Akyga AK-B1-700 Manual

Akyga Oplader til mobilenhed AK-B1-700

Læs gratis den danske manual til Akyga AK-B1-700 (3 sider) i kategorien Oplader til mobilenhed. Denne vejledning er vurderet som hjælpsom af 12 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 6.5 anmeldelser. Har du et spørgsmål om Akyga AK-B1-700, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/3

Basic Series - user manual

www.akyga.com

Short description of the product

The product is compatible with the applicable national and European requirements.

S explanation:ymbols

There is a risk of losing health or life (e.g. by electic shock).

There is a particular danger connected with service.

Important tips and information.

Product accordance with the EU directive 2002/96/EC. The symbol of the crossed out basket

placed on the product means that the marked product can not be disposed of with other

household waste. After use, the product must be return to collection point for used electical and

electronic equipment or to the seller. Appropriate segregation of rubbish for subsequent

processing, recovery or descrution contributes to avoiding negative effects on the environment

and health, and also allows the recovery of raw materials from which the product is made.

p. 1

The CE standard description on the product is the manufacturer's declaration that the marked

product meets the requirements of the directive so-called The "New Approach" of the European

Union (EU). For security and certification (CE) reasons, the device can not be rebuild or change

in any way. In the reason of using the power supply for other purposes than those described,

the product may be demaged. The incorrect use may also cause hazard such as short-circuits,

burns, electric shocks, etc. Read the users manual carefully and keep it for later use. The product

could be share to third partie only with the user manual included.

The BASIC series is a dedicated line of power supplies for the configuration of standard desktop

computers whose current requirements are adequate to the parameters given on the nameplate.

The product is adapted to supply voltage in the range of 230 V.

The power consumption of powering components can not exceed the power supply nominal current.

ATX power supplies

The RoHS mark on the product is the manufacturer's declaration that the marked product meets

the requirements of the EU Restriction of Hazardous Substances (2002/95/EC) directive, which

aims to reduce the amount of hazardous substances penetrating into the environment from

electrical and electronic waste.

BOX

EN 61000-3-12

PFC

The II protection class device. It provides protection against electric shock against direct and

indirect contact, and thanks to the additional isolation it is not necessary to connect the device

case with the protective earth conductor.

The device is intended only for domestic use, indoors.

ATX power supplies - user manual

p. 2

Safety Precautions

The assembly should be carried out by persons with appropriate technical knowledge of PC

construction.

Connecting components whose demanded power is greather than power of the power supply, can

cause battery failure or even damage (burn) of power supply.

An electrostatic discharge occurs when two object touch each other, for example, an electric

charge that occurs when user touch metal door handle after walking on a carpet . Discharging

electrostatic charges from fingers or other electrostatic conductors can damage electronic

components. To avoid damaging the computer, abstain from touching electrical outlets, wires and

electonic circuits. The user’s contact with electronic components should be kept to a minimum.

The manufacturer of the product is not responsible for damage or insults caused in effect

of disobey the safety instructions and informations contained in these user manual.

źKeep the product and the packaging out of range of children and animals. The package

includes a foil that child could choke while playing.

źIt is forbidden to apply the mechanical load to the product - strong shocks, impacts, dropping or

crushing may cause its damage.

źThe product operation in adverse conditions is not allowed. Adverse conditions are primarily:

exposure to direct sunlight, high or very low ambient temperatures, strong vibrations, high

humidity, surrounds of gases, dusts or flammable and aggressive liquids.

źIf the product has been damaged, does not work properly or has been stored for a long period

of time in bad or unfavorable conditions, safe operation of the device is not possible. It is

essential to stop using the product and to protect it against re-use for security purposes.

źProduct and power cord should not be touched with moist or wet hands under no

circumstances.

źShort-circuiting the current connection is prohibited.

źMake sure that the power cord is not crushed, bent, twisted, rubbed against sharp edges or

mechanically loaded in any other way. Avoid thermal load of the cable - in particular keep away

from heat sources (such as stoves, radiators, fireplaces).

źPower cords should be laid in such a way as to eliminate the risk of stumbling or hooking over.

źIts forbidden to modify the power cord. In the case of modifications, the cable may be

damaged, causing threats to life, health and property.

źBefore connecting the adapter to the mains socket, make sure that the voltage specified on the

power supply matches voltage supplied to the household socket.

źMains plug should be disconnect from power socket if the product is not in use for a long time.

źWhen disconnecting the power cord from the socket and from the device, do not pull on the

cord, but only on the part of the cable plug provided for this purpose.

źIn case of any doubts regarding operation, safety or connection of the product, please contact

the manufacturer or a qualified specialist for this purpose.

źAll maintenance, adjustment and repair work on the product may only be carried out by a

qualified person in a specialist facility.

Basic Series

Produkt Specifikationer

Mærke:	Akyga
Kategori:	Oplader til mobilenhed
Model:	AK-B1-700
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	220 - 230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	150 mm
Dybde:	160 mm
Højde:	85 mm
Vægt:	1260 g
Produktfarve:	Grå
Pakkevægt:	1330 g
Pakkedybde:	260 mm
Pakkebredde:	180 mm
Pakkehøjde:	95 mm
Driftstemperatur (T-T):	5 - 50 °C
Pakketype:	Kasse
Støjniveau:	- dB
Certificering:	CE, FCC, RoHS, REACH
Bæredygtighedscertifikater:	RoHS
Formål:	PC
Gennemsnitstid mellem fejl (MTBF):	100000 t
Total effekt:	700 W
Antal blæsere:	1 blæser(e)
Strømbeskyttelsesfunktioner:	Over current, Over power, Over voltage, Overheating, Short circuit
Effektivitet:	70 %
Strømkorrektionsfaktor (PFC):	Passiv
Kombineret effekt (+3,3 V):	300 W
Kombineret effekt (+12 V):	384 W
Kombineret effekt (+5 V):	300 W
Maks. udgangsstrøm (+3,3 V):	35 A
Maks. udgangsstrøm (+12 V):	32 A
Maks. udgangsstrøm (+5 V):	38 A
Maks. udgangsstrøm (-12V):	0.5 A
Maks. udgangsstrøm (+5 VSB):	2.5 A
Strømforsyningenhed (PSU) formfaktor:	ATX
ATX-version:	2.31
Ventilator diameter:	120 mm
Kølingstype:	Aktiv
Motherboard, strømstik:	20+4 pin ATX
Antal SATA strømstik:	5
Perifere (Molex) strømstik (4-pin):	2
PCI ekspres strømforbindelser (6+2 pin):	2
Kabeltype:	Ikke modulær
Kombineret effekt (-12V):	18.5 W
Kombineret effekt (+5 VSB):	18.5 W
Blæser placering:	Side
Længde på strømkabel på bundkort:	450 mm
Strømkabellængde SATA:	150,300 mm
Strømkabellængde Perifere (Molex):	150,300 mm
Strømkabellængde PCI Express:	450 mm
EPS-strømstik (4 + 4-benet):	Ja
EPS-kabellængde:	600 mm
