Side 1/10

User Instructions

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 2

Unpacking: Thank you for purchasing the Royal 3D II by ADJ Prod-

ucts, LLC. Every Royal 3D II has been thoroughly tested and has been

shipped in perfect operating condition. Carefully check the shipping

carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all equipment necessary to operate the unit has

arrived intact. In the event damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Please do not return this unit to your dealer without con-

tacting customer support rst.

Introduction: The Royal 3D II is an incredible five channel DMX intel-

ligent, green and violet blue laser fixture. The blue laser combined with

the green laser create amazing aerial effects on a ceiling or wall. The

Royal 3D II can operate as a stand alone fixture, or in a Master/Slave

configuration. The Royal 3D II has two operating modes; sound active

or controlled via DMX. This fixture is suitable for theaters, studios,

retail stores, and other similar locations. For best results use fog or

special effects smoke to enhance the beams projections.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide set up help and to answer any question

should you encounter problems during your set up or initial operation.

You may also visit us on the web at www.adj.com for any comments

or suggestions. For service related issue please contact ADJ Products,

LLC. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.

Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ customer support.

PLEASE recycle the shipping carton whenever possible.

Royal 3D II General Introduction

3/13

ROYAL 3D II

ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 4ADJ Products, LLC - www.adj.com - Royal 3D II Instruction Manual Page 3

Please carefully read and understand the instructions in this manual

thoroughly before attempting to operate this unit. These instructions

contain important safety information regarding the use and mainte-

nance of this unit. Please keep this manual with the unit, for future

reference.

CAUTION IMPORTANT! When installing this projector, make sure

that it is mounted in a manner that prevents the audience from

looking directly into the beam, and the beam from striking the

audience.

Royal 3D II General Instructions

Safety Issues: This unit may “pop” the fuse if the maximum allotted

load of 7 amps is reached.

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture.

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to remove or break off the ground prong from the

electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short. Do not attempt to oper-

ate this unit if the power cord has been frayed or broken.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 18 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances

(including amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The unit does not appear to operate normally or exhibits a

marked change in performance.

• 30mW Green Laser & 350mW Violet Blue Laser

• 5 Channel DMX Control

• 2 Operating Modes - Sound Active & DMX Control

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

• Run as Stand Alone unit or in a Master-Slave Conguration

• Power Cord Daisy Chain up to 14 units max. See page 16

Royal 3D II Features

Royal 3D II Warranty Registration

The Royal 3D II carries a 90 day limited warranty. Please fill out the

enclosed warranty card to validate your purchase. All returned ser-

vice items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. If the unit is

under warranty you must provide a copy of your proof of purchase

invoice. Please contact ADJ customer support for a R.A. number.

The unit should be mounted using a mounting clamp (not provided),

afxing it to the mounting bracket that is provided with the unit.

Always ensure that the unit is rmly xed to avoid vibration and slip-

ping while operating. Always ensure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10

times the unit’s weight. Also, always use a safety cable that can hold

12 times the weight of the unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

Royal 3D II Installation

Royal 3D II Safety Precautions

LASER RADIATION AVOID

DIRECT EYE EXPOSURE

Maximum output <5 mW

Wavelength: 532nm, 450nm

Class IIIa laser product

This device complies with 21 CFR chapter I,

Subchapter J, CFR 1040.10 and 1040.1 1
