Side 1/8

MN905

No. 281 Replaces 281G

LB7010

Instruction Manual For Baldor Tool Grinders

1MN905

SAFETY NOTICE:

WARNING statements describe conditions that may lead to personnel injury including potentially fatal injuries if the

machine is not properly used and warnings are not properly followed.

Caution statements describe conditions that may lead to equipment damage.

Electrical shock can cause serious or fatal injury. Only qualied personnel should install, maintain or troubleshoot

this equipment.

WARNING: Do not operate this grinder until you are sure that you are completely familiar with the safe operation of the

grinder, all accessories and safety equipment. Improper use can lead to severe injury. This manual deﬁnes

proper use of this equipment. Before using this equipment for any other use, please consult Baldor. Contact

Baldor if you do not understand any procedure or operation concerning this grinder or this manual.

WARNING: Prevent electrical shock hazard and accidental machine operation. Always disconnect grinder from the

power source before servicing, changing accessories (such as wheels, tool rest, spark arrestor, etc.) or

before performing maintenance.

WARNING: Avoid accidental starting. Make sure switch is in “OFF” position before connecting to power source.

WARNING: Be sure the system is properly grounded before applying power. Do not apply power before you ensure that

grounds are connected. Electrical shock can cause serious or fatal injury. Follow the National Electrical Code

(NEC) and local codes for the safe installation of this equipment.

WARNING: Always use safety glasses with side shields (or full face shield) when operating grinder. Do not use ordinary

eyeglasses. Also use face or dust mask if cutting operation is dusty.

WARNING: Unsuitable accessories or attachments added to this machine can create hazards. Baldor accessories

are speciﬁcally designed to be used with this grinder. Use accessories or attachments only in the proper

intended manner. Accessories or attachments obtained from another source may cause hazards. Consult the

manufacturer before use.

WARNING: Keep guards in place and in working order. Guards are design to prevent injury. Never operate this equipment

if a guard is damaged, missing or improperly installed.

WARNING: Remove adjusting keys and wrenches from this product after use. Check to see that keys and adjusting

wrenches are removed from grinder before turning it on. Projectiles can cause severe injury to yourself or

others.

WARNING: Keep work area clean and well lighted. Clutter and poor lighting invites accidents.

WARNING: Don’t use in dangerous environment. Don’t use grinders in damp or wet locations, or expose them to rain.

Electrical shock can cause serious or fatal injury. Follow the National Electrical Code (NEC) and local codes

for the safe installation of this equipment.

WARNING: Do not wear loose clothing, neckties, rings, bracelets, or other jewelry to get caught in moving parts. Nonslip

footwear is recommended. Wear protective hair covering to contain long hair.

WARNING: Don’t over reach. Keep proper footing and balance at all times. A rotating wheel can catch an article of

clothing and cause personnel injury.

WARNING: Secure work. Use clamps to secure the work piece when practical. It’s safer than using your hand and it

keeps hands away from wheel.

WARNING: When starting a grinder for the ﬁrst time, or after installing a replacement grinding wheel, it is most important

that the operator stand aside for at least one minute of rotation at full speed. This is the correct practice

since grinding wheels can disintegrate if they have received damage during shipping or handling.

WARNING: Check damaged parts. Before further use of the grinder, a guard or other part that is damaged should

be carefully checked to assure that it will operate properly and perform its intended function. Check for

alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other conditions

that may affect its operation. A guard or other part that is damaged should be properly repaired or replaced.

WARNING: Never install a wheel that is damaged, such as a chip or crack on any surface. A damaged wheel can

disintegrate while rotating at a high RPM or when work is placed against the wheel. This can severely harm

the operator or others in the area.

WARNING: Use proper extension cord. Make sure your extension cord is in good condition. When using an extension

cord, be sure it is rated for the voltage and current rating of your product. An undersized cord will cause a

drop in line voltage resulting in loss of power and overheating.

Table 1 shows the correct wire size to use depending on cord length and nameplate ampere rating. If in

doubt, use the next heavier gauge. The smaller the AWG gauge number, the heavier the cord.

WARNING: Dust created during grinding, sawing, power sanding, drilling, and other activities may contain chemicals

known to the State of California to cause cancer, birth defects or other reproductive harm.

WARNING: Keep children and visitors away. Remove starter keys turn off master switches. Padlock equipment or work

area when not in use.

WARNING: Never leave grinder running unattended. Always turn power off after use.

Caution: Don’t force grinder. It will do the job better and safer at the feed rate for which it was designed.

Caution: Use right tool. Don’t force tool or attachment to do a job for which it was not designed.

Caution: Maintain grinder with care. Keep grinder clean for best and safest performance.

Continued on Next Page.

Produkt Specifikationer

Mærke:	ABB
Kategori:	Kværn
Model:	7B510
Type:	Tør/våd mølle
Vekselstrømsindgangsspænding:	208-230/460 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	469.9 mm
Dybde:	698.5 mm
Højde:	431.8 mm
Vægt:	49486 g
Produktfarve:	Blå
Pakkevægt:	49486 g
Tomgang (min.):	3000 rpm
Tomgang (maks.):	3600 rpm
Strømstyrke:	2 A
Antal slibeskiver:	2
Slibeskive diameter:	152 mm
Slibehjul tykkelse:	25.4 mm
Slibeskive boring:	31.75 mm
