinating concept. Using built-in control

waveforms, it lets you rhythmically shape the signal

in many ways. Create totally novel sounds that will

captivate listeners. You can even use the expression

pedal to adjust the modulation depth of the ARRM

feature.

●

Integrated drum machine

60 built-in rhythm patterns using natural-sounding

PCM sources are available, which is great for

practice or a quick jam session. ARRM cycles can

be synchronized to the rhythm tempo, letting you

alter effects in sync with the ﬂow of the music. The

creative possibilities are limitless.

●

6-second sampling feature

A guitar phrase or the signal from an input source

such as a CD player can be sampled for up to 6

seconds and stored in the internal memory. The

recorded sample can be played back at a slower

speed without altering the pitch. This is a great tool

for enhancing a live performance or for copying a

lick or fast-playing phrase.

●

Energize creates dynamic sound

The Energize is another innovation with immense

appeal. Simply by turning a knob, you can optimize

the sound characteristics to match the playback

system. Enjoy powerful, dynamic sound even with a

small guitar amp or an audio system with ﬂat

response.

●

Designed for use on stage

The GFX-5 can be powered either from an AC

adapter or from batteries. With one set of alkaline

batteries, the unit will operate continuously for up

to 10 hours. A special mode lets you switch major

effects on or off with your foot or specify the

rhythm tempo during a performance. Operate the

unit like compact effects, while accessing a vast

array of functions.
