PCM-9365 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

1. 1 PCM-9365 SBC

2. 1 Startup Manual

3. 1 RS-232 COM3/4 cable p/n: 1701200220

4. 1 SATA power cable p/n: 1700018785

5. 1 RS-232 COM2 cable p/n: 1700019414

6. 2 USB Cable p/n: 1700018730

7. 1 SATA Cable p/n: 1700008941

8. 1 Audio cable p/n: 1700019584

9. 1 Heatsink p/n: 1960067897T001

10. mini jumper pack p/n: 9689000002

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note 1: For detailed contents of PCM-9365, please refer

to Advantech website for detailed information.

Note 2: Acrobat Reader is required to view any PDF

ﬁle. Acrobat Reader can be downloaded at:

http://get.adobe.com/reader/ (Acrobat is a trade-

mark of Adobe)

PCM-9365

Intel

Celeron

N2930 & Atom™ E3825, 3.5” SBC,

2GB/4GB On-board Memory, VGA, 48-bit LVDS, 2GbE,

Mini PCIe, PCI-104, SUSI 4

Startup Manual

General

• CPU: Intel

Celeron

N2930 Quad Core 1.83 GHz, burst

frequency 2.16GHz/ Atom™ E3825 Dual Core 1.33 GHz

• System Memory: 2GB/4GB DDR3L on-board memory,

N2930 with 1333MHz, E3825 with 1066MHz

• L2 Cache: 2 MB (N2930) / 1 MB (E3825)

• BIOS: AMI uEFI 64 Mbit

• Watchdog Timer: 255 levels timer interval, programmable

by software. Multi-level WDT (set by SUSI 4)

• Battery: Lithium 3 V/210 mAH

• Audio: High deﬁnition audio (HD), line-in, line-out, Mic-in

Expansion Interface

• 1 x Full-size Mini PCIe

• 1 x Full-size mSATA

• 1 x PCI-104

Display

• Controller: Intel

Gen 7 graphics and media encode/

decode engine

• Maximum Resolution:

- VGA: 2560 x 1600 @ 60 Hz

- HDMI (support by request):

* HDMI 1.4a with audio, 1920x1080

- LVDS/eDP:

* 48-bit LVDS up to WUXGA 1920 x 1200 at

60Hz, the 2nd LVDS is supported by request

- Dual Display: VGA + LVDS, HDMI+ LVDS, LVDS + LVDS

(HDMI and the 2nd LVDS are supported by request)

Ethernet Interface

• Speed: 10/100/1000 BASE-T

• Controller: Realtek RTL8111E-VL-CG

Mechanical and Environmental

• Dimensions: 146 x 102 mm (5.7” x 4”)

• Power Supply Type: ACPI support

• Power Requirement: +12 V ± 10%

• Power Consumption:

- Typical in Window 8:

PCM-9365E-2GS3A1E :0.39A @ 12V (4.68W)

PCM-9365EV-4GS3A1E : 0.44A @ 12V (5.28W)

PCM-9365N-4GS8A1E: 0.509A @ 12V (6.108W)

- Max in HCT:

PCM-9365E-2GS3A1E :0.49A @ 12V (5.88W)

PCM-9365EV-4GS3A1E : 0.554A @ 12V (6.648W)

PCM-9365N-4GS8A1E: 0.745A @ 12V (8.94W)

• Operating Temperature: 0 ~ 60 °C (32 ~ 140 °F)

• Weight: 0.54 kg (1.19 lb) (reference total weight)

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com

This manual is for the PCM-9365 Series Rev. A1

Part No. 2006936500

Printed in China

1st Edition

June 2015
