EKI-2718E-2CI Startup Manual 1
The EKI-2718E-2CI industrial Ethernet switch provides 16 ×
10/100M + 2GE combo ports, o󰀨ering versatile connectivity
for diverse applications. Users can conveniently enable or
disable Quality of Service (QoS), broadcast storm protec-
tion, and VLAN settings using DIP switches. Equipped with
12–48 VDC redundant power inputs and DIN-rail mounting,
this switch is designed for reliable performance in industrial
environments. With EMC Level 4 protection, it resists elec-
harsh conditions.
Packing List
Before installation, please make sure that you have rehceived
the following:
• 1 x EKI-2718E-2CI Ethernet Switch
• 1 x DlN-rail mounting bracket with screws (M3 x 5L)
• 2 x Wall mounting brackets with screws (M3 x 5L)
• 1 x EKI-2718E-2CI Startup Manual
If anything is missing or damaged, contact your distributor or
sales representative immediately.
EKI-2718E-2CI 16FE + 2GE Combo Unmanaged
Ethernet Switch
Startup Manual
General
• Compatibility: IEEE 802.3, 802.3u, 802.3ab, 802.3z,
802.3x,802.1p
• LAN: 16 x 10/100BaseT(X) + 2 x 10/100/1000Base-T(X)
or 100/1000Base-FX SFP
• Ethernet RJ-45: Up to 100 m
• Connectors: 16 x Fast Ethernet (RJ45) + 2 x Giga (RJ45/
SFP) combo ports
• Switch Architecture: Store and Forward
• Power Input: 12~48VDC, redundant power
• Power Consumption: 7W
• Dimensions (W x H x D): 72 x 140 x 105 mm
• Enclosure: IP30
• Operating Temperature:
-40 ~ 75°C (-40 ~ 167°F)
• Storage Temperature: -40 ~ 85°C (-40°F ~ 185°F)
• Operating Humidity: 5 ~ 95% (non-condensing)
• Storage Humidity: 5 ~ 95% (non-condensing)
• Safety: UL62368
• EMC: CE, FCC Class A, BSMI
• Warranty: 5 years
Introduction
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com/products/
For technical support and service:
http://www.advantech.com/support/
This manual is for the EKI-2718E-2CI.
Part No. 2049271800 1st Edition
December 2024
Specications
2 EKI-2718E-2CI Startup Manual
LEDDenition
LED Color Description
P1 Green
On
P1 is being supplied to
power input.
O󰀨
P1 is not being supplied
to power input.
P2 Green
On
P2 is being supplied to
power input.
O󰀨
P2 is not being supplied
to power input.
Copper
Ports
(P1~P16)
Green
(top)
On Ethernet port link
Blinking Ethernet port active
O󰀨 No link
Amber
(bottom)
On
When the port’s data is
being transmitted at 100M
O󰀨
When the port’s data is
being transmitted at 10M
Combo:
Fiber /
Copper
Ports
(P17~P18)
Green
(Fiber/
top)
On Ethernet port link
Blinking Ethernet port active
O󰀨 No link
Green/
Amber
(Copper/
bottom)
Green
On
When the port’s data
is being transmitted at
1000M
Amber
On
When the port’s data is
being transmitted at 100M
O󰀨
When the port’s data is
being transmitted at 10M
Overview
This series provide 4-pin DIP switches for function setting.
DIP switch denition is listed as follows:
Pin Function Setting Description
1 ONQoS
Switch the DIP to “ON” to
activate Quality of Service for
managing packet priorities.
CoS
Priority
7,6 1,05,4 3,2
WRR 8 4 2 1
2 ONBSP
Switch the DIP to “ON” to
activate broadcast storm protec-
tion for all ports, limiting the
threshold to be 2000 broadcast
packets/second.
3VLAN ON
Switch the DIP to “ON” to
activate VLAN.
(running by the following mode
options.)
4
VLAN
Mode 1
VM1
Switch the DIP to the ‘left’ posi-
tion to activate VLAN Mode 1,
Port Isolated Mode.
All ports are isolated from each
other, with only Uplink Ports 17
& 18 interconnected with other
ports.
VLAN
Mode 2
VM2
Switch the DIP to the ‘right’
position to activate VLAN Mode
2, 2-Grouping Mode.
This divides all ports into two
separate groups, ensuring no
interconnection between them.
Group 1 comprises Ports 1-8
with uplink port 17, while Group
2 comprises Ports 9-16, with
uplink port 18.
DIP Switch
