Side 1/4
R
Questions?
1-800-325-3841
Anthro
Corporation Technology Furniture
®
10450 SW Manhasset Drive Tualatin, Oregon 97062 anthro.com
Rev. F January 2006
Hello! Thank you for choosing Anthro.
Before beginning assembly of your Console Unit, take a moment to review the parts listed on the next page
to verify that your shipment is complete.
Please review the assembly instructions of all Anthro products you
purchased and are planning to include in this installation, prior to beginning this assembly.
Your Console Unit is heavy!
A second person will be needed for this assembly procedure.
To make the assembly of your Console Unit even easier, we have included all of the required tools. The handy
Hex Driver Bit can be used in your electric drill in place of the Hex Driver.
Hex Driver
5
/
32
”
...........................................................
375-5000-00
Hex Driver Bit
5
/
32
”
....................................................
375-5003-00
Hex Key
5
/
32
”
................................................................
375-5016-00
Hex Key
/
4
”
.................................................................
375-5024-00
3-Way Wrench
............................................................
225-5196-03
8 oz. Rubber Mallet
....................................................
375-5022-00
Console Unit
Assembly Instructions
1-800-325-3841
Step 15
Begin by placing the Base Tube Assembly
(Locking Casters
as shown)
onto the Vertical Legs.
Attach the Base Tubes to each Leg by inserting a
fit
Bolt through a Tube Washer, then insert the
fit
Bolt
through the Base Tube and carefully thread into
each Vertical Leg.
Tighten all
fit
Bolts and Cap Screws.
Step 16
(uses the
/
8
” Hex Key)
Carefully rotate your Console Unit onto the Casters.
Pop the six Small End Caps into the Leg ends.
Congratulations!
Your assembly is complete.
(
5
/
16
-18 X 3.5”)
fi t
Bolt
325-5194-00
fi t
Tube Washer
225-2050-00 or 225-3522-00
fi t Tube Washer
Locking Casters
Small End Caps
Adjust the Caddy Shelf height by:
1. Squeezing and holding the Paddle.
2. Reposition the Caddy to the desired location.
3. Release the Paddle.
Rotate Knob to
adjust Caddy
angle.
Squeeze Paddle
to adjust Caddy
height.
Adjust the Caddy Shelf angle by:
1. Rotating the Knob counterclockwise.
2. Reposition the Caddy to the desired angle.
3. Rotate the Knob clockwise.
Adjusting your Console Caddy
Anthro
Corporation Technology Furniture
®
10450 SW Manhasset Drive Tualatin, Oregon 97062 1-800-325-3841
anthro.com
18– 3” Non-Locking Casters
...........
Qty. 4
...................
150-5052-00
19– Caster Inserts
...............................
Qty. 6
...................
525-5032-00
20– 2.0” Large End Caps
...................
Qty. 4
...................
175-5157-00
21– Insert Screws
............................
Qty. 6
...................
325-5052-00
22–
fi t
Console Back Trough-Y
......
Qty. 1
...................
225-2368-00
23– Button Head Screws
..................
Qty. 4
...................
325-5003-00
24– 1.5” Small Caps
.............................
Qty. 6
...................
175-5156-00
25– Small Support X
..........................
Qty. 1
...................
225-2014-00
26–
3
/
4
” Wood Screws
........................
Qty. 42
................
325-5106-00
27– Support Screws
............................
Qty. 12
................
325-5010-00
28–
fit
Corner Connector Support-X
.
XX
Qty. 1
...................
225-5582-00
29–
fit
Corner Connector Support-Y
.
YY
Qty. 1
...................
225-5583-00
All Fastener quantities listed here are the minimum needed
for your Console Unit assembly. There may be a few extra
Fasteners included, which are not counted in the Parts List.
Component list for part # FCCzz/xx3
Detailed views of all Hardware is provided with each Assembly Step.
06
08
09
13
15
21
19
Step 12
(uses the
/
4
” Hex Key)
Position the 15.27” Base Tube against the Console
Junction, then mate the Keyed Feature to the Keyed Tube
End. Secure the Base Tube using a Cap Screw & the
/
4
”
Hex Key.
Place the 15 “ Base Tube against the Base Junction and
secure using a Cap Screw.
NOTE: Do not yet fully tighten the 15” Base Tube Cap Screw.
Step 13
(uses the
/
4
” Hex Key)
Place the Console Base Junction-X onto the open ends
of the 15” & 15.27” Base Tubes as shown, then mate the
Keyed Feature to the 15.27” Keyed Tube End.
Secure both Base Tubes to the Console Base Junction
using two Cap Screws & the
/
4
” Hex Key.
NOTE: Do not yet fully tighten the 15” Base Tube Cap Screw.
Step 14
(uses the
/
4
” Hex Key)
Place the non-coped ends of the two remaining Cross
Tubes against the Base Junction and loosely
secure using
two Cap Screws.
Orient the remaining Base Tube assembly as shown.
Secure to the coped Cross Tube Ends by inserting
a
fit
Bolt through a Tube Washer, then insert the Bolt
through the Base Tube and carefully
thread into each
Cross Tube, but don’t fully tighten the
fit
Bolts yet.
Tighten the two Cap Screws installed during
this Step.
(
5
/
16
-18 X 1.5”)
Cap Screw
325-5225-00
(
5
/
16
-18 X 1.5”)
Cap Screw
325-5225-00
Leave these two holes
open on the 15” Base Tube
be
15.27” Base Tube
Keyed ends
Screw
Leave these two holes open
15.27” Base Tube
Keyed end
fi t Tube Washer
Side
holes
Cross Tubes
Locking Caster
Cap Screw
(
5
/
16
-18 X 3.5”)
fit
Bolt
325-5194-00
fit
Tube Washer
225-2050-00 or 225-3522-00
(
5
((
/
16
-18 X 1.5”)
Cap Screw
325-5225-00
25
22
29
Base Tube Assembly
(from Step 11)
Console
Base
Junction-Y
Console Base Junction-X
Console
Base Junc-
tion-X
Remaining Base
Tube Assembly (from
Step 9)
Keyed Feature
01–
fi t
––
Console Large Shelf
.............
ff
Qty. 1
...................
100-6498-00
02–
fit
Console Caddy
......................
Qty. 1
...................
100-6499-
00
03–
fit
––
Adjusta Mechanism
...............
Qty. 1
...................
225-5547-00
(The Adjusta Mechanism is packaged separately & requires assembly)
04–
fit
Console Back Trough-X
....
Qty. 1
...................
225-2367-00
05– Small Support Y
...........................
Qty. 1
...................
225-2015-00
06–
fit
24.875” Vertical Legs
............
Qty. 6
...................
125-5230-00
07–
fi t
21” Base Tubes
.......................
Qty. 2
...................
125-5275-00
08–
fi t
30.5” Console Cross Tubes
...
Qty. 4
...................
125-5248-00
09–
fi t
Console Base Junction-Y
...
Qty. 1
...................
225-5787-00
10– Acorn Nuts
....................................
Qty. 2
...................
325-5023-00
11– Cap Screws
....................................
Qty. 8
...................
325-5225-00
12–
fit
15.27” Keyed Base Tube
.....
Qty. 1
...................
125-5249-00
13–
fit
––
15” Base Tube
.........................
Qty. 1
...................
125-5250-00
14–
fit
Console Base Junction-X
...
Qty. 1
...................
225-5786-00
15– 3” Locking Casters
......................
Qty. 2
...................
150-5053-00
16–
5
/
6
-18
fi t
Bolts
..............................
Qty. 10
................
325-5194-00
17–
fi t
Tube Washers
.........................
Qty. 10
225-2050-00 or 225-3522-00
Cap
Screw
