Thank you for selecting the ZOOM RFX-300 (hereafter simply called the "RFX-300").

The RFX-300 is a sophisticated multi-effect processor with the following features and

functions.

Please take the time to read this manual carefully so as to get the most out of your RFX-

300 and to ensure optimum performance and reliability. Retain this manual, the warranty

card and all other documentation for future reference.

Safety Precautions/Usage Precautions

•••••••••••••••••••••••••• 2

Controls and Features

••••••••••••••••••••••••••••••••••••••••••••• 3

Top Panel

••••••••••••••••••••••••••••••••••••••••••••••••••••••• 3

Rear Panel

••••••••••••••••••••••••••••••••••••••••••••••••••••• 3

Getting Connected

•••••••••••••••••••••••••••••••••••••••••••••••• 4

To Operate the Unit on Batteries

••••••••••••••••••••••••••••••••• 5

Turning the Unit On

•••••••••••••••••••••••••••••••••••••••••••••••• 5

Adjusting the Sound of an Effect

••••••••••••••••••••••••••••••••• 6

Using the Bypass Function

••••••••••••••••••••••••••••••••••••••• 6

Effects and Parameters

••••••••••••••••••••••••••••••••••••••••••• 7

Troubleshooting

Specifications

• Ideal for use with a multi-track recorder

A total of 22 high-quality preset effects using a sampling frequency of 44.1 kHz and

18-bit A/D and D/A converters are built in. This includes reverb effects such as Hall,

Room, Plate, and Ambience, delay/modulation type effects as well as combination

effects, mixdown effects for changing the overall mood of a song. Any effect can be

called up quickly and without fuss. The unit is designed to be especially useful for

recording and mixdown on a multi- track recorder.

• Easy operation

The main parameters of preset effects can be adjusted directly with convenient knobs

on the top panel. This allows quick fine-tuning for optimum sound.

• Integrated tap input function

Tap input lets you set time-based parameters simply by tapping a key in the desired

interval. This makes it a snap to match delay time or modulation rate to the tempo of

a song.

• Versatile input/output configuration

The inputs and outputs of the RFX-300 accommodate both standard phone plugs and

RCA type phono plugs. Electronic instruments, multi-track recorders, various audio

components and a wide range of other equipment can be connected without hassle.

The phone jack input is equipped with a gain switch, allowing connection of

microphones as well. You can use the RFX-300 as a portable vocal effect device or as

a microphone preamp for recording.

• Dual power supply design

The dual power supply principle allows the unit to be powered from an AC adapter or

six IEC R6 (size AA) batteries. This is convenient for example when using the unit

on stage.

OPERATION MANUAL

Introduction

Contents

Safety Precautions

In this manual, symbols are used to highlight warnings and

cautions for you to read so that accidents can be prevented.

The meanings of these symbols are as follows:

Please observe the following safety tips and precautions to

ensure hazard-free use of the RFX-300.

• Power requirements

Since power consumption of this unit is fairly high, we

recommend the use of an AC adapter whenever

possible. When powering the unit from a battery, use

only an alkaline type.

[AC adapter operation]

• Be sure to use only an AC adapter which supplies 9

V DC, 300 mA and is equipped with a "center

minus" plug (Zoom AD-0006). The use of an

adapter other than the specified type may damage

the unit and pose a safety hazard.

• Connect the AC adapter only to an AC outlet that

supplies the rated voltage required by the adapter.

• When disconnecting the AC adapter from the AC

outlet, always grasp the adapter itself and do not pull

at the cable.

• When not using the unit for an extended period,

disconnect the AC adapter from the AC outlet.

[Battery Powered Operation ]

• Use six IEC R6 (size AA) 1.5V batteries (alkaline).

• The RFX-300 cannot be used for recharging.

Pay close attention to the labelling of the battery to

make sure you choose the correct type.

• When not using the unit for an extended period,

remove the batteries from the unit.

• If battery leakage has occurred, wipe the battery

compartment and the battery terminals carefully to

remove all remnants of battery fluid.

• While using the unit, the battery compartment cover

should be closed.

• Environment

Avoid using your RFX-300 in environments where it

will be exposed to:

• Extreme temperature

• High humidity or moisture

• Excessive dust or sand

• Excessive vibration or shock

• Handling

Since the RFX-300 is a precision electronic device,

avoid applying excessive force to the switches and

buttons. Also take care not to drop the unit, and do not

subject it to shock or excessive pressure.

• Alterations

Never open the case of the RFX-300 or attempt to

modify the product in any way since this can result in

damage to the unit.

• Connecting cables and input and output jacks

You should always turn off the power to the RFX-300

and all other equipment before connecting or

disconnecting any cables. Also make sure to disconnect

all cables and the AC adapter before moving the RFX-

300.

Usage Precautions

• Electrical interference

For safety considerations, the RFX-300 has been designed

to provide maximum protection against the emission of

electromagnetic radiation from inside the device, and

protection from external interference. However, equipment

that is very susceptible to interference or that emits

powerful electromagnetic waves should not be placed near

the RFX-300, as the possibility of interference cannot be

ruled out entirely.

With any type of digital control device, the RFX-300

included, electromagnetic interference can cause

malfunctioning and can corrupt or destroy data. Care

should be taken to minimize the risk of damage.

• Cleaning

Use a soft, dry cloth to clean the RFX-300. If necessary,

slightly moisten the cloth. Do not use abrasive cleanser,

wax, or solvents (such as paint thinner or cleaning

alcohol), since these may dull the finish or damage the

surface.

Please keep this manual in a convenient place for

future reference.

ZOOM RFX-300

Safety Precautions/Usage Precautions

Warning

Caution

Warning

Caution

This symbol indicates explanations

about extremely dangerous matters. If

users ignore this symbol and handle the

device the wrong way, serious injury or

death could result.

This symbol indicates explanations

about dangerous matters. If users ignore

this symbol and handle the device the

wrong way, bodily injury and damage to

the equipment could result.

Caution
