Introduction Physical Layout

Making the Connection

Features

Package Contents

The Ultra series USB-C Dock UNI is the next generation USB-C peripheral designed to

work with the latest USB-C and Thunderbolt 3 enabled computers. Featuring ALOGIC’s

latest advancement in USB-C technology, this next generation dock UNI is one of the most

advanced products in its class across the industry.

1. Connect the integrated USB-C connector of the dock to the available USB-C port on

your computer.

2. Once connected the LED on the dock will glow white to indicate the device is ready to

use

3. A message on your computer taskbar may notify you as well that the device is ready for

use.

4. Once the installation is completed, you can plug your accessories to the docking station

as per required.

USB-C Connector x 1

SD Card Slot

Micro SD Card Slot

USB-C Port (Data +

Power Delivery)

USB 3.0 Ports x 2

HDMI Port

• Compact and light weight design

• Aluminium & ABS construction for the most elegant look

• Full array of ports – HDMI 4K@30Hz, USB-C (Data & PD 100W), USB-A & Micro/SD Card

Readers

• Supports charging your Macbook with up to 100W power when connected with a suitable

charger

• USB-C port also supports data transfer when connected to a suitable accessory

• Supports monitor resolution with up to 4K@30Hz via the HDMI port

• Two port USB-A hub for connecting keyboard, mice, printer or another existing USB-A

peripheral

• Supports both Micro & SD memory cards

• Warranty – 1 Year

• USB-C Dock UNI x 1

• User Manual x 1

2 3

Note

• Do not deliberately damage this product and put it in damp, direct sunlight or high

temperature environment.

• If improper use, demolition or operation not according to the instructions result in any

damage of your device or product, our company will not be liable for any compensation

or maintenance responsibility.

Speciﬁcations

Model ULDUNI-SGR, ULDUNI-SLV

Input USB-C x 1

Output

HDMI 4K@30 Hz x 1, USB-A (USB 3.1 Gen1) x 2, USB-C (Power Delivery

& Data) x 1 (Up to 100W & USB 3.1 Gen 1 Speed), Micro SD Card

Reader x 1, SD Card Reader x 1

Resolution 4K@30 Hz

System Requirement

USB-C Ports with DP alt Mode, Windows 10 & above and Mac OS

& above

Produkt Specifikationer

Mærke:	Alogic
Kategori:	Vugge & Dockingstation
Model:	ULDUNI-SGR
Bredde:	119.5 mm
Dybde:	49.2 mm
Højde:	12 mm
Vægt:	75 g
Produktfarve:	Grå
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Harmoniseret systemkode (HS):	84733020
Værtsgrænseflade:	USB Type-C
Intern:	Ingen
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte:	1
Output-grænseflade:	HDMI, USB 3.2 Gen 1 (3.1 Gen 1)
