AFE-R360DVK-M01 Startup Manual 1
Before you begin installing your module, make sure that the following materials have been included:
• 1 x AFE-R360C5P-Q5A1
• 1 x SQR-SD5N16G5K6HNAG, SODIMM DDR5 5600 16GB
• 1 x SQF-C8BV2-128GDEDC, M.2 2280 128G NVMe, with pre-load OS & driver
• 1 x MIOE-MIPI-RPA1
• 4 x MIPI camera EV2M-OOM1, 22pin MIPI cam, 1920x1200 (w cable) (PN: 968DD00501)
• 1 x Cooler (PN: 1970005512T001)
• 1 x USB2.0 cable (PN: 1700030406-01)
• 1 x MIOe-MIPI assembly screw pack (PN: 9666R360010)
If any of the above items are missing or damaged, please contact your distributor or sales representative immediately.
Note: For detailed contents regarding AFE-R360DVK-M01, please refer to information on the support website: http://sup-
port.advantech.com.tw/.
AFE-R360DVK-M01 AFE-R360, 125H, 4 x MIPI
(2MP) Development Kit
Startup Manual
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website at:
http://www.advantech.com/support/
This startup manual is for AFE-R360DVK-M01.
Part No. 2046R36000 Edition 1
January 2025
2 AFE-R360DVK-M01 Startup Manual
Fig 1: AFE-R360 & MIOe-MIPI Installation
Fig 2: AFE-R360 & MIOe-MIPI Complete Installation
3-1935030500
3-1910000026
MIPI BOARD
AFE-R360 BOARD
3-1910000041
Mechanical Assembly
