PCE-5B06-00A1E Startup Manual 1

PCE-5B06-00A1E Backplane: 6-slot BP for 6 slot Chassis, 1 PICMIG 1.3, 4 PCIe

PCE-5B06-00A1E Backplane: 6-slot BP for 6 slot

Chassis, 1 PICMIG 1.3, 4 PCIe

Startup Manual

Before you begin installing your card, please make sure

that the following materials have been shipped:

If any PCE-5B06-00A1E of these items are missing or

damaged, contact your distributor or sales representative

immediately.

Standard Functions

• PICMIG 1.3 slots:

PCE-5B06-00 supports PCE-5xxx CPU boards

• PCIe slots:

PCE-5B06-00 supports one PCIe x 16 slot, four PCIe x 1

slot

• USB (2.0) support: Four USB 2.0 port pin headers

Mechanical and Environment

• Dimensions: 317.5 x 142.17 mm

• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V

+5VSBY, +3.3VSBY

• Power requirements: Refer to the CPU Board, add-on

Card & Peripherals

• Operating temperature: 0 ~ 60° C

• Weight: 0.3 kg (weight of board)

Packing list Specifications

• 2 Two Port USB Cable p/n: 1700002204

• PCE-5B06-00A1E User Manual

1st.ED

p/n: 200K5B0610

• M4*6*0.7 Round Screws (15 pcs)

p/n: 1939000410

• 2 years quality warranty card p/n: 2190000902

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the PCE-5B06-00A1E series Rev. A1

Part No. 200K5B0610

Printed in China

1st Edition

Feb. 2007

2 PCE-5B06-00A1E Startup Manual

The backplane has a number of connectors and jumpers that

allow you to configure your system to suit your application. The

table below lists the function of each of the jumpers and con-

nectors:

Connectors and Jumpers

Connectors

Label Function

SHBA1~SHBD1 PICMG1.3 CPU board slot

PPCIE3 PCIe x 16 slot

PPCIE1,PPCIE2,

PPCIE4,PPCIE5

PCIe x 1 slot

EATXPWR1 ATX2.0 24-pin Power Connector

ATX12V1 ATX 12V 4-pin Power Connector

EATX12V1 ATX 12V Auxiliary 8-pin Power Connector

PWR3V1 3.3V Auxiliary 8-pin power connector

VOLT1 Alarm board / CMM Power Connector

FAN1 FAN Connector

FAN2 FAN Connector

FAN3 FAN Connector

FAN4 FAN Connector

FANDEC1 FAN speed detector Connector

SMBUS1 SMBus Connector for chassis monitor

SMBUS2 SMBus Connector for chassis monitor

KBMS1 External Keyboard/Mouse Connector

KBMS2 External Keyboard/Mouse Connector

JFP1 Power and Reset button Connector

IPMB1 IPMB Connector

USB12 Two USB port pin header

USB34 Two USB port pin header

Jumpers

Label Function

PSON1 ATX / AT Mode Selection

EATXPWER1

Pin Name

1 3.3 V

2 3.3 V

3 GND

4 5 V

5 GND

6 5 V

7 GND

8 Power OK

9 5 V SBY

10 12 V

11 12 V

12 3.3 V

13 3.3 V

14 -12 V

15 GND

16 PSON#

17 GND

18 GND

19 GND

20 -5 V

21 -5 V

22 5 V

23 5 V

24 GND

ATX12V1

Pin Name

1 GND

2 GND

3 12 V

4 12 V

EATX12V1

Pin Name

1 GND

2 GND

3 GND

4 GND

5 12 V

6 12 V

7 12 V

8 12 V

PWR3V1

Pin Name

1 3.3V

2 3.3V

3 3.3V

4 GND

5 GND

6 GND

VOLT1

Pin Name

1 5VSBY

2 GND

3 GND

4 -5V

5 5V

6 3.3V

7 -12V

8 12V

FAN1 - FAN4

Pin Name

1 GND

2 12V

3 FANIO1~FANIO4

FANDEC1

Pin Name

1 FANIO1

2 FANIO2

3 FANIO3

4 FANIO4

5 N/A

6 N/A

7 N/A

SMBUS1 ~ SMBUS2

Pin Name

1 5V

2 C-SMBBUS

3 C-SMBDAT

4 GND
