Thank you for selecting the ZOOM RFX-1000 (hereafter simply called the "RFX-
1000 "). The RFX-1000 is a sophisticated digital reverb and multi-effect processor with
the following features and functions.
Please take the time to read this manual carefully so as to get the most out of your RFX-
1000 and to ensure optimum performance and reliability. Retain this manual, the
warranty card and all other documentation for future reference.
• 33 immediately usable effects
The RFX-1000 comes with a full complement of preset effects (11 effects x 3 banks).
Right out of the box, the unit is ready to create great sound. The REVERB bank in
particular provides a wide spread and natural sounding ambience that meets even
demanding professional standards.
• Built-in professional quality reverb
The reverb effects alone allow 121 different settings. The convincing sound stage
created by the RFX-1000 far surpasses anything else available in this class.
• Innovative choices
Lo-Fi EFX purposely degrades sound quality for special effect. RESONANCE
processes the input signal with sophisticated filtering. MIC SIMULATOR produces
condenser mic sound from a dynamic microphone. These and various other effects
are great for recording and give full scope to your creativity.
• Attractive mixdown effects
Mixdown effects can be used effectively to tailor the overall mood of a song when
performing mixdown (mixing multiple tracks onto two final stereo tracks) or
mastering (fine-tuning the sound and level of a final 2-track mix).
• Intuitive editing controls
Convenient knobs on the front panel let you directly adjust items such as the mixing
ratio of original sound and effect sound. Editing effect parameters on the fly is also
easy and straightforward. This allows quick fine-tuning for optimum sound.
• MIC IN jack
The dedicated microphone jack on the front panel comes in handy for creating vocal
effects without having to make cumbersome connections in the rear. Controlling the
VOCODER effect is a snap thanks to this feature.
OPERATION MANUAL
Introduction
Contents
Controls and Functions
••••••••••••••••••••••••••••••••••••••••••••••••••••••• 2
Front Panel
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 2
Rear Panel
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 2
Rack Mounting
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 4
Getting Connected
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 4
Trying Out the Effects
••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 6
Changing the Sound of an Effect
•••••••••••••••••••••••••••••••••••••••••••• 7
RFX-1000 Effects
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 8
Troubleshooting
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 15
Specifications
••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 5
Safety Precautions/Usage Precautions
2
(1) POWER switch
Serves to turn the unit on and off.
(2) POWER indicator
When the RFX-1000 is on, this LED indicator is lit in
green. When the foot switch FS01 (option) was used
to switch the effects off, the indicator flashes red.
(3) MIC IN jack
A dynamic microphone with an output impedance of
about 600 ohms can be connected here. Normally the
input signal from this jack is mixed with the signal
from the rear-panel INPUT jacks. When the
VOCODER effect is selected, the mic input signal
serves for controlling the effect. You can use your
voice to alter the sound character and the envelope
(volume change curve).
Note: When plugging or unplugging a
microphone here, noise may occur. Be sure
to turn down the INPUT control (5) first.
(4) Level meter
These indicators show the signal input level.
(5) INPUT control
Serves to adjust the signal from the INPUT jacks and
the MIC IN jack.
(6) OUTPUT control
Serves to adjust the level of the signal supplied at the
OUTPUT jacks.
(7) MIX control
Serves to adjust the balance between original sound
(DRY) and effect sound (WET). When the control is
turned fully counterclockwise, only the original sound
is output. When the control is turned fully clockwise,
only the effect sound is output.
ZOOM RFX-1000
Controls and Functions
Front Panel
Rear Panel
(1) POWER switch
(2) POWER indicator
(3) MIC IN jack
(4) Level meter
(5) INPUT control
(6) OUTPUT control
(7) MIX control
(1) BYPASS jack
(1) BYPASS jack
Serves for connection of the foot switch FS01 (option)
for switching effects on and off.
(2) OUTPUT jacks
Connect these jacks to the recorder or playback
system.
(3) INPUT jacks
Connect a line-level source, such as an instrument or
the send output of a mixer, to these jacks. If a plug is
inserted only in the L/MONO jack, the signal from
this plug will be supplied to both channels. A high-
impedance source such as an electric guitar should be
routed through a preamplifier or a guitar effect first.
Controls and Functions
