Alfatron ALF-SCK51TS-D Manual
Læs gratis den danske manual til Alfatron ALF-SCK51TS-D (26 sider) i kategorien Skifte. Denne vejledning er vurderet som hjælpsom af 35 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 18 anmeldelser. Har du et spørgsmål om Alfatron ALF-SCK51TS-D, eller vil du spørge andre brugere om produktet?
Side 1/26
www.alfatronelectronics.com
ALFATRON ELECTRONICS GmbH
GERMANY
ALF-S -D CK51TS
ALF- -D SCK51TS
Thank this you for purchasing product
For optimum performance and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical
spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is
highly recommended in order to protect and extend the life of your equipment.
Caution
The product requires the use of UTP connectors. Please connect in direct interconnection
method and do not cross connect.
White and Orange
Orange
White and Green
Blue
White and Blue
Green
White and Brown
Brown
Direct Interconnection Method
Table of Contents
1. Introduction ........................................................................................................................... 1
2. Features ................................................................................................................................. 1
3. Specifications ........................................................................................................................ 2
4. Operation Controls and Functions ...................................................................................... 4
4.1 Switch Panel .................................................................................................................... 4
4.2 HDBaseT Receiver Panel ............................................................................................... 6
4.3 IR Pin Cable Assignment ................................................................................................ 9
5. IR Remote .............................................................................................................................. 9
6. User Web GUI Guide ........................................................................................................... 10
7. Dante Web GUI User Guide ................................................................................................ 20
8. 232 RS- Control Command.................................................................................................. 23
9. Connection Diagram ........................................................................................................... 24
