Side 1/5

MIC-3810 Startup Manual 1

Before you begin installing your IPC, please make sure that

the following items have been shipped:

1. 1 x MIC-3810-A1D1

2. 2 x Screws M2.5*6LR/S D

3. 1 x Screws M2.5x4.5L 1/4R/S D

4. 1 x Display card panel cover(U)

If any of the above items are missing or damaged, contact

your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF le.

Acrobat Reader can be downloaded at:

www.adobe.com/Products/acrobat/readstep2.

html (Acrobat is a trademark of Adobe)

MIC-3810

3U CompactPCI

Serial PCIe Carrier Board

Startup Manual

Standard Functions

• Backplane Interface: PCIe Gen3 x8

• PCIe Connector: PCIe x16, backwards compatible PCIe

x1, PCIe x4, PCIe x8

• Card Size: maximum dimensions of 176 x 68.9 mm (6.9”

x 2.7” inches).

• Power: +12V, +5V standby: Power consumption depend-

ing on plugged module, supports up to 80W

Mechnical and Environment

• Dimensions (W x H x D): 160.00 x 100.00 mm (6.30” x

3.95”)

• Non-operating Temperature: -40 ~ 85 °C (-40 ~ 185 °F)

• Operating Temperature (depending on module): -40 ~

70 °C (-40 ~ 158 °F)

• Operating Humidity: 95% @ 40 °C, non-condensing

• Non-operating Humidity: 95% @ 60 °C, non-condensing

• Vibration (5~500 Hz): 2.0 Grms

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support services, please visit our support

website at:

http://support.advantech.com

This manual is for the the MIC-3810-A1D1.

Part No. 2041381000

Printed in China

Edition 1

July 2022

Specications

2 MIC-3810 Startup Manual

P1PinDenition

Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name

A1 +12V_HOT B1 +5V_STANDBY C1 GND D1 +12V_HOT

A2 GND B2 SMB_P1_CLK C2 SMB_P1_SDA D2 GND

A3 NC B3 NC C3 P1_GA0 D3 NC

A4 GND B4 NC C4 NC D4 GND

A5 PEG_P1_TX0P B5 PEG_P1_TX0N C5 GND D5 PEG_P1_RX0P

A6 GND B6 PEG_P1_TX2P C6 PEG_P1_TX2N D6 GND

Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name

E1 +12V_HOT F1 GND G1 +12V_HOT H1 +12V_HOT

E2 NC F2 P1_PLTRST# G2 GND H2 P1_PLTRST#

E3 NC F3 P1_GA1 G3 NC H3 NC

E4 PCIE_P1_CLKP F4 PCIE_P1_CLKN G4 GND H4 NC

E5 PEG_P1_RX0N F5 GND G5 PEG_P1_TX1P H5 PEG_P1_TX1N

E6 PEG_P1_RX2P F6 PEG_P1_RX2N G6 GND H6 PEG_P1_TX3P

Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name

I1 GND J1 +12V_HOT K1 +12V_HOT L1 GND

I2 P1_WAKE_OUT# J2 GND K2 P1_PCIE_EN# L2 NC

I3 P1_GA2 J3 NC K3 NC L3 P1_GA3

I4 NC J4 GND K4 NC L4 NC

I5 GND J5 PEG_P1_RX1P K5 PEG_P1_RX1N L5 GND

I6 PEG_P1_TX3N J6 GND K6 PEG_P1_RX3P L6 PEG_P1_RX3N

P2PinDenition

Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name

A1 PEG_P2_TX4P B1 PEG_P2_TX4N C1 GND D1 PEG_P2_RX4P

A2 GND B2 PEG_P2_TX6P C2 PEG_P2_TX6N D2 GND

A3 NC B3 NC C3 GND D3 NC

A4 GND B4 NC C4 NC D4 GND

A5 NC B5 NC C5 GND D5 NC

A6 GND B6 NC C6 NC D6 GND

A7 NC B7 NC C7 GND D7 NC

A8 GND B8 NC C8 NC D8 GND

Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name

E1 PEG_P2_RX4N F1 GND G1 PEG_P2_TX5P H1 PEG_P2_TX5N

E2 PEG_P2_RX6P F2 PEG_P2_RX6N G2 GND H2 PEG_P2_TX7P

E3 NC F3 GND G3 NC H3 NC

E4 NC F4 NC G4 GND H4 NC

E5 NC F5 GND G5 NC H5 NC

E6 NC F6 NC G6 GND H6 NC

E7 NC F7 GND G7 NC H7 NC

E8 NC F8 NC G8 GND H8 NC

PinDenition
