Flood and Temp Sensor is an integrated environmental

sensor. It detects ood conditions and reports extreme

temperatures.

Features

• Titanium probes for unmatched corrosion immunity

• IP67 rated waterproof enclosure

• GORE

vent to prevent seal failure

• 5 year warranty

Enroll by placing the panel into wireless enrollment mode and

removing the battery tabs, tampering the sensor, or manually

entering the sensor ID.

Loop Conguration

• Loop 1 = Freeze

• Loop 2 = Heat

• Loop 3 = Flood

Install by placing the sensor in the location requiring ood or

temperature detection. If desired, the wall clip can be used to

secure the sensor.

Optional Screw Mounting

• Remove the wall clip from the sensor’s body.

• Secure the clip to a wall, baseboard or cupboard

using a #6 screw.

• Slide the sensor’s body down onto the wall clip

until it snaps into place.

Detects water pooled under the sensor and reports extreme

temperature conditions.

Temperature Trip Points

• Heat alarms when over 100°F (38°C)

• Heat restores when under 97°F (36°C)

• Freeze alarms when under 45°F (7°C)

• Freeze restores when over 48°F (9°C)

To replace the batteries, insert a at blade screwdriver into

the front slot and twist. Slide both old batteries out and the

new batteries in. To reinstall the cover, align the rear latches

and roll the cover forward until it snaps into place.

Verify proper enrollment and operation using your control panel’s installation manual.

Front slot

Mounting Screw Hole

Wall Clip

RE218 Flood & Temp Sensor

Honeywell® Compatible

Resolution Compatibles

Pro Tips

The cover can be removed without removing the wall clip.

Both titanium probes must be in the same puddle for the sensor to detect water.

Tamper detection depends on how the sensor is installed.

• Sensor secured to wall: Tamper is indicated when lifted off the clip.

• Sensor NOT secured to wall: Tamper is indicated when the cover is removed.

When changing the batteries replace both with new batteries.

Automatic enrollment signals are sent for loop 3 (Flood) when the battery tabs are

removed.

Specications

Physical

Housing Dimensions

Weight with Batteries

Mounting Fastener

2.43 x 2.48 x 1.17 inches (6.2 x 6.3 x 3.0 cm)

1.34 ounces (38 grams)

#6 screw (not provided)

Environmental

Operating Temperature

Maximum Humidity

Water Resistance

32°F to 120°F (0°C to 49°C)

85% non-condensing relative humidity

IP67 rated (Waterproof for over 30 minutes at 1 meter depth)

Sensor Specications

Frequency

Replacement Batteries

Nominal Battery Life

Battery Voltage

Current Draw

Transmitted Indications

Temperature Accuracy

345 MHz

Two Panasonic CR2032

10 years

3.0 VDC (Nominal) 2.3 VDC (Low)

20 mA (Maximum) 0.5 uA (Quiescent)

Cover Tamper, Wall Tamper, Low Battery, Supervision

+/- 2°C

Certication

RE218 FCC, IC

Specications subject to change without notice.

47-0028-02 • REV C • 2018-03-28

Tech Support Line • (888) 88-ALULA • (888) 882-5852

alula.net

WARRANTY

Alula will replace all non-portable products that are defective in

their rst ve (5) years, and all portable products that are defective

in their rst two (2) years.

IC NOTICE

This device complies with Industry Canada license-exempt RSS

standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and

(2) This device must accept any interference, including interference

that may cause undesired operation of the device.

Le présent appareil est conforme aux cnr d’Industrie Canada

applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) L’appareil ne doit pas produire de brouillage, et

(2) L’utilisateur de l’appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est susceptible d’en

compromettre le fonctionnement.

IC: 8310A-RE218

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is

subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference that may be received,

including interference that may cause undesired operation.

Changes or modications not expressly approved by Alula could void

the user’s authority to operate this equipment.

FCC ID: U5X-RE218

TRADEMARKS

Alula is a trademark owned by Alula Holdings, LLC.

“Honeywell” is a trademark owned by Honeywell International, Inc.

Alula products will function with Honeywell systems. However, no

Alula product is produced by, endorsed by, or ofcially associated

with Honeywell. Alula recommends verifying proper enrollment and

operation, per control panel installation instructions, at installation.
