Side 1/24

Quick Start Installation Guide

This is an abbreviated Installation and Programming manual for the GT Series. The complete GT Series

Installation Manual is supplied with the GT-BC Bus Control Unit. Additional manuals are available online,

including The GT Standard & Expanded Setting Manual and GT Multi Building Installation and Setting Manuals.

The GT Setup Tool for programming tenant names and numbers and other settings can be downloaded from

www.aiphone.net.

ATTENTION:

GT SERIES

Multi-Tenant Entry Security

The illustrations used in this manual may di󰀨er from the actual product.

2 | GT Series Quick Start Guide

Table of Contents

System Wiring

Standard system wiring: audio only..................................................................................................................................3

Standard system wiring: audio/video................................................................................................................................4

Expanded system wiring...................................................................................................................................................5

Option connector wiring: tenant stations...........................................................................................................................5

Settings

Dip switch settings: entrance and guard station ID settings.............................................................................................6

Dip switch settings: entrance station.................................................................................................................................6

Programming

Entering tenant information..............................................................................................................................................7

Addressing tenants via dip switch method.........................................................................................................................8

Entering guard station and entrance station information...................................................................................................9

Transfer data to other guard/entrance stations................................................................................................................10

Uploading to stations via USB........................................................................................................................................11

GT Setup Tool for Android

Download from Google Play...........................................................................................................................................11

Downloading settings................................................................................................................................................11-12

Editing settings...............................................................................................................................................................12

Uploading settings..........................................................................................................................................................13

Programming: addressing tenants via handshake method.......................................................................................14-15

GT-MCX Network Adaptor

Multi-Building System Wiring with GT-MCX....................................................................................................................16

GT-MCX: network adaptor..............................................................................................................................................17

Dip switch settings: tenant section and main section......................................................................................................17

System Programming with Multiple GT-MCX: multi-building......................................................................................18-19

Programming: addressing tenants via dip switch method...............................................................................................19

Programming: entering resident info..............................................................................................................................20

Programming: entering entrance station and guard station information.........................................................................21

Programming: transfer data to entrance stations and guard stations.............................................................................22

Programming: uploading to GT-MCX via LAN................................................................................................................23

Programming: sharing handshake data..........................................................................................................................24

Produkt Specifikationer

Mærke:	Aiphone
Kategori:	Ikke kategoriseret
Model:	GT-202HB
Vægt:	- g
Antal pr. pakke:	1 stk
Produktfarve:	Beige
Produkttype:	Overflademonteringsboks
Mærke kompatibilitet:	Aiphone
