Side 1/7

PCE-5B13(7B14)-03 Startup Manual 1

Before you begin installing your card, please make sure

that the following materials have been shipped:

• One 2 port USB able P/N: 1700002204

• PCE-5B13(7B14)-03 startup manual

• M4*6*0.7 round screws (20 pieces) P/N: 1939000410

• 2-year quality warranty card P/N: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

PCE-5B13(7B14)-03 Backplane: 13(14)-slot BP for 14-Slot

Chassis, 1 x PICMIG 1.3, 9 (10) x PCIe, 3 x 32-bit/33-MHz

PCI

Standard functions

• PICMG 1.3 Slot:

PCE-5B13-03 supports PCE-5xxx CPU Cards

PCE-7B14-03 supports PCE-7xxx CPU Cards

• PCIe Slots:

PCE-5B13-03: 1 x PCIe x16, 8 x PCIe x4

PCE-7B14-03: 2 x PCIe x8, 3 x PCIe x4

• 32-bit PCI Slots:

PCE-5B13-03: 3 32-bit/33-MHz PCI

PCE-7B14-03: 3 32-bit/33-MHz PCI

• USB (2.0) Support: Four Universal Serial Bus ports to

Backplane

Note: Some add-on cards installed on this backplane

may cause CPU card BIOS resource allocation

problems, if this occurs please contact Advan-

tech technical support staff for help in solving the

problems.

Mechanical and Environment

• Dimensions: 327.66 x 315.45 mm

• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V

SBY, +3.3 V

• Power requirements: Depends on the CPU board, add-

on card & peripherals

• Operating temperature: 0 ~ 60° C

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the PCE-5B13-03A1E(PCE-7B14-

03A1E) series.

Part No. 20015B1300

Pr i n t e d i n C h i n a

1st Edition,

Jan. 2018

2 PCE-5B13(7B14)-03 Startup Manual

Connectors and Jumpers

This table shows the function of each jumper and connector:

Connectors

Label Function

SHBA1~SHBD1

PICMG1.3 CPU board slot

PPCIE2

PCIe x 16 slot (Only on PCE-

5B12-07)

PPCIE1, PPCIE2

PCIe p2-x8 slots (Only on PCE-

7B13-07)

P1PCIE1~P1PCIE3

PCIe p2-x4 slots

PPCI1~ PPCI3 32 Bit / 33 MHz PCI Bus slots

EATXPWR1

ATX2.0 24-pin Power Connector

EATX12V1

ATX 12V Auxiliary 8-pin Power

Connector

ATX12V1

ATX 12V 4-pin Power Connector

PWR3V1 3.3V Auxiliary Power Connector

PWR3V2

3.3V Auxiliary Power Connector

VOLT1

Alarm board / CMM Power Con-

nector

FAN1~5

FAN Connector (Horizontal Type)

FAN6~7 FAN Connector (Vertical Type)

FANDEC1

FAN speed detector Connector

(Optional)

SMBUS1~SMBUS2

System Management Bus

(Optional)

JFP1

Power and Reset button Con-

nector

IPMB1 IPMB Connector (Optional)

USB12

Two USB port pin header

USB34 Two USB port pin header

Note: In this backplane’s default conguration, FAN-

DEC1, SMBUS1~SMBUS3, IPMB1 pin-headers

are NOT populated, those footprints are reserved

for customization.

Jumpers

Label Function

PSON1

ATX / AT Mode Selection

EATXPWER1

Pin Name

3.3 V

2 3.3 V

GND

4 5 V

GND

5 V

GND

8 Power OK

5 V SBY

12 V

12 3.3 V

3.3 V

14 -12 V

GND

16 PSON#

GND

18 GND

GND

20 -5 V

-5 V

22 5 V

5 V

24 GND

ATX12V1

Pin Name

GND

2 GND

12 V

4 12 V

Connectors and Jumpers (Cont.)
