Side 1/3
1 Startup Manual
STARTUP MANUAL
PCI-1714U/UL
Simultaneous 4-ch Analog Input Card
Before installation, please make sure that you have
received the following:
• PCI-1714U, PCI-1714UL DA&C card
• Driver CD
If anything is missing or damaged, contact your dis-
tributor or sales representative immediately.
For more detailed information on this product,
please refer to the PCI-1714U User Manual on the
CD-ROM (PDF format).
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residen-
tial area is likely to cause interference in which case the
user is required to correct interference at his own expense.
CE
This product has passed the CE test for environmental spec-
ifications when shielded cables are used for external wiring.
We recommend the use of shielded cables. This kind of
cable is available from Advantech. Please contact your local
supplier for ordering information.
The PCI-1714U and PCI-1714UL are simultaneous 4-chan-
nel analog input cards with high sampling rates. They are
advanced-performance data acquisition cards based on 32-
bit PCI bus architecture. The maximum sampling rate of
PCI-1714U is up to 30 MS/s, and 10 MS/s for PCI-1714UL.
Analog Input
PCI-1714U: 30 MHz is only for FIFO depth of 32K.
PCI-1714UL: 10 MHz is only for FIFO depth of 8K.
Packing List Specifications
User Manual
Declaration of Conformity
Overview
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com/support/
This startup manual is for PCI-1714U/1714UL.
Part No. 2003171411 2nd Edition
Feburary 2011
Channels 4 single-ended analog input channels
Resolution 12-bit
FIFO Size PCI-1714U: 32K
PCI-1714UL: 8K
Max. Sampling
Rate
30MHz For PCI-1714U
10MHz For PCI-1714UL
Input range and
Gain List
Gain 1 2 5 10
Range ±5V ±2.5V ±1V ±0.5V
Drift Gain 1 2 5 10
Zero (V / °C) ±200 ±100 ±40 ±20
Gain
(ppm / °C)
±30 ±30 ±30 ±30
Small Signal Band-
width for PGA
Gain 1 2 5 10
Bandwidth
(-3dB)
7MHz 7MHz 7MHz 7MHz
Max. Input Voltage ±15V
Input Surge Protec-
tion
30 Vp-p
Input
Impedance
50/1M/Hi Z jumper selectable /100pF
Trigger Mode Software, pacer, post-trigger, pre-trigger,
delay-trigger, about-trigger
Accuracy DC DNLE ±1LSB (No Missing
Codes:12 Bits
Guaranteed)
INLE ±2LSB
Offset
error
Adjustable to
±1LSB
Gain
error
Adjustable to
±1LSB
AC SINAD
S/ (N+D)
66 dB (Hi Z)
ENOB 10.67 bits (Hi Z)
THD -73 dB (Hi Z)
External Clock 1 Logic level TTL (Low: 0.8 V max. High:
2.0V min.)
Input
impedance
50 ohms
Input
Coupled
DC
Frequency Up to 10MHz
External Clock 0 Logic level 5.0V peak to peak sin wave
Input
impedance
Hi Z
Input cou-
pled
AC
Frequency Up to 10MHz
External Trigger 0
Logic level TTL (Low: 0.8 V max. High:
2.0V min.)
Input
impedance
Hi Z
Input
Coupled
DC
External Analog
Trigger Input
Range By analog input range
Resolution 8-bit
Frequency Up to 1MHz
