Side 1/4

Unpacking: Thank you for purchasing the Haze Generator by Ameri-

can DJ . Every unit has been thoroughly tested and has been shipped ®

in perfect operating condition. Carefully check the shipping carton for

damage that may have occurred during shipping. If the carton appears

to be damaged, carefully inspect your xture for any damage and be

sure all equipment necessary to operate the unit has arrived intact. In

the event damage has been found or parts are missing, please contact

our toll free customer support number for further instructions. Do not

return this unit to your dealer without rst contacting customer sup-

port.

Introduction: This unit is a heater-less special effect fog producing

unit. This unit is designed to produce a light haze to enhance the beam

intensity of lighting effects and produce a light smoky atmosphere for

theatrical groups. A haze machine will not produce hot and heavy

vapor as fog machine, because of this a haze machine is preferred to

many theatrical groups for stage productions. Please read the follow-

ing instructions and safety precautions before attempting any installa-

tion or using your new HAZE generator.™

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.americandj.com for any com-

ments or suggestions. For service related issue please contact Ameri-

can DJ . Service Hours are Monday through Friday 9:00 a.m. to 5:00 ®

p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

your nearest American DJ dealer.

Please do not discard the shipping cartoon in the trash. Please recycle

when ever possible.

HAZE Generator™ Introduction

American DJ

User Instructions

American DJ

4295 Charter Street

Los Angeles Ca. 90058

www.americandj.com

HAZE generator

™

No warm-up necessary!

Uses Haze-Generator™ liquid only!

Available in gallon bottles

Revised 5/07

Caution: Fog Machines may set off Smoke Alarms!

• Be sure to save the packing carton in the unlikely event the unit

may have to be returned for service

• Do not spill water or other liquids into or on to your fogger. Be

sure that all the fog uid is kept inside the uid reservoir

• Be sure that the local power outlet match that or the required

voltage for your fog machine

• Do not remove the top cover under any conditions. There are no

user serviceable parts inside

• Disconnect the unit’s main power when left unused for long peri-

ods of time

• Never connect this unit to a dimmer pack

• Do not attempt to operate this unit, if it becomes damaged in anyway

• Never operate this unit when it’s cover is removed

• To reduce the risk of electrical shock or re, do not expose this

unit rain or moisture

• Do not attempt to operate this unit if the power cord has been fray-

ed or broken. Do not attempt to remove or break off the ground

prong from the electrical cord. This prong is used to reduce the

risk of electrical shock and re in case of an internal short

• Disconnect from main power before making any type of connection

• Never block the ventilation holes. Always be sure to mount this

unit in an area that will allow proper ventilation. Allow about 6”

(15cm) between this device and a wall

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties

• Always mount this unit in a safe and stable matter

• Please route your power cord out of the way of foot trafc. Power

cords should be routed so they are not likely to be walked on,

pinched by items placed upon or against them

• The unit should only be serviced by qualified service personnel

when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The appliance does not appear to operate normally or

exhibits a marked change in performance.

Haze Generator™ Safety Precautions

HAZE Generator™ Operating Instructions

Always be sure to maintain an adequate supply of American DJ Brand ®

Haze Juice™ in the fluid reservoir. Running the haze machine dry will

cause pump failure and or clogging. This is the largest cause of failure in

fog and haze machines.

Stand Alone Operation: This unit may be operated with or without the

remote control attached to the unit. If the remote is not connect the unit

will immediately begin to function and emit haze as soon as the unit is

turned on.

Remote Operation: The remote allows the unit to run automatically or

by timer. The remote has a “on/off” button, that must be turned on to

operate the unit. A red LED above the on/off button will glow when the

remote is activated.

Manual: The remote has a green button, this button allows operation to

be controlled manually. Haze will emit as long as this button is activated,

a green LED above this button will glow when the manual function is

activated.

Timer: The timer function allows haze to be emitted at designated inter-

vals. To activate the timer function press the yellow timer button. A yel-

low LED will glow when the timer function is activated. The “duration”

button will control the length of haze burst. The “interval” button will

control the time between burst. Turing these knobs in a clockwise direc-

Haze Generator™ Set-Up

1. Open the shipping carton and carefully remove the unit from the

shipping carton.

2. Be sure to remove all the packing material especially around the

nozzle.

3. Set the machine on a flat dry surface and remove the reservoir

cap located on the top of the machine.

4. Fill the haze generator reservoir with American DJ branded haze

fluid only and replace the cap.

5. Remove the remote control from the carton. Firmly attach the

remote control to the remote control socket located on the rear

unit.

6. Plug the unit in to a matching power supply and flip the power

switch to the on position.

7. Follow the operating instructions on the next page for proper

operation.

Produkt Specifikationer

Mærke:	Adj
Kategori:	Effektmaskine
Model:	HAZE generator
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	120 - 220 V
Bredde:	482.6 mm
Dybde:	247.65 mm
Højde:	234.95 mm
Vægt:	12200 g
Produktfarve:	Sort
Indbygget skærm:	Ingen
Strøm:	- W
Certificering:	CE
Fjernbetjent:	Ja
Bæredygtighedscertifikater:	CE
Fjernbetjeningstype:	Ledningsført
Væsketank, kapacitet:	1.25 L
Volumen af udgående røg:	- m³/min
Betjeningsvæske:	Olie
Røgmaskine, type:	Røgmaskine
Røgvejledning:	Vandret retning
