ASMB-927 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 x ASMB-927 Startup Manual

• 1 x SATA data cable

• 1 x SATA power cable

• 2 x CPU power cables (8P)

• 2 x CPU carriers

• 1 x I/O port bracket

• 1 x M.2 screw

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note 1:  AcrobatReaderisrequiredtoviewanyPDFle.

Acrobat Reader can be downloaded at:

https://www.adobe.com/downloads.html

(Acrobat is a trademark of Adobe)

ASMB-927 Dual LGA4677 4th Gen Intel

Xeon

Scalable

EATX Server Board with 16 DDR5, 4 PCIe x16, 9 SATA 3.0,

6 USB 3.2 (Gen1), Dual 10GbE, and IPMI

Startup Manual

Standard M/B Functions

• CPU: Dual LGA4677 4th Gen Intel® Xeon® Scalable

processors

• BIOS: AMI 256 Mbit SPI BIOS

• Chipset: Intel® C741 PCH

• System Memory: 16 x DDR5 3200/3600/4000/4400/4800

MT/s registered ECC DIMM, max. capacity 2 TB

• SATA Interface:

- 8 x SATA 3.0 (6 Gb/s) via Mini SAS HD (SFF-8643),

supports software RAID 0,1,5,10

- 1 x SATA 3.0 (6 Gb/s)

• Serial Ports: One onboard header, only supports RS-232

• Keyboard/Mouse Header: Supports the standard PS/2

keyboard and mouse via PS/2 cable.

• Watchdog Timer: 255 /sec or min level timer intervals

• USB Port: 6 x USB 3.2 Gen1 (4 rear and 2 onboard) and

3 x USB 2.0 (2 onboard and 1 Type-A)

VGA Interface

• Chipset: ASPEED AST2600

• Resolution: Supports VGA up to a resolution of 1920 x

1200 @ 60 Hz refresh rate.

Ethernet Interface

• Interface: 100M/1G/10Gbps

• Controller: LAN1/2: Intel® X710-AT2

Mechanical and Environment

• Dimensions (L x W): 304.8 x 330.2 mm (12” x 13”)

• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vs

• Power Consumption (mainboard only, excluding

I/O devices): Max. load: +3.3V@2.2A, +5V@1.9A,

+12V@0.3A, +5Vsb@0.1A, -12V@0A, 12V_8P@38.53A

• Operating Temperature: 0 ~ 40 °C (depending on CPU)

• Weight: 1.5 kg

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our sup-

port website for ASMB-927 at:

https://advt.ch/asmb927

months extra warranty for free at:

http://www.register.advantech.com

This manual is for the ASMB-927 series Rev. A1

Part No. 2042092700

Printed in China

1st Edition

January 2023

2 ASMB-927 Startup Manual

The board has a number of jumpers that allow you to con-

gureyoursystemtosuityourapplication.Thetablebelow

lists the function of each of the jumpers and connectors.

Connectors

Label Function

ATXPWR1

ATX 24-pin main power connector

ATX12V1, ATX12V3

Processor power connector

(mandatory)

ATX12V2, ATX12V4

Processor power connector

(reserved)

BH2 For optional battery kit

BIOS_SKT1 BIOS SPI ROM

BMC_SPI1 BMC SPI ROM

BMC_LAN IPMI dedicated LAN connector

COM1 RS-232 connector

COM2 RS-232 header

CPUFAN0, CPUFAN1 CPU FAN connector

DIMMA1, DIMMB1,

DIMMC1, DIMMD1,

DIMME1, DIMMF1,

DIMMG1, DIMMH1

DDR5 from CPU0

DIMMI1, DIMMJ1,

DIMMK1, DIMML1,

DIMMM1, DIMMN1,

DIMMO1, DIMMP1

DDR5 from CPU1

DIMMA1, DIMMC1,

DIMME1, DIMMG1,

DIMMI1, DIMMK1,

DIMMM1, DIMMO1

DCPMM slot

EC_SKT1 EC EEPROM

ESPI1 eSPI connector

EX_THR1 Connector for external thermistor

GPIO1 GPIO connector

HDAUD1 Audio header

JFP1, JFP2, JFP3 Front panel header

KBMS2

External keyboard and mouse

connector

LAN1, LAN2 10 Gbps LAN connector

LANLED1 LAN LED extension connector

M2_2280_2 M.2 connector (SATA & PCIe x4)

PCIEX16_SLOT1 PCIe x16 slot (CPU0)

PCIEX8_SLOT2 PCIe p2-x8 slot (CPU1)

PCIEX16_SLOT3 PCIe x16 slot (CPU0)

Jumpers and Connectors (Cont.)

PCIEX8_SLOT4 PCIe p2-x8 slot (CPU1)

PCIEX16_SLOT5 PCIe x16 slot (CPU0)

PCIEX16_SLOT6 PCIe x16 slot (CPU1)

PMBUS1

PMBUS connector to communi-

cate with the power supply

SATA0~SATA3,

SATA4~7

SATA via SFF-8643

SGPIO1 SATA0~3 SGPIO header

SGPIO2 SATA4~7 SGPIO header

SLOT12V1 For PCIe slot 12V input only

SMBUS1 SMBus header

SSATA SATA connector

SYSFAN0~SYSFAN3,

REAR_FAN

System FAN connector

SYS_LED1 System LED connector

USB2H1 USB 2.0 port (9-pin header)

USB2A1 USB 2.0 port (Type-A)

USB3H1 USB 3.0 port (20-pin header)

VGA1 VGA connector

Jumper list

Label Function

JCASE1 Chassis case open alarm

JCMOS1

CMOS clear

JME1 ME update

JTHR_SEL1

Internal (default pins 1-2) and external

(pins 2-3) thermistor selection

JWDT1 Watchdog reset

PSON1 AT(1-2) / ATX(2-3)

JCMOS1/JME1: CMOS Clear/ME Update Function

Closed pins Result

1-2

Keep CMOS data/Disable ME update*

2-3 Clear CMOS data/Enable ME update

*: Default

Keep CMOS data / Disable ME update Clear CMOS data / Enable ME update

1 2 3

Jumpers and Connectors
