Side 1/6
11/10
User Instructions
RGB 3C
LED CONTROLLER
Unpacking: Thank you for purchasing the RGB 3C by American DJ . ®
Every RGB 3C has been thoroughly tested and has been shipped in
perfect operating condition. Carefully check the shipping carton for
damage that may have occurred during shipping. If the carton appears
to be damaged, carefully inspect your xture for any damage and be
sure all equipment necessary to operate the unit has arrived intact. In
the event damage has been found or parts are missing, please contact
our toll free customer support number for further instructions. Please
do not return this unit to your dealer without contacting customer sup-
Introduction: The RGB 3C small, lightweight, very easy to use,
3-channel RGB LED controller. The RGB 3C is designed to control
any 3 channel RGB fixture. The RGB 3C has a sound active mode,
program mode, auto run, and static color mode. It also features RGB
faders so that you can create your own unique color. This controller
is the ideal control solution for D.J.’s, small night clubs, and bars that
want a simple LED controller to run the show.
Customer Support: American DJ provides a toll free customer ®
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
RGB 3C General In formation
American DJ® www.americandj.com - RGB 3C Page 2
American DJ® www.americandj.com - RGB 3C Page 3
• 9 Static Colors
• RGB Faders To Create Desired Color
• 10 Factory Programs
• Auto, Program, Color, and Sound Active Operation Modes
• Adjustable Program Speed
• Adjustable Sound Sensitivity
• Strobing
• Hold Button Locks the Controller and Pauses Current Scene
RGB 3C Features
American DJ® www.americandj.com - RGB 3C Page 4
RGB 3C Product Registration
RGB 3C DMX
Power Supply: Before plugging your unit in, be sure the source volt-
age in your area matches the required voltage for your American DJ ®
RGB 3C. The American DJ RGB 3C is 120v only. Only use the included ®
power supply to power RGB 3C.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used by most lighting and controller manufactures as a form of
communication between intelligent fixtures and controllers. A DMX
controller sends DMX data instructions from the controller to the fix-
ture. DMX data is sent as serial data that travels from fixture to fixture
via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX
fixtures (most controllers only have a DATA “OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
different manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-
ant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. Therefore, the first fixture controlled by
the controller could be the last fixture in the chain. When a fixture is
assigned a DMX address of 1, the DMX controller knows to send DATA
assigned to address 1 to that unit, no matter where it is located in the
DMX chain.
Data Cable (DMX Cable) Requirements (For DMX and Master/Slave
Operation): DMX controller and unit require a approved DMX-512
110 Ohm Data cable for data input and data output (Figure 1). We
recommend Accu-Cable DMX cables. If you are
making your own cables, be sure to use standard
110-120 Ohm shielded cable (This cable may be
purchased at almost all professional sound and
lighting stores). Your cables should be made with
a male and female XLR connector on either end of
the cable. Also remember that DMX cable must be
daisy chained and cannot be split.
Figure 1
The VioRoll LED carries a 2 year (730 days) limited warranty. Please
fill out the enclosed warranty card to validate your purchase and war-
ranty. You may also register your product online at www. americandj.
com. All returned service items whether under warranty or not, must
be freight pre-paid and accompany a return authorization (R.A.) num-
ber. If the unit is under warranty you must provide a copy of your proof
of purchase invoice. Please contact American DJ® customer support
for a R.A. number.
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
RGB 3C General Instructions
