Nebia
®
Yuba
™
5Setting Handshower with
HaloNetic™ Double Docking System
Douchette à 5 réglages avec
système d’amarrage double HaloNetic
Ducha de mano de 5 ajustes con
sistema de doble acoplamiento
HaloNetic
Quick Start Installation Guide
Guide d’installation et de démarrage rapide
Guía de instalación de inicio rápido
Model/Modèle/Modelo: NE80HSHN
#24NE80-HSHN_WEB_0724
PO Box 470085
San Francisco, CA 941470085
(888) 5423355
brondell.com
WARNING:
If you have a pacemaker or other implantable medical device, please note
that this handheld shower product contains neodymium magnets ranging in
strength up to .41T. In certain conditions, some magnets may interfere with
the operation of pacemakers or other implantable medical devices. Please
consult with your device manufacturer and or physician for speciic guidance.
Step 4
Step 5
Step 3
Installation:
1. Unscrew existing showerhead by turning it counterclockwise. If necessary,
use an adjustable wrench.
2. Conirm the washer (black donut) is in the cradle’s shower ball.
3. Thread the cradle’s shower ball connection onto the shower arm, and tighten
clockwise by hand.
NOTE: Be careful not to overtighten or cross thread to avoid damaging the
connections.
4. Conirm the washers (black donuts) are placed in both ends of the hose.
Connect hose to cradle and handshower and tighten connections by hand.
CAUTION: Risk of personal injury! If the water temperature is set too high,
scalding will occur. The water temperature should never be set above 120°F
(49°C). Do not use this Brondell low-low product with a shower valve that
allows the water temperature to become too hot.
5. Attach the magnet to the dock. Tilt the handle upwards to remove from the dock.
Switching Spray Settings:
To switch between Nebia Yuba’s 4 spray settings, rotate the handshower face to the
left or right.
Using Pause Mode:
1. Nebia Yuba has a Pause Mode button on the back of the handle to help save
water while lathering, rinsing, etc.
2. To turn on Pause Mode, press the button to the upward position.
3. To resume showering, press the button to the downward position.
NOTE: Each Pause Mode is distinct and pressure and pattern may vary.
Step 2
Limited Lifetime Warranty
Brondell products are backed by some of the most comprehensive warranties in the industry. Brondell warrants
that our Brondell Nebia Shower Products (excluding consumable items and Filtered Showerhead and Compact
Shower Filter) shall be free from defects in material and workmanship under normal use and service.
Brondell Nebia Shower Products Residential Limited Lifetime Warranty:
• Brondell will provide free of charge the necessary parts to put the shower products back in good working
condition.
• Brondell will replace free of charge any part or inish that proves defective in material and manufacturing
workmanship, under normal installation, use and service.
• Valid proof of purchase from the original consumer purchaser must be provided with any warranty claims.
• Brondell will provide parts free of charge, but the customer is responsible for any associated shipping costs
to receive the parts.
Brondell Nebia Shower Products Commercial Warranty:
The warranty period is 5 years from original purchase date for all Brondell Nebia Shower products.
Exclusions and Limitations
1. BRONDELL warrants its products to be free from manufacturing defects under normal use and service.
This warranty is extended only to the ORIGINAL PURCHASER.
2. BRONDELL’s obligations under this warranty are limited to repairs or replacement, at BRONDELL’s option, of
products or parts found to be defective, provided that such products were properly installed and used in
accordance with instructions and using genuine Brondell parts. BRONDELL reserves the right to make such
inspections as may be necessary to determine the cause of the defect.
3. BRONDELL is not responsible for the cost of removal, return (shipping) and/or re-installation of products.
This warranty does NOT apply to:
• Damage or loss which occurs during shipment.
• Damage or loss sustained through any natural or man-made causes beyond the control of BRONDELL,
including but not limited to ire, earthquake, loods, etc.
Limited Lifetime Warranty (cont.)
• Damage or loss resulting from sediments or foreign matter contained in a water system.
• Damage or loss resulting from negligent or improper installation including installation of a unit in a
harsh or hazardous environment.
• Damage or loss resulting from removal, improper repair, modiication of the product, or improper main-
tenance including damage caused by chlorine or chlorine-related products.
• This Warranty does not cover Brondell Filtered Showerhead or Compact Shower Filter Products
4. This warranty gives you speciic legal rights. You may have other rights which vary from state to state.
THIS WRITTEN WARRANTY IS THE ONLY WARRANTY MADE BY BRONDELL. REPAIR OR REPLACEMENT AS
PROVIDED UNDER THIS WARRANTY SHALL BE THE EXCLUSIVE REMEDY AVAILABLE TO THE PURCHASER.
BRONDELL SHALL NOT BE RESPONSIBLE FOR LOSS OF USE OF THE PRODUCT OR FOR OTHER
INCIDENTAL, SPECIAL, FOR CONSEQUENTIAL DAMAGES OR EXPENSES INCURRED BY THE PURCHASER OR
FOR LABOR OR OTHER COSTS DUE TO INSTALLATION OR REMOVAL OR COSTS OF REPAIRS BY OTHERS,
OR FOR ANY OTHER EXPENSE NOT SPECIFICALLY STATED ABOVE. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTIES, INCLUDING THAT OF MERCHANTABILITY, ARE EXPRESSLY
LIMITED TO THE DURATION OF THIS WARRANTY. SOME STATES DO NOT ALLOW LIMITATIONS, SO THE
ABOVE LIMITATION AND EXCLUSION MAY NOT APPLY TO YOU.
How to Obtain Service
To initiate a Brondell warranty claim, please visit Brondell.com/support and complete our online support request
form or call our Customer Support team for assistance at 18885423355. Our dedicated Customer Support
specialists will work with you to troubleshoot the issue, and depending on the results, will provide you with a
Return Merchandise Authorization (RMA) number and a pre-paid shipping label, if applicable, for you to ship
your Brondell product to our Service Center.
When returning your item to our Service Center, please ensure to include the RMA number and a copy of the
original receipt as proof of purchase for proper identiication and processing.
