Quick Start Guide for ADAM-6700 Series and ADAM-6700E.

This Quick Start Guide demonstrates how to use ADAM-6700E, USB to MiniPCIe

Adaptor Module, to extend wireless communicaon for ADAM-6700 series.

ADAM-6700 Web Ulity Conguraon

To obtain the gateway IP address, connect the LAN port of the ADAM-6700 device to your

computer. Then use the ADAM/Apax.NET Ulity, version 2.05.11 B19 or later, to obtain the

IP address (stac or DHCP mode). Please refer below steps

1. Enter the ADAM/Apax.NET Ulity. Right-click the Ethernet Search Device icon and click .

Figure 1. 1 Web Ulity Searching Devices

2. The ADAM/Apax.NET Ulity will list the connected ADAM-6700 gateways and their IP

address.

Figure 1 Web Ulity Obtaining the Gateway IP Address .2

Note: Advantech has developed a web portal for conguring the ADAM-6700 series

gateways. To access the web portal, users must obtain the IP address of the assigned LAN

port. Then open a browser and type the IP address of the LAN port. The default IP setup

mode is “DHCP”.

 If the IP mode is set as “DHCP and the gateway is connected to the DHCP server, ”

type the IP address of the assigned LAN port.

 If the IP mode is set as “DHCP”, but the gateway is not connected to the DHCP

server, the LAN port will be automacally set to (Eth0)10.0.0.1 and (Eth1)

11.0.0.1

 If the IP mode is set as “stac IP”, input the assigned stac IP address.

3. Open the web ulity

Input the LAN Port IP Address in browser.

Figure 1. Input the LAN Port IP Address 3

Aer inpung the LAN port IP address, the web portal interface should be displayed.

Click “Link” to navigate to the web ulity conguraon page.

Figure 1 Web Portal .4

4. On the Conguraon page of the web ulity, click “Link”. In the popup window

displayed, enter the username and password and click “Sign In”.

Default username: root

Default password: 00000000

Figure 1.5 Web Utility Login Window

Figure 1.6 Web Utility Conguraon Page

Wi- Network SeingFi

Users need to click andEnable WLAN set the SSID name and security of the WLAN to

join the network. There are 3 oponal security modes for the network:
