Side 1/4
Document 90-000 B 84 Algo Communication Products Ltd (604) 454-3792
2017-09-08 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com
8189 SIP Surface Mount Speaker
GETTING STARTED SHEET
Full Configuration Guide Available
Online From
www.algosolutions.com/8 /guide188
Need Help?
(604) 454-3792 or support@algosolutions.com
Document 90-000 B 84 Algo Communication Products Ltd (604) 454-3792
2017-09-08 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com
About the Algo SIP 8189 SIP Surface Mount Speaker
The Surface Mount Speaker is a SIP compliant and multicast capable IP speaker suitable for 8189
voice paging, notification, and background music.
The 6.5” (165mm) coaxial speaker is G.722 wideband capable and music capable using a fullband
codec. An integrated microphone provides talkback capability and ambient noise detection for
automatic level control.
Dual SIP extensions provide both voice paging and notification (ring) capability. One or both
extensions can be registered with any Communication Server (hosted or enterprise) that supports
3rd party SIP Endpoints.
Multiple speakers in a SIP environment require only one speaker to register as a SIP extension.
Multicasting capabilities allow the SIP registered speaker to page and simultaneously stream
multicast audio to the other speakers.
The is configured using central provisioning features or by accessing a web interface using 8189
browsers such as Google Chrome, Firefox, or Internet Explorer.
What Included is
8189 SIP Surface Mount Speaker
White trim ring and speaker grill
Tool for grill removal and reset
Pluggable terminal block for relay input and output
Getting Started Sheet
What is not Included
Optional 1202 Call Button or 1203 Wall Switch
Screws for mounting the back box to ceiling
The full User Guide ( ) 8188 www.algosolutions.com/8188/guide
Getting Started - Quick Install & Test
This guide provides important safety information which should be read thoroughly before
permanently installing the adapter.
1. Connect the 8189 SIP Surface Mount Speaker to an IEEE 802.3af compliant PoE network switch.
The blue light will remain on until boot up is completed about 30 seconds. –
2. After the blue light turns off, press the reset switch (RST) that is hidden behind the speaker grill, to
hear the IP address over the speaker. The IP address may also be discovered by downloading the
Algo locator tool to find Algo devices on your network: www.algosolutions.com/locator
3. Mount the speaker per the instructions in this guide.
Note: The 8189 SIP Surface Mount Speaker harbours the same feature set as the 8188
SIP Ceiling Speaker. Therefore, the 8188 User Guide may be used for configuring the 8189.
For 8189 installation details, please follow the steps outlined in this document.
