Side 1/4

Jelly Cosmos Ball Introduction

Introduction: Thank you for purchasing the Jelly Cosmos Ball by

ADJ Products, LLC. The Jelly Cosmos Ball is ready to be plugged

in right out of the box and does not require any type of controller

to operate. The new Jelly Cosmos Ball has tri colored LED dual

rotating balls which rotate on the base and heads while chaning

color to the beat of the music. This is a great centerpiece effect

with a large coverage area. The rotation speed is adjustable from

21 r.p.m. to 35 r.p.m. This unit produces multiple color beams of

light that creates unique patterns on the floor and walls. To opti-

mize beam intensity use this fixture with a fog machine or other

type of special effect smoke. This fixture is suitable for theaters,

studios, retail stores, and other similar locations.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide set up help and to answer any

question should you encounter problems during your set up or

initial operation. You may also visit us on the web at www.adj.

com for any comments or suggestions. For service related issue

please contact ADJ Products, LLC. Service Hours are Monday

through Friday 8:00 a.m. to 4:30 p.m. Pacific Standard Time.

Voice: (800) 322-6337

Fax: (323) 725-6100

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or fire,

do not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do

not attempt any repairs yourself, doing so will void your manu-

factures warranty. In the unlikely event your unit may require ser-

vice please contact ADJ Products, LLC.

PLEASE recycle the shipping carton whenever possible.

ADJ Products, LLC - www.adj.com - Jelly Cosmos Ball Instruction Manual Page 2

User Instructions

Rev. 3/14

JELLY COSMOS BALL

ADJ Products, LLC - www.adj.com - Jelly Cosmos Ball Instruction Manual Page 4ADJ Products, LLC - www.adj.com - Jelly Cosmos Ball Instruction Manual Page 3

Jelly Cosmos Ball Operation

Power Supply: The ADJ Jelly Cosmos Ball contains a auto-

matic voltage switch, which will auto sense the voltage when

it is plugged into the power source. With this switch there is no

need to worry about the correct power voltage, this unit can be

plugged in anywhere.

General Operation: Just plug this light in, switch the power

on, and watch it go. This fixture can operate in two ways, either

sound active color change or auto color change. The Jelly

Cosmos Ball is ready to be plugged in, out of the box. After

plugging the unit in, switch the power switch to the “On” posi-

tion. When the unit is on the base and two outer heads will

immediately begin to spin.

Adjustable Speed Knob: The speed at which this unit spins

can be adjusted by turning the knob located at the base of the

unit. When the knob is turned all the way counter-clockwise it

will spin the slowest at 21 r.p.m. By turning the knob clockwise

you can increase the rate of speed 21 r.p.m. to the fastest rate

at 35 r.p.m.

Please carefully read and understand the instructions in this

manual thoroughly before attempting to operate this unit. These

instructions contain important safety information regarding the

use and maintenance of this unit. Please keep this manual with

the unit, for future reference.

Jelly Cosmos Ball General Instructions

Jelly Cosmos Ball Precautions

Jelly Cosmos Ball Unpacking

• Donotattempttoremoveorbreakoffthegroundprongfromthe

 electricalcord.Thisprongisusedtoreducetheriskofelectrical

 shockandreincaseofaninternalshort.

•Donotremovetheunitcoverunderanyconditions.Thereareno

 userserviceablepartsinside.

• Neverplugthisunitintoadimmerpack

• Alwaysbesuretomountthisunitinanareathatwillallowproper

 ventilation.Allowabout6”(15cm)betweenthisdeviceandawall.

• Toreducetheriskofelectricalshockorre,donotexposethisunit

 rainormoisture.

• Thisunitisintendedforindooruseonly,useofthisproductout- 

 doorsvoidsallwarranties.

• Duringlongperiodsofnonuse,disconnecttheunit’smainpower.

• Alwaysmountthisunitinsafeandstablematter.

• Power-CordProtection-Power-supplycordsshouldberoutedso

 thattheyarenotlikelytobewalkedonorpinchedbyitemsplaced

 uponoragainstthem,payingparticularattentiontocordsatplugs,

 conveniencereceptacles,andthepointwheretheyexitfromthefix-

 ture.

•Cleaning-Thefixtureshouldbecleanedonlyasrecommendedby

 themanufacturer.

• Thefixtureshouldbeservicedbyqualifiedservicepersonnelwhen:

 A.Thepowercordortheplughasbeendamaged.

 B.Objectshavefallen,orliquidhasbeenspilledintotheappliance.

 C.Theappliancehasbeenexposedtorainorwater.

 D.Thefixturedoesnotappeartooperatenormallyorexhibitsa

markedchangeinperformance.

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Produkt Specifikationer

Mærke:	Adj
Kategori:	Effektmaskine
Model:	Jelly Cosmos Ball
Bredde:	134 mm
Dybde:	337.9 mm
Højde:	254 mm
Vægt:	2000 g
Produktfarve:	Black, Transparent
Kontroltype:	Knapper
Lampe type:	LED
Produkttype:	Disco spotlight
Strømforbrug (typisk):	18.4 W
Antal:	1
Strømkilde:	Vekselstrøm
Pæreeffekt:	3 W
Antal lamper:	4 Lampe( r)
Indgangsspænding:	100 - 240 V
Strålevinkel:	360 °
Pære levetid:	50000 t
Indgangsfrekvens:	50 - 60 Hz
Bold diameter:	- "
