ASMB-935 Startup Manual 1

Before you begin installing your card, please make sure

that the following items have been shipped:

• 1 ASMB-935 Startup Manual

• 1 Driver CD

• 2 Serial ATA HDD data cables

• 2 Serial ATA HDD power cables

• 2 CPU power cables (8P)

• 1 I/O port bracket

• 1 Warranty card

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note 1: Acrobat Reader is required to view any PDF ﬁle.

Acrobat Reader can be downloaded at:

https://www.adobe.com/downloads.html

(Acrobat is a trademark of Adobe)

ASMB-935 LGA 3647 Dual Intel Xeon® Processor Scalable

Family Server Board with 24 DDR4, 5 PCIe x16 + 1 PCIe

x8, 10 SATA3, 6 USB3.0, Dual 10GbE, IPMI

Startup Manual

Standard M/B Functions

• CPU: Dual LGA3647-P0 Intel Xeon® processor scalable

family series

• BIOS: AMI 256 Mb SPI BIOS

• Chipset: Intel® C620 PCH

• System Memory: 24* DDR4-1866/2133/2400/2666

registered ECC DIMM, max. capacity 768 GB

Note 2: Due to the inherent limitations of the PC architec-

ture, the system may not fully detect 768 GB

RAM when 768 GB RAM is installed.

• SATA Interface: 10 SATA3 6 Gb/s ports Intel Rapid

Storage (for Windows only) (supporting software RAID 0,

1, 10 & 5 )

• Serial Ports: Two RS-232 (one on rear I/O, and another

one via pin header)

• Keyboard/Mouse Header (KBMS1): Supports the stan-

dard PS/2 keyboard and mouse via PS/2 cable

• Watchdog Timer: 255 sec/min level timer intervals

• USB Port: Supports up to 6 USB 3.0 ports (2 ports from

onboard 20-pin header) and 5 USB 2.0 ports (1*Type-A,

4 ports from onboard 10-pin header)

VGA Interface

• Chipset: ASPEED AST2500/2510

• Display Memory: 64 MB

• Resolution: Supports VGA up to resolution 1920 x 1200

@ 60 Hz refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps & 10Gb (only for LAN3 &

LAN4)

• Controller: LAN1/2: Intel I210; LAN3/4: Intel X557

Mechanical and Environment

• Dimensions (L x W): 330 x 304 mm (13” x 12”)

• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vsb

• Power Consumption (mainboard only, excluding

IO device): Max. load: +3.3V@6.77A, +5V@5.11A,

+12V@0.04A, +5V_SB@0.17A, -12V@0.01A,

+12V_8P_0@21.49A, +12V_8P_1@23.10A

• Operating Temperature: 0 ~ 40° C (depending on CPU)

• Weight: 1.5 kg (weight of board)

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com

This manual is for the ASMB-935 series Rev. A1

Part No. 2001093500

Printed in China

1st Edition

May 2018

2 ASMB-935 Startup Manual

The board has a number of jumpers that allow you to con-

ﬁgure your system to suit your application. The table below

lists the function of each of the jumpers and connectors.

Connectors

Label Function

ATXPWR1

ATX 24 Pin main power connector

ATX12V1

Processor power connector

(for CPU0)

ATX12V2

Processor power connector(for

CPU1)

BH2 For optional battery kit

BIOS_SKT1 BIOS ROM

BMC_CN1, BMC_CN2 IPMI module header

CN1 CPLD code update header

COM2 Serial port RS-232

CPUFAN0, CPUFAN1 CPU FAN connector

DIMMA1, DIMMA2,

DIMMB1, DIMMB2,

DIMMC1, DIMMC2,

DIMMD1, DIMMD2,

DIMME1, DIMME2,

DIMMF1. DIMMF2

DDR4 slot from CPU0

DIMMG1, DIMMG2,

DIMMH1, DIMMH2,

DIMMI1, DIMMI2,

DIMMJ1, DIMMJ2,

DIMMK1, DIMMK2,

DIMML1. DIMML2

DDR4 slot from CPU1

DIMMC1, DIMMF1,

DIMMI1, DIMML1

DDR4 slot supporting AEP

memory

EX_THR1 Connector for external thermistor

GPIO1 GPIO connector

HDAUD1 Audio header

JFP1, JFP2, JFP3 Front panel header

KBMS1

External keyboard and mouse

connector (6 pin)

LAN1_USB3_12

RJ-45 LAN port 1 + USB 3.0 port

1/2 connector

LAN2_USB3_34

RJ-45 LAN port 2 + USB 3.0 port

3/4 connector

LANLED1 LAN LED extension connector

LPC2 TPM connector

M2_2280_1 M.2 2280 (PCIe & SATA signal)

PCIEX16_SLOT1 PCIE x16 slot (CPU1)

PCIEX16_SLOT2 PCIE x16 slot (CPU1)

PCIEX16_SLOT3 PCIE x16 slot (CPU0)

Jumpers and Connectors (Cont.)

PCIEX8_SLOT4 PCIE p2-x8 slot (CPU0)

PCIEX16_SLOT5 PCIE x16 slot (CPU1)

PCIEX16_SLOT6 PCIE x16 slot (CPU0)

PCN1 CPU power code update header

PEHP1 CPU SMBUS header

PMBUS1

PMBUS connector to

communicate with power supply

SATA0~SATA7 Serial ATA0~7

SGPIO1 sSATA SGPIO header

Slot12V1 For PCIe slot 12V input only

SMBUS1 SMBus header

SPI_CN1 Connector for BIOS update tool

SPI_SKT1 EC EEPROM

sSATA0, sSATA1 sSATA port 0~1

SYS_LED1 System LED connector

SYSFAN0~SYSFAN4 System FAN connector

USB2_78, USB2_910

USB 2.0 port 7, 8, 9, 10 (9-pin

header)

USB2_11 USB 2.0 port 11 (Type-A)

USB3_56 USB 3.0 port 5,6 (20-pin header)

VGA1_COM1 VGA and COM connector

VOLT1 Alarm board power connector

VROC1 Intel Virtual RAID (VROC) key

Jumper List

Label Function

JCASE1 Chassis case open alarm header

JCMOS1

CMOS clear

JME1 ME update

JTHR_SEL

Internal (deault pin1-2) or external

(pin2-3) thermistor selection

JWDT1 Watch dog reset

PSON1 AT(1-2) / ATX(2-3)

JCMOS1/JME1: CMOS clear/ME update function

Closed pins Result

1-2

Keep CMOS data/Disable ME update*

2-3 Clear CMOS data/Enable ME update

*: Default

Keep CMOS data/Disable ME update Clear CMOS data/Enable ME update

1 2 3

Jumpers and Connectors
