Side 1/8

Smart Hyde

USER MANUAL

Thank your for buying our Smart Hyde ampliﬁer. We hope you’ll enjoy it for years to come. Please read these

instructions carefully and keep this manual for later reference. .

1. WARNINGS AND SAFETY

• To prevent ﬁre or electric shocks, the device must not be exposed to rain or humidity.

• For your own safety: to prevent electric shocks do not remove the housing.

• Do not try to repair any malfunctioning parts of the device yourself. Ask a professional expert to do this for you.

• When plugged into the mains, the device remains electrically charged even when switched o.

2. CONTENTS

Check that the packaging contains the following parts:

• 1x Smart Hyde

• 1x Power supply

• 2x RCA cable

• 2x Antennas

• 1x User Manual

1. Warnings and safety 1

2. Contents 1

3. Interface and Functions

A. Front panel 2

B. Rear panel 2

4. Use 3

5. Installation 3

A. Unpack 3

B. Placement 3

C. Connect 3

D. Download the App 4

E. First time usage & WiFi setup 4

6. Connection via LAN 4

7. Connection via Bluetooth 4

8. 4Stream Application 4

A. Playback 4

B. Streaming from Mobile Phone / NAS /

Online Music Services 5

C. Device Settings 6

9. Firmware update 6

10. Technical Speciﬁcations 6

11. FAQ 7

12. Warranty conditions 7

SMART HYDE

3. INTERFACE AND FUNCTIONS

A FRONT PANEL

1. WiFi ANT: Antenna for WiFi connection

2. Reset: Short press to reset network, Long press

to factory reset

3. Line in R: Right channel audio input

4. Line in L: Left channel audio input

5. SW out: Audio output to an active subwoofer

6. OPT in: Optical digital audio input to connect tv

sound or others

7. LAN: For RJ45 LAN network

8. USB: Used to connect USB disk drive

9. Load switch: The switch to switch between 4-8Ω

load

**Unplug the power before switching**

10. Speaker output: Used to connect 4-8 Ω speakers

with phoenix connector

11. BT ANT: Antenna for Bluetooth connection

12. DC in: Used to connect power adaptor

13. LED: Indicates the status of the device

Blinking white: Power on and searching for

network

Solid white: Network connected

Solid blue: Bluetooth mode

Solid red: USB mode

Solid green: Line input mode

Solid purple: Optical input mode

14. USB Audio: Used to connect to PC to stream

music directly from PC

15. PRE out: Audio output to provide analog signal to

an ampliﬁer, mixer, or other device.

16. Volume: Used to manually tune the device maxi-

mum volume, press to change audio input mode.

Volume range is large so you can turn the knob

around more than once.

17. Treble: Used to manually tune the treble, press to

reset to default value

18. Bass: Used to manually tune the bass, press to

reset to default value

B REAR PANEL

Produkt Specifikationer

Mærke:	Artsound
Kategori:	Højttaler
Model:	UNI30
Vekselstrømsindgangsfrekvens:	100 - 20000 Hz
Bredde:	115 mm
Dybde:	112 mm
Højde:	180 mm
Vægt:	1200 g
Produktfarve:	Sort
Udgangseffekt (RMS):	60 W
Strømforbrug (typisk):	20 W
Integreret ur:	Ingen
Anbefalet brug:	PC
Frekvensområde:	100 - 2000 Hz
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	2-vejs
Lyd-output kanaler:	1.0 kanaler
Højttaler, placering:	Floor, Tabletop/bookshelf
Strømkilde type:	Vekselstrøm
Antal drivere:	2
Diskanthøjttaler:	Ja
Sensitivitet:	86 dB
Indbygget batteri:	Ingen
Nattilstand:	Ingen
Diskant diameter:	1.2 "
Bashøjttaler:	Ja
Forstærker:	Indbygget
Højttaler kabinet:	Refleks
Woofer diameter (britisk mål):	3 "
Højttalerplacering:	Front
USB-opladning:	Ingen
Automatisk digital indstilling:	Ingen
Basrefleks:	Ja
Strømbesparende tilstand:	Ingen
Originalt modelnavn:	UNI30
