USB-5801 Startup Manual 1

Before installation, please ensure that the following items

are included with the product:

• 1 x USB-5801 module

• 4 x Terminal blocks

• 1 x USB 3.0 lockable cable (1 m)

• 1 x USB-5801 startup manual

If any of the above items are missing or damaged, contact

your distributor or sales representative immediately

User Manual

For more detailed information regarding this product, please

download the USB-5801 user manual from the Advantech

website.

USB-5801 is a highly accurate dynamic signal acquisition

USB 3.0 module speciﬁcally designed for vibration and

acoustic measurements. The module provides four simulta-

neously sampled 24-bit IEPE sensor inputs with an up to 192

kS/s sample rate for high-resolution measurements. USB-

5801 is also equipped with two 24-bit analog outputs with an

up to 192 kS/s update rate and two tachometer inputs whose

data can be correlated to the sensor data. The built-in USB

hub makes this module daisy chainable with other USB-5000

series products.

USB-5801

4-Ch, 24-Bit, 192 kS/s

Dynamic Signal Acquisition

USB

3.0 I/O Module with Analog Output and Tachometer

Startup Manual

FCC Class A

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part 15

of the FCC rules. These limits are designed to provide rea-

sonable protection against harmful interference when the

equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential

area is likely to cause interference. In such cases, users are

required to correct the interference at their own expense.

This product has passed the CE test for environmental speci-

ﬁcations when shielded cables are used for external wiring.

We recommend the use of shielded cables. This kind of cable

is available from Advantech. Please contact your local sup-

plier for ordering information.

Analog Input

• Channels: 4 (simultaneous sampling, 50 pseudo Ω

differential conﬁgurable)

• Resolution: 24 bits (delta-sigma ADC)

• Max. Sampling Rate: 1 ~ 192 kS/s

• Input Coupling: AC/DC, selectable per channel

• Trigger Mode: Start, delay start, stop, delay stop

• Input Range: ±1 V, ±2 V, ±5 V, ±10 V

• Offset Error: < ±0.2 mV

• Gain Error:< ±0.02% of full-scale range

• Total Harmonic Distortion Plus Noise (THD+N): -95 dB

• IEPE Excitation: 2 mA

• Automatic Calibration: Yes

Analog Output

• Channels: 2 (50 pseudo differential)Ω

• Resolution: 24 bits (delta-sigma DAC)

• Update Rate: 1 ~ 192 kS/s

• Output Coupling: DC

• Output Range: ±1 V, ±10 V

• Offset Error: < ±0.5 mV

• Gain Error: < ±0.03% of full-scale range

Declaration of Conformity Packing List

For more information about this or other Advantech

products, visit our website at

http://www.advantech.com

For technical support and customer service, visit our

support website at

http://support.advantech.com

This manual is for USB-5801.

Part No. 2041580101

Printed in China

Edition 2

May 2019

Specications

Overview

2 USB-5801 Startup Manual

• Total Harmonic Distortion Plus Noise (THD+N): -91 dB

• Trigger Mode: Start, delay start, stop, delay stop

• Automatic Calibration: Yes

Tachometer Input

• Channels: 2

• Input Voltage: Logic 0: 3 V max.

Logic 1: 10 V min. (30 V max.)

• Input Frequency: 5 kHz max.

• Digital Filter: 16 μs ~ 131 ms

• Isolation Protection: 2,500 V

Digital Input

• Channels: 4

• Input Voltage: Logic 0: 3 V max.

Logic 1: 10 V min. (30 V max.)

• Opto-Isolator Response Time: 100 μs

• Digital Filter: 16 μs ~ 131 ms

• Isolation Protection: 2,500 V

Digital Output

• Channels: 4

• Load Voltage: 5 ~ 40 V

• Load Current: 350 mA/ch (sink)

• Opto-Isolator Response Time: 100 μs

• Isolation Protection: 2,500 V

General

• Interface: USB 3.0

• Data Transfer Rate: 5 Gbps

• Connectors:

6 x BNC (AI and AO)

2 x 10-pin, 3.81-mm terminal blocks (tachometer, trigger,

and DI/O)

2 x 3-pin, 3.81-mm terminal blocks (power)

1 x USB 3.0 type A (downstream port)

1 x USB 3.0 type B (upstream port)

• Dimensions:

168 x 120 x 40 mm (6.6 x 4.7 x 1.6 in)

• Operating Temperature: 0 ~ 60 °C (32 ~ 140 °F)

• Storage Temperature: -40 ~ 70 °C (-40 ~ 158 °F)

• Storage Humidity: 5 ~ 95% RH (non-condensing)

• Power Supply: External 10 ~ 30 V

or USB bus power

• Power Consumption:

150 mA typ./200 mA max. @24 V external power

700 mA typ./860 mA max. @5 V bus power

Specications (Cont.)

We recommend installing the driver before installing the

USB-5801 module to guarantee problem-free installation.

The Advantech DAQNavi Device Drivers setup program

for the USB-5801 module can be downloaded from the

Advantech website (www.advantech.com). Follow the steps

outlined below to install the driver software.

1. Execute the USB-5801 driver package.

2. The driver installation program should be launched.

When the setup program is launched, a setup screen

will be displayed.

3. Click the “Next” button and wait for driver installation.

4. Click the “Finish” button to exit the setup program.

After the device drivers are installed, the USB-5801 module

can be installed in the computer. We recommend referring

to the user manual or related documentation for detailed in-

structions. Alternatively, follow the steps outlined below for

module installation.

1. Touch any metal surface of the computer to discharge

any static electricity that may be in your body.

2. Insert the USB module into the designated USB port.

Use caution when inserting the module to avoid damage

due to excessive force.

After the module is installed, the device can be conﬁgured

using the Advantech Navigator Program automatically in-

stalled during driver setup. Complete device installation pro-

cedures should include device setup, conﬁguration, and test-

ing. Information is provided in the following sections to guide

users through the device setup, conﬁguration, and testing.

Hardware Installation

Driver Installation
