Side 1/2

user manual

Symbols explanation:

Product accordance with the EU directive 2002/96/EC. The symbol of the crossed out basket

placed on the product means that the marked product can not be disposed of with other

household waste. After use, the product must be return to collection point for used electical and

electronic equipment or to the seller. Appropriate segregation of rubbish for subsequent

processing, recovery or descrution contributes to avoiding negative effects on the environment

and health, and also allows the recovery of raw materials from which the product is made.

The CE standard description on the product is the manufacturer's declaration that the marked

product meets the requirements of the directive so-called The "New Approach" of the European

Union (EU). For security and certification (CE) reasons, the device can not be rebuild or change

in any way. In the reason of using the power supply for other purposes than those described,

the product may be demaged. The incorrect use may also cause hazard such as short-circuits,

burns, electric shocks, etc. Read the users manual carefully and keep it for later use. The product

could be share to third partie only with the user manual included.

BOX

Ecological Solutions

GREEN

ATX power supplies

The RoHS mark on the product is the manufacturer's declaration that the marked product meets

the requirements of the EU Restriction of Hazardous Substances (2002/95/EC) directive, which

aims to reduce the amount of hazardous substances penetrating into the environment from

electrical and electronic waste.

www.akyga.com

In case of replacement of an old unit:

źDisconnect all power plugs from the computer

źRemove the computer housing

źDisconnect all power connectors of the old PSU

źUnscrew 4 screws holding the old PSU on the back of the computer

Installation of new Power Supply:

źScrew new power supply to the case using 4 screws

źConnect power connectors of a new PSU to suitable devices inside of the computer

źPlease remember that power connectors are intended for assembly in one particular way,

if there are problems with connection of plug and connector then reverse it and try again.

źMake sure that there are no loose screws left inside the computer

źPut on and tighten the computer case

źConnect the power cord plug to an electrical outlet

Power Supply Instalation guide

Safety Precautions

WARNING! Product heats up during operation. To reduce the risk of burns or overheating the power

supply, do not place it in restricted ventilation area. Also, do not allow the working power supply to touch

soft surface such as pillows, blankets or clothing. The power supplies meets the limits on the surface

temperatures available to the user, as defined in the International Standard for Safety of Information

Technology Equipment (IEC 60950).

page 1

page 2

Connecting PC whose demanded power is greather than power of the power supply, can cause battery

failure or even damage (burn) of power supply.

An electrostatic discharge occurs when two object touch each other, for example, an electric

charge that occurs when user touch metal door handle after walking on a carpet . Discharging

electrostatic charges from fingers or other electrostatic conductors can dameage electronic

components. To avaid damaging the computer, avoid touching electrical outlets, wires and

electonic circuits. The user’s contact with electronic components should be kept to a minimum.

The manufacturer of the product is not responsible for damage or insults caused in effect

of disobey the safety instructions and informations contained in these user manual.

źKeep the product and the packaging out of range of children and animals. The package

includes a foil that child could choke while playing.

źIt is forbidden to apply the mechanical load to the product - strong shocks, impacts, dropping or

crushing may cause its damage.

źThe product operation in adverse conditions is not allowed. Adverse conditions are primarily:

exposure to direct sunlight, high or very low ambient temperatures, strong vibrations, high

humidity, surrounds of gases, dusts or flammable and aggressive liquids.

źIf the product has been damaged, does not work properly or has been stored for a long period

of time in bad or unfavorable conditions, safe operation of the device is not possible. It is

essential to stop using the product and to protect it against re-use for security purposes.

źProduct and power cord should not be touched with moist or wet hands under no

circumstances.

źShort-circuiting the current connection is prohibited.

źMake sure that the power cord is not crushed, bent, twisted, rubbed against sharp edges or

mechanically loaded in any other way. Avoid thermal load of the cable - in particular keep away

from heat sources (such as stoves, radiators, fireplaces).

źPower cords should be laid in such a way as to eliminate the risk of stumbling or hooking over.

źIts forbidden to modify the power cord. In the case of modifications, the cable may be

damaged, causing threats to life, health and property.

źBefore connecting the adapter to the socket (the cable is not included with the AK-B1-XXX

power supply) make sure that the voltage specified on the mains adapter matches the voltage

supplied to the household socket.

źDisconnect the mains plug from the socket if you do not use the product for a long time.

źWhen disconnecting the power cord from the socket and from the device, do not pull on the

cord, but only on the part of the cable plug provided for this purpose.

źIn case of any doubts regarding operation, safety or connection of the product, please contact

the Manufacturer or a qualified specialist for this purpose.

źAll maintenance, adjustment and repair work on the product may only be carried out by a

qualified person in a specialist facility.

user manual

ATX power supplies

Product manufacturer:

Ropla Computers sp. z o.o.

ul. Wrocławska 1c

52-200 Suchy Dwór

Produkt Specifikationer

Mærke:	Akyga
Kategori:	Oplader til mobilenhed
Model:	AK-I1-200
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	81.5 mm
Dybde:	150 mm
Højde:	40 mm
Vægt:	580 g
Brugervejledning:	Ja
Produktfarve:	Grå
Pakkevægt:	587 g
Pakkedybde:	211 mm
Pakkebredde:	101 mm
Pakkehøjde:	41 mm
Formfaktor:	Terning
Driftstemperatur (T-T):	5 - 50 °C
Kabler inkluderet:	Vekselstrøm
Støjniveau:	- dB
Certificering:	OVP, OCP, OPP, OTP, SCP, REACH, RoHS, CE
Formål:	PC
Gennemsnitstid mellem fejl (MTBF):	100000 t
Total effekt:	200 W
Antal blæsere:	1 blæser(e)
Effektivitet:	70 %
Strømkorrektionsfaktor (PFC):	Aktiv
Kombineret effekt (+3,3 V):	76 W
Kombineret effekt (+12 V):	120 W
Kombineret effekt (+5 V):	76 W
Maks. udgangsstrøm (+3,3 V):	8 A
Maks. udgangsstrøm (+12 V):	10 A
Maks. udgangsstrøm (+5 V):	8 A
Maks. udgangsstrøm (-12V):	10 A
Maks. udgangsstrøm (+5 VSB):	8 A
Strømforsyningenhed (PSU) formfaktor:	ATX
80 PLUS certificering:	80 PLUS
Ventilator diameter:	40 mm
Kølingstype:	Aktiv
Motherboard, strømstik:	24-pin ATX
Antal SATA strømstik:	1
Perifere (Molex) strømstik (4-pin):	1
CPU P4 strømstik (4-pin):	1
Kabeltype:	Ikke modulær
Kombineret effekt (-12V):	120 W
Kombineret effekt (+5 VSB):	76 W
