User Guide

Firmware V1.2 Issue 4


 2

User Guide V1.2 Issue 4

1. Important Information .................................................................................. 7
2. Introduction ................................................................................................... 8
The different models .............................................................................................. 8
Images and examples in this guide ................................................................ 10
3. Updating Firmware ...................................................................................... 11
Update firmware using the CQ-MixPad app ................................................ 11
Update firmware using a USB drive ................................................................12
4. Connections .................................................................................................. 13
Power ........................................................................................................................... 13
Mic/Line Inputs ....................................................................................................... 13
Outputs ....................................................................................................................... 14
Footswitch ................................................................................................................ 15
USB and SD Card ................................................................................................... 15
Network Port ............................................................................................................ 15
Built-In WiFi Access Point (CQ-18T, CQ-20B) ............................................ 16
Bluetooth .................................................................................................................... 17
MIDI ............................................................................................................................... 17
5. Connecting control apps ......................................................................... 18
First connection to a CQ-20B ........................................................................... 18
Switching the Enabled Network on a CQ-20B ........................................... 19
Connect using WiFi Access Point (CQ-18T, CQ-20B).............................. 19
Connect using an external router or network ........................................... 20
Connect a computer directly with a network cable ............................... 20
6. Operation and Workflow ........................................................................... 21
Powering on ...............................................................................................................21

Produkt Specifikationer

Mærke:	Allen & Heath
Kategori:	Blander
Model:	CQ-18T
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50/60 Hz
Bredde:	346 mm
Dybde:	242 mm
Højde:	89 mm
Vægt:	3000 g
Brugervejledning:	Ja
Indbygget skærm:	Ja
Pakkevægt:	3800 g
Pakkedybde:	310 mm
Pakkebredde:	430 mm
Pakkehøjde:	200 mm
Berøringsskærm:	Ja
Kompatible hukommelseskort:	SD, SDHC
USB-port:	Ja
Strømforbrug (typisk):	35 W
Frekvensområde:	20 - 20000 Hz
Indbygget kortlæser:	Ja
Mikrofonindgang:	Ja
USB-stik type:	USB Type-A, USB Type-B
Antal kanaler:	18 kanaler
XLR indgang:	Ja
Output impedans:	75 ohm (Ω)
Indgangsimpedans:	10 ohm (Ω)
Fantomstrøm:	48 V
Digital lydbehandling:	- Bit
Line-in maksimal indgang:	21 dBV
Antal mikrofon-indgange:	18
Understøttede stikprøver:	96 kHz
Master (XLR) udgang:	2
