AIMB-785 Startup Manual 1

AIMB-785 LGA1151 Intel® Core™ i7/i5/i3 ATX with

Triple Display, DDR4, SATA III

Startup Manual

Specications (Cont.)

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the AIMB-785 series Rev. A1.

Part No. 2001078513

Printed in China

4th Edition

October 2024

• SATA interface: Four on-board Serial ATA 3.0 connectors

support data transmission rates of up to 600 MB/s. All

four SATA 3.0 ports support Advanced Host Controller

Interface (AHCI) technology.

• PCIe and PCI slots: 1 PCIe x16 expansion slot, 3 PCIe

x4 expansion slots, 3 PCI slots 32-bit/33 MHz PCI 2.2

compliant

• LPC interface: Advantech-designed LPC connector sup-

ports dTPM 2.0 module

• Serial ports: Six serial ports: COM1, COM2 and COM4 ~

6 are RS-232; COM3 is RS-232/422/485 with BIOS menu

options

• Keyboard/mouse connector: An external keyboard and

mouse connector on the motherboard is supported. No

PS/2 keyboard/mouse connector is supported in the rear

I/O.

• Watchdog timer: 255 sec timer intervals

• USB 3.0/2.0: Thirteen USB ports: 1/2/3/4/13/14 are USB

3.0; others are USB 2.0.

Graphics Interface

• Chipset: CPU integrated graphics controller

• Display Memory: 1 GB maximum shared memory with 2

GB and above system memory installed

• Resolution: Supports DVI up to 1920 x 1200 resolution

@ 60 Hz refresh rate.

Supports VGA up to 1920 x 1200 resolution @ 60 Hz

refresh rate.

Ethernet Interface

• Interface: 10/100/1000 Mbps

• Controller: LAN1: Intel

I219LM; LAN2: Intel

I210AT

Mechanical and Environmental

• Dimensions (L x W): 304.8 x 244 mm (12” x 9.6”)

• Power supply voltage: +3.3 V, +5 V, +12 V, +5 Vsb

• Power consumption:

Intel® Core™ Intel® I7-6700 3.4 GHz; DDR4 8 G x 4

Maximum: +3.3 V at 1.02 A, +5 V at 1.96 A, +12 V at 1.14

A, +5 Vsb at 0.08 A, -5 V at 0.03 A, -12 V at 0.06 A

• Operating temperature: 0 ~ 60°C (depending on CPU)

• Weight: 0.7 kg (weight of board)

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 AIMB-785 motherboard

• 1 AIMB-785 Startup Manual

• 2 Serial ATA HDD data cables

• 2 Serial ATA HDD power cables

• 1 I/O port bracket

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

le.AcrobatReadercanbedownloadedat:

www.adobe.com/Products/acrobat/readstep2.

html (Acrobat is a trademark of Adobe)

Specications

Standard Functions

• CPU: LGA1151 6th and 7th Gen Intel® Core™ i7/i5/i3

and Celeron®/Pentium® processors

Note: Only 6th Gen Intel® processors can support

Windows 7.

• BIOS: AMI 128 Mb SPI BIOS

• Chipset: Intel® Q170 chipset

• System memory: Up to 64 GB with four 288-pin DIMM

sockets, supporting dual-channel DDR4 1866/2133

SDRAM.AIMB-785supportsnon-ECCunbu󰀨eredDIMMs

anddoesnotsupportanymemorycongurationthat

mixesnon-ECCwithECCunbu󰀨eredDIMMs.

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 64 GB RAM

when 64 GB RAM is installed.

2 AIMB-785 Startup Manual

The board has a number of jumpers that allow you to con-

gureyoursystemtosuityourapplication.Thetablebelow

lists the function of each jumper and connector.

Connector / Jumper List

Label Function

JWDT1 Watchdog reset

LPC1

Low pin count connector for Advantech

dTPM 2.0 and RS232 modules

LAN1_USB12 LAN1 / USB 3.0 port 1, 2

LAN2_USB34 LAN2 / USB 3.0 port 3, 4

VGA1+COM1 VGA connector / COM connector

DVI1+DVI2 Dual DVI-D connectors

COM1 Serial port: RS-232 (DB-9 connector)

COM2

COM4

COM5

COM6

Serial port: RS-232 (9-pin header)

COM3

Serial port : RS-232/422/485 (9-pin

header)

KBMS1 Keyboard and mouse connector (6-pin)

JFP3

Keyboard lock and power/sleep LED

Suspend:fastash(ATX/AT)

Systemon:ON(ATX/AT)

Systemo󰀨:OFF(AT/ATX)

JFP2

External speaker / HDD LED connector

SNMP / SM Bus connector

JFP1 Power switch / reset connector

JCASE1 Case open connector

PSON1 AT/ATXmodeselector

VOLT1 Alarm board power connector

JOBS1

Close: Enable OBS alarm

Open: Disable OBS alarm

CPUFAN1 CPU FAN connector (4-pin)

SYSFAN1 System FAN power connector (4-pin)

SYSFAN2 System FAN power connector (4-pin)

LANLED1 Front panel LAN indicator connector

AUDIO1

AUDIO2

Audio connector (Line-Out, Mic-In)

FPAUD1 Front panel audio pin header

USB56 USB port 5, 6

USB78 USB port 7, 8

USB910 USB port 9, 10

USB11 USB11 (Type-A)

USB1314 USB 3.0 13, 14

SATA2 Serial ATA3

SATA3 Serial ATA4

SATA4 Serial ATA5

SATA5 Serial ATA6

ATX12V1

ATX12Vauxiliarypowerconnector

(for CPU)

EATXPWR1

ATX24-pinmainpowerconnector

(for system)

SPDIF_OUT1 Digital audio output pin header

SPI_CN1 SPIashcardpinheader

JCMOS1

Clear CMOS

JME1 Intel® ME Enable/Disable jumper

JPCICLK1

PCI Clock selection

(1-2): 33/66 MHz auto-detected (default)

(2-3): 33 MHz

JUSB_1

USB power source switch between +5V

and +5V_ DUAL for Rear USB ports

JUSB_2

USB power source switch between +5V

and +5V_ DUAL for On-board USB

ports

GPIO1 8-bit digital I/O connector

SMBUS1 SMBus connector

JCMOS1: CMOS and ME Clear Function

Pins Result

1-2 Keep CMOS data*

2-3

Clear CMOS data

* Default

1 2 3

*Keep CMOS data Clear CMOS data

Jumpers and Connectors

Jumpers and Connectors (Cont.)
