Side 1/55

AdderLink Innity and Innity dual

User Guide

Experts in

Connectivity

Solutions

KVM Extension

Solutions

(1002, 2000, 2002 & 2020)

INSTALLATION

CONFIGURATIONOPERATION

FURTHER

INFORMATION

INDEX

Introduction

Welcome ................................................................................................................ 2

ALIF features .........................................................................................................3

Firmware version 3.3 (or greater) ...................................................................4

AdderLink Innity (1002) unit features ........................................................... 5

AdderLink Innity dual unit features ...............................................................6

Supplied items - ALIF 1002 ................................................................................7

Supplied items - ALIF dual ..................................................................................8

Optional extras .....................................................................................................9

Installation

Connections ........................................................................................................10

Mounting ..............................................................................................................10

TX video link .................................................................................................11

TX audio links ...............................................................................................12

TX USB link ...................................................................................................12

TX AUX (serial) port ..................................................................................13

TX power in ..................................................................................................13

TX/RX high speed links ..............................................................................14

TX/RX Management port ..........................................................................15

RX video display ...........................................................................................16

RX microphone & speakers .......................................................................17

RX USB devices ............................................................................................17

RX AUX (serial) port ..................................................................................18

RX power in ..................................................................................................18

Conguration

Initial conguration ............................................................................................19

Manual factory reset ....................................................................................19

AdderLink Innity browser-based conguration utility .......................20

Performing an upgrade ......................................................................................21

Options switches ................................................................................................21

Operation

Front panel indicators .......................................................................................22

Further information

Getting assistance ..............................................................................................23

Appendix A - Transmitter (TX) unit conguration pages ..........................24

Appendix B - Receiver (RX) unit conguration pages ...............................31

Appendix C - Tips for success when networking ALIF units ....................39

Appendix D - Troubleshooting ........................................................................41

Appendix E - Glossary ......................................................................................43

Appendix F - Cable pinouts, video modes and general specications ...46

Appendix G - Fiber modules and cables .......................................................47

Appendix H - Mounting options .....................................................................48

Warranty ..............................................................................................................51

Safety information ..............................................................................................51

Radio frequency energy ....................................................................................52

Index

Contents

Produkt Specifikationer

Mærke:	Adder
Kategori:	bryter
Model:	ALIF2002T
Type:	Sender
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Vægt:	1100 g
Produktfarve:	Sort
Driftstemperatur (T-T):	0 - 40 °C
Dimensioner (BxDxH):	198 x 150 x 44 mm
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC
Pc lydindgang:	Ja
Plug and play:	Ja
Indgangsstrøm:	0.8 A
Stativ-montering:	Ja
Maksimal digital opløsning:	2560 x 1600 pixel
RS-232-porte:	1
PC-lydudgang:	Ja
Antal RJ-45-porte:	2
USB porttype:	USB Type-B
Antal installerede SFP+ moduler:	1
Sender til lokal tastatur/mus porttype:	USB
Sender til video porttype:	DVI-D
