Quad Clock Distributor (QCD)

from 4ms Company

Eurorack Module User Manual v2.0 (2015-02-20)

The Quad Clock Distributor (QCD) from 4ms Company is a four channel Voltage Controlled Clock Divider/Multiplier

with master Tap Tempo. Each channel can be synced to the tap tempo, to the channel above, or to an external

clock. Each channel also has a reset jack.

With a Tap Tempo button and five sync'ed clock outputs, the QCD is a versatile head-of-the-chain "Master" clock

module, and/or a complex rhythmic pattern generator.

The QCD has headers for connecting to the QPLFO, VCA Matrix, and other modules.

• Four CV Clock Divider/Multipliers (/32 to x16)

• Tap Tempo button with dedicated tap clock output

• Channels sync to tap tempo, or can be driven by external clock(s)

• Reset jack on each channel

• Gate or trigger outputs, or variable PW and Trigger Delay using the QCD Expander

• Create complex trigger patterns for drum modules or rhythmic patches

• Connects to QPLFO and other modules with the included 8-pin cable

• QCD Expander adds attenuator/inverters for CV inputs

DOWNLOAD MOST RECENT MANUAL AT:

http://4mspedals.com/qcd.php

Basic features:

• Four CV-controlled Clock Divider/Multipliers

◦ CV control allows for clock speed to be sequenced, manually changed, and/or self-patched for complex and

controllable patterns

◦ Divides and Multiplies clocks from /32 to x16 on each channel

▪ Detented knobs snap to integer division/multiples

▪ CV jacks modulate Div/Mult amount

▪ Channels can be stacked for more range (/1048576 to x65536)

• Tap clock output jack runs at the tapped tempo even if other channels are being clocked externally

• Independent CLOCK IN, OUT, Reset and Div/Mult CV on each channel

• Reset jack restarts the clock when a trigger is received (alters phase of clock)

• Clock input jacks are normalized downwards: Tap->Red->Black->Blue->Green

◦ Plugging into a CLK IN jack will clock the channel(s) below with the same clock

• Auto-stop: each channel stops automatically when the incoming clock stops

• LED brightness can be adjusted from the front panel

• Jumper selectable gate or trigger outputs (QCD Expander adds CV control)

• High-quality potentiometers with metal shafts and nuts

Connectivity:

• Daisy chain multiple QCDs or other clock modules using Tap Out jack

• Interfaces with QCD Expander for more features (Pulse Width, Inverted Gate, attenuverters for CV inputs)

• 8-pin header on the PCB connects to the Quad Pingable LFO (QPLFO) to provide four LFOs with CV control of Skew,

and CV control of the clock divide/multiply amount.

• The 8-pin header can also interface with other modules (VCA Matrix, Mixiplexer, Intermix)

• Can create a standard clock from a DINSYNC 24ppq clock and vice-versa, using two channels (/12 and /2, or p2-x6 and

x4, for example).

Controls and jacks:

• Tap tempo button tap twice to set a tempo. If no external clocks are plugged in, it clocks all the channels

• TAP OUT jack: Clock output for the tapped tempo.

• Each of the 4 channels has:

• CLK IN jack: Clock input. Any signal can be used. A trim pot on the back sets the triggering threshold (default

is 2.5V). If nothing is plugged in, the clock is taken from the CLK IN jack on the channel above. The top

channel's CLK IN jack is normalized to the Tap clock.

• OUT jack: Clock output. Period (tempo) is a division or multiple of the time between the last two pulses on the

CLK IN jack

• Reset jack: Trigger input locks the clock phase to a new spot in the "measure". Any signal can be used. The

same triggering threshold for the CLK IN jack is used.

• Div/Mult: Knob selects amount of clock division or multiplication from /32 to x16, detenting/clicking at integer

amounts.

Note: /32 and x16 have two "clicks" each. Turning the knob all the way down is /32, and turning it up one click

is also /32. The next click is /16. Similarly, the top two clicks are x16. The artwork on the faceplate shows this.

• Div/Mult jack: 0V to 10V sweeps full range. Knob provides offset to the signal on the jack.

• LED: blinks to the tempo. Brightness is adjustable.

• LED Brightness: the small hole next to the TAP OUT jack is for adjusting the LED Brightness. A tiny phillips

screwdriver can be inserted through the panel to adjust the brightness. See manual section for instructions.

Dimensions

• 10 HP Eurorack format module

• 1.06” (27mm) deep

Power consumption

+12V rail:

53mA max with 5V Source jumper selecting external 5V

65mA max with 5V Source jumper selecting internal 5V

+5V rail:

13mA max with 5V Source jumper selecting external 5V

not used with 5V Source jumper selecting internal 5V

-12V rail:

40mA max
