Side 1/15

Aruba AP-375EX and AP-377EX Outdoor Access Points

Installation Guide

Rev01 | July 2019 1

The Aruba AP-375EX and AP-377EX outdoor wireless access points support IEEE 802.11ac Wave 2 standard,

delivering high performance with the MU-MIMO (Multi-User Multiple-Input, Multiple-Output) technology, while

also supporting 802.11a/b/g/n wireless services.

The AP-375EX and AP-377EX outdoor wireless access points provide the following capabilities:

IEEE802.11a/b/g/n/ac operation as a wireless access point

IEEE802.11a/b/g/n/ac operation as a wireless air monitor

IEEE802.11a/b/g/n/ac spectrum monitor

Compatibility with IEEE 802.3at PoE

Package Contents

AP-375EX or AP-377EX access point

Cable gland x1

USB console cable x1

Copper lug x1

M4x6 screw x1

The weatherproof caps for Ethernet and Console interfaces are connected to the access point, not loose in the

package.

Mounting kits for use with the access points are sold separately. Contact your Aruba sales representative for

details.

Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton,

including the original packing materials. Use these materials to repack and return the unit to the supplier if

needed.

2Aruba AP-375EX and AP-377EX Outdoor Access Points | Installation Guide

Hardware Overview

Figure 1 AP-375EX Front View

Figure 2 AP-377EX Front View

LED

The access point is equipped with one LED that indicates the system status of the access point.

System LED

Produkt Specifikationer

Mærke:	Aruba
Kategori:	Adgangspunkt
Model:	AP-375EX
Bredde:	230 mm
Dybde:	240 mm
Højde:	270 mm
Vægt:	2400 g
Produktfarve:	Hvid
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	-40 - 60 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Sikkerhedsalgoritmer:	WPA2, WPA3
Strømforbrug (maks.):	23 W
Placering:	Ceiling, Wall
Netværksstandarder:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az
Servicekvalitet support (QoS):	Ja
Slot til kabellås:	Ja
Driftshøjde:	0 - 3000 m
Maksimal dataoverførselshastighed:	2033 Mbit/s
Modulation:	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Antenne type:	Intern
Kabellåseslids type:	Kensington
Strøm over Ethernet (PoE):	Ja
MIMO:	Ja
Auto MDI/MDI-X:	Ja
2.4 GHz:	Ja
5 GHz:	Ja
Niveau for antennestyrke (maks.):	4.6 dBi
Maksimal dataoverførselshastighed (5 GHz):	1733 Mbit/s
Maksimal dataoverførselshastighed (2,4 GHz):	300 Mbit/s
MIMO type:	Multi User MIMO
Antenneretningstype:	Omniretningsbestemt
