DIMMABLE LED LIGHT
WITH SPEAKERS
User manual
Modell: Soundbird B10
• Bluetooth version: v.5.3
• Communication distance:
<10 meter
• Music time: 12h (50% volume)
• Speaker: 52mm / 10W*2
• Charging time: 5.5h
• Battery capacity:
10000mAh/3.7V
• Charging voltage: DC4.7~5.5V
• Rated power: 20W
Soundbird B10 Instruction
manual
Charging
cable Type-A
to Type-C.
Congratulations on your
purchase of the Soundbird B10.
This is a well tested, safe to use
product from Aqiila that we hope
will bring you much joy and help
you experience things in an
easier and more fun way
than before.
+ +
DIMMABLE LED LIGHT
WITH SPEAKERS
User manual
Modell: Soundbird B10
INCLUDED:
SPECIFICATIONS:INTRODUCTION:
FUNCTION KEYS:
1. Power button.
-Long press 3 seconds to turn on/o
-Once Power is on, at first time use, or when no
device is connected, the device automatically
enters into pairing mode.
-Short press: answer/end call, play/pause music
How to pair
multiple speakers:
-Disconnect your phone from the
speaker.
-Press down button 3 (Mode)
simultaneously on both speakers, the
speakers will then say ‘pairing mode’.
-Have the buttons pressed down for
three seconds intil you hear ‘beep’.
-Re-connect your phone to the main
speaker (Soundbird), and your
TWS-speakers are ready to Rock!
How to pair
your phone:
-Hold on/o button pressed for
3 seconds on speaker.
-Go to your Bluetooth seetings on your
device and connect the Soundbird.
Please note:
When you connect two Soundbirds together, it’s
important that you are not
connected to your phone at the same time.
2. Volume button -
-Short press the volume button: turn down the volume
-Long press the volume button: switch to the previous song
1.
2.
3.
4.
5.
6.
3. Source button
-Short press: Change source of sound (bluetooth, AUX, TF-card).
-Long press: Connection of two Soundbirds in TWS-pairing.
(please note: Disconnect your phone before pairing.)
4. Yellow light button
-Short press: Turn light on.
-Short press repeatedly to switch between the three light modes.
-4th short press turns the light o.
-Long press (>8 seconds) to reset and shut down the device.
5. Multi color light button
-Short press: Turn on the breathing light (in various ever changing colors).
-Short press second time: Freeze the breathing light into a monochrome light.
-Long press: Turn o the breathing light.
6. Volume button +
-Short press the volume key: turn up the volume
-Long press the volume key: switch to the next song
Charging port:
Charge your Soundbird via the
USB Type-C connection.
Powerbank use:
Charge your phone or other device by using
the built-in Powerbank. The Powerbank is
accessed by connecting to the USB Type-A
connection.
