USER MANUAL

ECO406 • ECO407

EC • TDS Monitors

ISTECO406 09/14

WARRANTY

This instrument is warranted from all defects in materials and

manufacturing for a period of 2 years from the date of purchase.

Probes are warranted for a period of 6 months.

If during this period, the repair or replacement of parts is required,

where the damage is not due to negligence or erroneous operation by

the user, please return the parts to either dealer or our office and the

repair will be effected free of charge.

Note: We reserve the right to modify the design, construction and

appearance of our products without advance notice.

SPECIFICATIONS ECO406 ECO407

Range 0 to 9.99 mS/cm 0 to 1990 ppm

Resolution 0.01 mS/cm 10 ppm

Accuracy (@25 °C) ±2% f.s. ±2% f.s.

TDS factor — approx. 0.7

Probe AD7632 AD7634

Calibration Manual, single point, through trimmer

Temp. Compensation Automatic

Environment 0 to 50 ºC, 95% RH max

Power supply External, 12 Vdc

Dimensions 120 x 134 x 54 mm

Weight approx. 300 g

ACCESSORIES

AD7632 EC probe for ECO406 with 2 m cable

AD7634 TDS probe for ECO407 with 2 m cable

AD70031P 1413 µS/cm EC standard solution, 20 ml sachet (25 pcs.)

AD70442P 1500 ppm TDS standard solution, 20 ml sachet (25 pcs.)

AD70000P Rinse solution, 20 ml sachet (25 pcs.)

GENERAL OPERATIONS

• Each unit is supplied complete with probe and 12 Vdc adapter.

• Connect the 12 Vdc adapter to the power supply connector

and to the mains.

• Make sure the unit has been calibrated before using it.

• For taking measurements immerse the tip (4 cm) of the

probe into the solution to be measured, then shake briefly.

Note: For accurate measurements it is recommended that the

probe does not touch nor stand close to the side walls of

the vessel.

• The display will show the EC (ECO406) or TDS (ECO407)

value, in mS/cm or ppm unit respectively. Wait a few seconds

for the reading to stabilize and the meter will start continuous

monitoring.

• To turn the unit off simply unplug the 12 Vdc adapter from the

mains.

CALIBRATION PROCEDURE

For better accuracy, frequent calibration of the instrument is

recommended.

Anyway the meter should be calibrated at least once a month

and after performing probe cleaning procedure.

• Choose the proper calibration solution (see

below) and, if possible, use plastic beakers to

minimize any EMC interference.

• Use solution AD70031 (1413 µS/cm) for

ECO406 and AD70442 (1500 ppm) for ECO407.

• Immerse the probe in the calibration solution,

making sure that the metal pins are completely

submerged.

• Using a small screwdriver adjust the CAL

trimmer to read "1.41" mS/cm for ECO406 or

"1500" ppm for ECO407.

• The calibration is now complete and the instrument is ready

for use.

CALIBRATION 

SOLUTION

PROBE MAINTENANCE

To minimize clogging and provide longer life to the probe, it is

recommended to clean it often, or at least once a month.

• Immerse the tip of the probe in rinse solution for one hour or

clean it with detergents used to wash irrigation pipelines and

fertilizer vessels.

• If a more thorough cleaning is required, brush the metal pins

with very fine sandpaper.

• After cleaning and before storing the probe, rinse it with tap

water.
