Side 1/43

DESKTOP BARCODE PRINTER

OS-214plus/OS-2140D/

OS-2140/OS-2140Z/

OS-2140DZ/OS-2140E

User’s Manual

Website: http://www.argox.com

Proprietary Statement

This manual contains proprietary information of Argox Information Co., Ltd. It is

intended solely for the information and use of parties operating and maintaining

the equipment described herein. Such proprietary information may not be used,

reproduced, or disclosed to any other parties for any other purpose without the

expressed written permission of Argox Information Co., Ltd.

Product Improvements

Continuous improvement of products is a policy of Argox Information Co., Ltd. All

specifications and signs are subject to change without notice.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that the interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and the receiver.

 Connect the equipment into a different outlet on a different circuit.

 Consult the dealer or an experience Radio/TV technician for help.

This unit was tested with shielded cables on the peripheral devices. Shielded

cables must be used with the unit to insure compliance. The user is cautioned

that any changes or modifications not expressly approved by Argox Information

Co., Ltd. could void the user’s authority to operate the equipment.

Liability Disclaimer

Argox Information Co., Ltd. takes steps to assure that the company’s published

engineering specifications and manuals are correct; however, errors do occur.

Argox Information Co., Ltd. reserves the right to correct any such errors and

disclaims any resulting liability. In no event shall Argox Information Co., Ltd. or

anyone else involved in the creation, production, or delivery of the

accompanying product (including hardware and software) be liable for any

damages whatsoever (including, without limitation, damages for loss of business

profits, business interruption, loss of business information, or other pecuniary

loss) arising out of the use of or the results of use of or inability to use such

product, even if Argox Information Co., Ltd. has been advised of the possibility of

such damages.

CAUTION:

Any changes or modifications not expressly approved by the party responsible

for compliance could void the user's authority to operate the equipment.

Safety

INDUSTRY CANADA NOTICE:

This device complies with Industry Canada ICES-003 class A requirements.

Cet equipement est conforme a ICES-003 classe A de la norm Industrielle

Canadian.

Supplemental Information: This device complies with the

requirement of FCC Part 15 Rules. Operation is subject to the

following two Conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference

received, including interference that may cause un

desired operation.

Please only use adapters with the following electrical characteristics and

are certified by current legislation. Using other adapters may damage the

device and void the warranty also cause risks to the user.

Features Output: 24VDC, 2.4A

The manufacturer declares under sole responsibility that this product

conforms to the following standards or other normative documents:

EMC: EN 55022:2006+A1:2007, class A

EN 55024:1998+A1:2001+A2:2003

Argox Information Co., Ltd certifies that the following products and/or

components are compliant with the current requirements of the European

Union Restriction on the use of Hazardous Substances (RoHS) Directive,

2002/95/EC.

III

Table of Contents

Safety .................................................................................... II

Getting Started ..................................................................5

Unpacking .............................................................................. 5

Package Contents................................................................ 6

Connecting the Power Supply ................................................. 7

Getting to Know Your Printer .........................................10

Parts and Features ................................................................. 10

Controls and Indicators ......................................................... 13

Loading Ribbon and Media ............................................15

Loading Ribbon .................................................................... 15

Loading Media...................................................................... 20

Standard Mode.................................................................. 20

Cutter Mode...................................................................... 25

Calibration and Configuration........................................27

Performing Calibration and Configuration ............................ 27

Resetting to Factory Default Settings .................................... 28

Computer Connections...................................................29

USB Interface Requirements................................................. 29

Serial (RS-232) Interface Requirements ................................ 30

Serial Cabling Requirements................................................. 31

Parallel Interface Requirements ............................................ 32

Ethernet Interface.................................................................. 33

Communicating with the Printer ....................................35

Installing a Plug and Play printer driver (for USB only) ........ 35

Installing the Printer Driver................................................... 43

Troubleshooting ..............................................................55

LED Diagnosis ..................................................................... 55

Miscellaneous....................................................................... 58

Recovery .............................................................................. 59

Caring for Your Printer....................................................60

Cleaning ............................................................................... 60

Produkt Specifikationer

Mærke:	Argox
Kategori:	Etiketprinter
Model:	OS-2140
Bredde:	186 mm
Dybde:	278 mm
Højde:	165 mm
Vægt:	2000 g
Produktfarve:	Hvid
Wi-Fi:	Ingen
USB-port:	Ja
Opbevaringstemperatur (T-T):	-20 - 50 °C
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Antal USB 2.0-porte:	1
Ethernet LAN:	Ingen
Driftstemperatur (T-T):	4 - 38 °C
Udskrivningsteknologi:	Direkte termisk/termisk overførsel
Maksimal opløsning:	203 x 203 dpi
Intern hukommelse:	8 MB
Udgangsspænding for vekselstrømsadapter:	24 V
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, cTUVus, FCC, CCC
LED-indikatorer:	Power, Status
Flashhukommelse:	4 MB
Vekselstrømsadapterens udgangsstrøm:	2.92 A
Indbygget processer:	RISC
Understøttet papirbredde:	25.4 - 110 mm
Udskrivningshastighed:	102 mm/sek.
RS-232-porte:	1
Maksimal udskrivningsbredde:	105 mm
Maksimal rullediameter:	109 mm
Kernediameter:	12.7 mm
Medietykkelse:	0.0635 - 0.254 mm
Indbyggede stregkoder:	1D, 2D, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, PDF417, POSTNET, UPC-A, UPC-E
Båndbredde:	101.6 mm
Båndlængde:	92 m
