PCE-7129/5129/5029 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

1. 1 x PCE-7129/5129/5029 PICMG 1.3 Single Host Board

2. 1 x PCE-7129/5129/5029 Startup Manual

3. 1 x CD with utility

4. 1 x Serial ATA HDD data cables

5. 1 x Serial ATA HDD power cables

6. 1 x COM port cable kit

7. 1 x 2-port USB cable kit

8. 1 x Keyboard and mouse Y cable

9. 1 x Jumper package

10. 1 x Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note 1: For detailed contents of PCE-7129/5129/5029,

please refer to the user manual in the enclosed

CD-ROM (in PDF format).

Note 2: Acrobat Reader is required to view any PDF

le. Acrobat Reader can be downloaded at: get.

adobe.com/reader (Acrobat is a trademark of

Adobe)

PCE-7129/5129/5029 LGA1151 Intel

Core

i7/i5/i3/

Pentium

/Xeon

(PCE-7129) PICMG 1.3 Single Host

Board with (ECC) DDR4/M.2 (2280)/Dual GbE LAN

Startup Manual

General

• LGA1151 6th and 7th Intel

Core™ i7/i5/i3/Pentium

Xeon

• BIOS: AMI 128 Mb SPI BIOS

• Chipset:

- PCE-7129: Intel® C236

- PCE-5129: Intel® Q170

- PCE-5029: Intel® H110

• System memory:

- PCE-7129: Supports dual channel DDR4 1866/2133

16GB per DIMM with ECC; Max. capacity is up to 32GB

- PCE-5129/5029: Supports dual channel DDR4

1866/2133 16GB per DIMM without ECC; Max. capacity

is up to 32GB

Note1: Please select Intel® ECC supported processor to

enable ECC function.

Note2: Supports DDR4 1024M x 8 memory technology.

• SATA Ports:

- PCE-7129/5129 supports 5 SATA3.0 ports with SW Raid

0,1,5,10.

- PCE-5029 supports 4 SATA3.0 ports without Raid

function.

• M.2 Ports: PCE-7129/5129 supports M.2 2280 type M

module and compatible to both SATA3.0 and PCI Express

3.0 standard.

• Serial ports: Two RS-232 with pin headers

Note: PCE-5029VG SKU feature 1*pin header and 1* rear

COM port.

• Keyboard/mouse connector: Supports one standard

PS/2 keyboard and mouse connector and one external

6-pin header.

• Watchdog timer: 255 level timer intervals

• USB 2.0: PCE-7129/5129/5029: 7 * USB 2.0 (Pin-

header*2+USB Type-A*1+, 4 on backplane)

• USB 3.0:

- PCE-7129/5129: 5 * USB 2.0 (Pin-header*4+Rear USB

3.0 * 1)

- PCE-5029: 3 * USB 2.0 (Pin-header*2+Rear USB 3.0

* 1)

• GPIO: One programmable 8-bit GPIO pin-header

VGA Interface

• Chipset: Intel

HD Graphics

• Shared system memory is subject to OS

Ethernet Interface

• Chipset supports:

- LAN 1: I219LM(PCE-7129/5129); I219V(PCE-5029)

- LAN 2: I210AT(PCE-7129); I210AT (PCE-5129/5029)

• Connection: 2 on-board RJ-45 connectors with LED indica-

tors

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://www.advantech.tw/support

This manual is for the PCE-7129/5129/5029 Series

Rev. A3.

Part No. 2001512912

Printed in China

3rd Edition

October 2022

2 PCE-7129/5129/5029 Startup Manual

Mechanical and Environmental

• Dimensions: (L x W): 338 x 122 mm

• Power supply voltage: +12 V, +5 V, +3.3 V, +5 V

• Power requirements:

- CPU: Processor: Intel

Core™ i7-6700

- Memory: 2 DDR4 2133 8 GB DIMMs

- Voltage: +12 V, +5 V, +3.3 V, +5 V

, 12 V,-5 V

- Current: 2.64 A, 1.23 A, 0.19 A, 0.09 A, 0.06 A, 0 A

- Operating temperature: 0 ~ 60 °C (depending on CPU)

• Weight: 0.5 kg (weight of board)

The board has a number of jumpers that allow you to con-

gure your system to suit your application. The table below

lists the function of each of the jumpers and connectors.

Connectors

Label Function

USB3_1 USB3 port1

LAN1

Intel® I219LM(PCE-7129/5129); Intel®

I219V(PCE-5029)

LAN2

Intel® I210AT(PCE-7129); Intel® I210AT

(PCE-5129/5029)

VGA1 VGA connector

KBMS1

External PS/2 keyboard and mouse

connector

KBMS2

Internal PS/2 keyboard and mouse

connector

HDAUD1

Advantech HD audio module expansion

pin-header

LPC1 LPC module expansion pin-header

Sysfan1

4 PIN fan power connector for support-

ing PWM or DC fan

LANLED1 LANLED

USB11 USB port 10

USB45 USB port 4, 5

USB3_45 USB3 port 4, 5

USB3_23 USB3 port 2,3

COM1 RS-232 (9-pin Box Header)

COM2 RS-232 (9-pin Box Header)

LPT1 Parallel port

SATA0 /

NGFF1

SATA port 0 or PCIex4

SATA 1~5 SATA Port 1 ~ 5

SPI_CN1 CMOS ash jig pin-header

SPI1 CMOS ROM

DP1 Display port pin-header 1

Jumpers and Connectors

DP2 Display port pin-header 1

JCMOS1 Clear CMOS

JME1 Clear ME

JFP1 + JFP2

Power Switch / Reset connector / Exter-

nal speaker / SATA HDD LED connector

JFP3

(Keyboard

Lock and

Power LED)

Power LED

Suspend: Fast ash (ATX/AT)

System On: ON (ATX/AT)

System O󰀨: OFF (ATX/AT)

CPUFAN1 CPU FAN Power connector

SYSFAN1

System FAN Power Connector for 1

system FAN

JCASE1 Case Open pin-header

JCASEOP_

SW1

Case Open switch for always open or

BAT1 Button battery socket

BAT2 External battery connector

GPIO1 GPIO pin header (SMD pitch-2.0 mm)

DIMMA1 Memory connector channel A

DIMMB1 Memory connector channel B

Jumpers

Label Function

JCMOS1 CMOS clear

JME1 Clear ME data

JWDT1 Watchdog timer output selection

JOBS1 SIO Monitor Alarm

JCMOS1/JME1: Clear CMOS/ME data

Closed Pins Result

1-2 Keep CMOS/ME data (Default)

2-3 Clear CMOS/ME data

123

Specications(Cont.)

JumpersandConnectors(Cont.)
