PCE-7B13-64C1E(PCE-5B12-64C1E) Startup Manual 1

PCE-7B13-64C1E(PCE-5B12-64C1E) PICMG

1.3 Backplane 13(12)-slot BP for 14 slots

Chassis, 2(1) PCIe, 6 64-bit PCI-X, 4 32-bit PCI

Startup Manual

Before you begin installing your card, please make

sure that the following materials have been shipped:

If any PCE-7B13-64C1E(PCE-5B12-64C1E) of these

items are missing or damaged, contact your distribu-

tor or sales representative immediately.

Standard Functions

•

PICMIG 1.3 slots:

PCE-7B13-64 supports PCE-7xxx CPU boards

PCE-5B12-64 supports PCE-7XXX/5XXX CPU boards

•

PCIe slots:

PCE-7B13-64 Supports two PCIe p1-x8 slot

PCE-5B12-64 Supports one PCIe p1-x16 slot

•

64-bit PCI-X slots:

Four 64 Bit / 66Mhz PCI-X slot

Two 64 Bit / 100Mhz PCI-X slot

•

32-bit PCI:

Four 32 Bit / 33 Mhz PCI slot

• USB

(2.0) support:

Four Universal Serial Bus ports to Back-

plane

Mechanical and Environment:

• Dimensions:

327.66 x 297.67 mm

• Power supply voltage: +12V, +5V, -12V, -5V, +3.3V,

+5VSBY

• Power requirements: Refer to the CPU Board , add-on

Card & Peripherals

• Operating temperature:

0 ~ 60°C

• Weight: 0.6kg (weight of board)

The backplane has a number of connectors and jumpers

that allow you to configure your system to suit your appli-

cation. The table below lists the function of each of the

connectors and jumpers.

Connectors

Jumpers

Packing list

• One 2 Ports USB Cable

p/n: 1700002204

• PCE-7B13-64C1E(PCE-5B12-

64C1E) Startup Manual

• M4*6*0.7 Round Screws [15 pcs.]

p/n: 1939000410

• 2 years quality warranty card

p/n: 2190000902

For more information on this and other Advantech prod-

ucts, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our support

website at:

http://www.advantech.com/support

This manual is for the PCE-7B13(5B12)-64B1E series

Rev. C1.

Part No. 20027B1303

Printed in China

4th Edition

Aug. 2014

Connectors and Jumpers

Part

Reference

Function

SHBA1~SHBD1PICMG 1.3 CPU board slot

PPCIE1 PCE-7B13-64: PCIe p1-x8 slot

PCE-5B12-64: Not Available

PPCIE2 PCE-7B13-64: PCIe p1-x8 slot

PCE-5B12-64: PCIe p1-x16 slot

P1PCIX1~

P1PCIX4

64 Bit / 66MHz PCI-X Bus Slot (Primary 1)

P2PCIX1,

P2PCIX2

64 Bit / 100MHz PCI-X Bus Slot (Primary 2)

PPCI1~PPCI4

32 Bit / 33MHz PCI Bus Slot (Primary 3)

EATXPWR1 ATX2.0 24-Pin Power connector

EATX12V1 ATX 12V Auxiliary 8-pin power connector

ATX12V1 ATX 12V 4-pin power connector

PWR3V1

3.3V Auxiliary power connector

PWR3V2

3.3V Auxiliary power connector

VOLT1 Alarm board/CMM Power

connector

FAN1 FAN Connector

FAN2 FAN Connector

FAN3 FAN Connector

FAN4 FAN Connector

FAN5 FAN Connector

FAN6 FAN Connector

FAN7 FAN Connector

FANDEC1 Fan speed detector connector

SMBUS1 SMBus connector for chassis monitor

SMBUS2 SMBus connector for chassis monitor

JFP1 Power and Reset Button connector

IPMB1 IPMB Connector

USB12 Two USB port pin header

USB34 Two USB port pin header

Part

Reference

Function

JP1VIO1 Primary 1 PCI-X Bus VIO voltage selection

JP2VIO1 Primary 2 PCI-X Bus VIO voltage selection

JM66ENA1 Primary 1 PCI(-X) Bus capability selection

JPCIXCAPA1 Primary 1 PCI Bus freq. selection

JM66ENB1 Primary 2 PCI Bus freq. selection

JPCIXCAPB1 Primary 2 PCI(-X) Bus capability selection

PSON1 ATX/AT mode selection

PCE-7B13-64C1E(PCE-5B12-64C1E) Backplane: 13(12)-slot BP for 14 slots

Chassis, 1 PICMIG 1.3, 2(1) PCIe, 6 64-bit PCI-X, 4 32-bit PCI

2 PCE-7B13-64C1E(PCE-5B12-64C1E) Startup Manual

Board Layout: Jumper and Connector Locations

Board Layout

P1PCIX1 P1PCIX3 P2PCIX1 PPCI1 PPCI3

P1P CIX 2 P1PCIX 4 P2PCI X2 PPC I2 PPCI 4

EATXPWR1

PWR 3V1

PWR 3V2

VOLT1

JP1VI O1

JP2VI O1

PPCIE1

PPCIE2

FAN7

SHB A1

SMB US2

USB 12

USB 34

FAN D EC 1

IPM B1

JFP 1 SMB US1 FAN2

FAN 1 P SO N 1

EATX12V1

ATX 12V1

FAN4

D182,D184,D183,D185

Fan3

, ,

FAN5 FAN6

JM66 ENB1

JPC IX C AP B1

JM66 ENA1

JSE L100A1

JPC IXC APA1

D146,D147,D148,D149
