INR-450

INR-450INR-450

Model

INR-450

Product Type

Standalone NVR

Maximum Number of Video devices

200

Additional Computing Power

Yes

Processor

Intel Xeon E5-2600 v3

Original Manufacturer

Dell

Maximum Number of Clients

1 local, 4 remote

License required

Yes

Free License

64 (64-channel for ACTi and 1-channel for

third-party video device)

Video Resolution

Support all ACTi cameras in all resolutions

Compression

H.264, MPEG-4, MJPEG

Audio

Network Connector

RJ-45

Power Source

AC 100-240V

Redundant Power Supply

Yes

Rack Space

Built-in Analytics

Motion Detection, Tamper

Bundled Accessories

Rack kit

Mount Type

Rack Mount

Scheduled Recording

Yes

Event Recording

Yes

Manual Recording

Yes

Speed Up

Yes

Dual Stream Management

Yes

External Storage Interface

iSCSI, USB

RAID Level

Hardware RAID 0, 1, 5, 10

Display Layout Mode

Local: 1, 4, 6, 8, 9, 10, 12, 16

Remote: 1, 4, 9, 16, 25, 36, 49, 64

Local Live View performance

Please check "Standalone NVR

Performance Validator"

(http://www.acti.com/SANVRPerformance)

Recording Throughput

300 Mbps

Digital Zoom

Yes

Event Status

Display event status upon alarm or upon

connection loss or recovery between server

and client or when the allocated disk space

is full

HDD Interface

Maximum 12 3.5" SATA disks (Without

Storage Disks)

Instant Playback

Instant Playback in live view window

e-Map

Yes

PTZ Control

Yes

Playback Control

Continuous forward and backward playback

with speeds 1x/2x/4x/8x/16x or frame-by-

frame; pause; stop

Synchronized Playback

9 channels (local), 64 channels (remote)

Local Access

VGA/Mini display port for monitor; USB

joystick, keyboard & mouse

Remote Access

Workstation, Web Client (IE), Mobile Client

(iOS & Android)

Event Trigger

NVR: Disk full; Disk not found; Disk is

available;

Device: Video motion detection; Passive IR

sensor; External device through digital input;

Video loss and recovery; Network loss and

recovery

Event Response

Pop-up window with live video; Switch to

hotspot window; Switch to customize View;

Command a PTZ device to go to a preset

point; Play alert sound; Activate external

device through digital output; Execute

system command to activate other programs;

Upload snapshot to FTP server; E-mail

notification with snapshots

Permission Control

Unlimited number of users and user groups,

Active Directory, Customizable permissions

for user groups, Playback Password

protected, Password Validity Period

GPS Position

Manual setting

Video Export

eSATA, iSCSI, USB

Video Export Formats

RAW, AVI, EXE

Server Operating System

Embedded Windows 7

Client PC Operating System

Windows 10, Windows 8, Windows 7,

Windows Server 2012, Windows Server

2008

PC Web Browser

IE 10, IE 11

Unified Solution

Fully compatible with ACTi cameras,

encoders, central management system, TV

wall and intelligent video surveillance

software

ONVIF Compliant

Yes (Profile S)

Fan

Yes

Packing Dimension

68.4 x 44.4 x 8.73 (cm)

Operating Temperature

5°C ~ 40°C

(41°F ~ 104°F)

Warranty

3 Years

Approvals

CE, FCC, UL (for built-in power adapter)

Product Availability

ACTi : 2016.08.05

Distributor : 2016.08.12

MSRP (USA, reference only)

USD$21,190 *Preliminary Price

Produkt Specifikationer

Mærke:	ACTi
Kategori:	VCR
Model:	INR-450
Vekselstrømsindgangsspænding:	100-240 V
Bredde:	482.4 mm
Dybde:	723 mm
Højde:	87.3 mm
Vægt:	17500 g
Produktfarve:	Black, Grey
Wi-Fi:	Ingen
Relativ luftfugtighed ved drift (H-H):	10 - 85 %
Ethernet LAN-porte (RJ-45):	4
Antal USB 2.0-porte:	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Strømforbrug (typisk):	750 W
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	- pixel
Ethernet LAN-datahastigheder:	1000 Mbit/s
Intern hukommelse:	16000 MB
Operativsystem installeret:	Windows Embedded Standard 8
Certificering:	CE, FCC, UL
Understøttede netværksprotokoller:	IPv4/v6, TCP, UDP, DHCP Client, HTTP, DNS, NTP, RTP, RTSP, SMTP, FTP, ICMP, ARP, UPnP, iSCSi, LDAP
HDD kapacitet:	0 GB
Intern hukommelsestype:	DDR4
Understøttede Windows-operativsystemer:	Ja
Afspilningstilstande:	Digital zoom
Video codec:	H.265, H.264, MPEG-4, MJPEG
Indbygget processer:	Ja
HDD-grænseflade:	SATA, SATA II, SATA III, Serial Attached SCSI (SAS)
Stativ-montering:	Ja
PTZ-kontrol:	Ja
HDD-størrelse:	3.5 "
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	168 TB
Antal understøttede HHD'er:	12
Rackkapacitet:	2U
RAID-niveauer:	0, 1,5, 6,10, 50, 60
Video indgangskanaler:	12 kanaler
Indgang båndbredde:	300 Mbit/s
VGA (D-Sub) udgangsporte:	2
