User Instructions

FS600LED Introduction

ADJ Products, LLC - www.adj.com - FS600LED User Manual Page 2

Rev. 4/15

Unpacking: Thank you for purchasing the FS600LED by ADJ Prod-

ucts, LLC. Every FS600LED has been thoroughly tested and has been

shipped in perfect operating condition. Carefully check the shipping

carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all accessories necessary to operate the unit has

arrived intact. In the case damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Do not return this unit to your dealer without rst contact-

ing customer support.

Introduction: The ADJ FS600LED is part of a continuing pursuit to

create high quality intelligent lighting. The FS600LED is a modern 60W

LED follow spot. It features a bright 60W LED, 8 colors, variable strobe

speed and dimming capabilities. This fixture is suitable for theaters,

studios, retail stores, and other similar locations.

Customer Support: ADJ Products, LLC provides a customer sup-

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.adj.com for any comments or sugges-

tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.

Pacic Standard Time.

Voice: (323) 582-3322

Fax: (323) 582-3108

E-mail: support@adj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ Products, LLC.

PLEASE recycle the shipping carton when ever possible.

FS600LED

FS600LED Safety Precautions

ADJ Products, LLC - www.adj.com - FS600LED User Manual Page 4ADJ Products, LLC - www.adj.com - FS600LED User Manual Page 3

• 8 Colors

• Strobing

• Adjustable Iris

• Shutters for Manual Framing

• Dimming 0-100%

• DMX-512 protocol

• 3-Pin & 5-Pin DMX Connection

• 3 DMX Channels

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break o the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 10 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

FS600LED Warranty Registration

FS600LED Features

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. Please keep this manual

with the unit, for future reference.

FS600LED General Instructions

The FS600LED 2 carries a year limited warranty. Please fill out the

enclosed warranty card to validate your purchase. All returned service

items whether under warranty or not, must be freight pre-paid and

accompany a return authorization (R.A.) number. The R.A. number

must be clearly written on the outside of the return package. A brief

description of the problem as well as the R.A. number must also be

written down on a piece of paper included in the shipping carton. If

the unit is under warranty, you must provide a copy of your proof of

purchase invoice. You may obtain a R.A. number by contacting our

customer support team on our customer support number. All pack-

ages returned to the service department not displaying a R.A. number

on the outside of the package will be returned to the shipper.

Produkt Specifikationer

Mærke:	Adj
Kategori:	Ikke kategoriseret
Model:	FS600LED
Bredde:	484 mm
Dybde:	290 mm
Højde:	370 mm
Vægt:	7800 g
Produktfarve:	Sort
Kontroltype:	Knapper
Lampe type:	LED
Produkttype:	Disco spotlight
Strømforbrug (typisk):	80 W
Antal:	1
Strømkilde:	Vekselstrøm
Pæreeffekt:	60 W
Lysfarve:	Blue, Green, Red, White, Yellow
Farvetemperatur:	3200 K
Indgangsspænding:	100 - 240 V
Strålevinkel:	26 °
Indgangsfrekvens:	50 - 60 Hz
Velegnet til indendørsbrug:	Ja
Belysningstilstande:	DMX
Belysningskontrol protokoller:	DMX
Bold diameter:	- "
Dæmpningsområde:	0 - 100 %
