NA8912 / Second Edition / January 2014

1 2

Quick Start Guide

PCE-AC68

Wireless Local Area Network Card

(For 802.11 a/g/b/n/ac Wireless Networks)

Driver Installation

Insert the support CD into the optical drive.

Insérez le CD de support dans le lecteur optique.

Inserte el CD de soporte en la unidad óptica.

When the setup is complete, connect your desktop

PC to the Internet wirelessly via PCE-AC68.

Une fois la conguration terminée, connectez votre

ordinateur au réseau sans l par le biais du

PCE-AC68.

Use la utilidad ASUS para congurar la tarjeta

PCE-AC68.

Use the ASUS utility to add wireless proles.

Utilisez l’utilitaire ASUS pour ajouter des prols sans l.

Emplee la utilidad de ASUS para agregar perles

inalámbricos.

Adjust the magnetic antenna base to get the best

signal with your router.

Ajustez la base de l’antenne magnétique pour

améliorer la qualité du signal sans l du routeur.

Ajuste la base de antena magnética para obtener la

mejor señal con su enrutador

Follow the onscreen instructions to complete the

installation.

Suivez les instructions apparaissant à l’écran pour

compléter l'installation.

Siga las instrucciones que aparezcan en la pantalla

para completar la instalación.

Setting up a Home Network

To adjust network performance, click the Advanced button on

the Survey page.

Pour régler les performance réseau, cliquez sur le bouton

Advanced (Avancé) de la page Survey (Analyse de site).

Para ajustar el rendimiento de la red, haga clic en el botón

Opciones avanzadas de la página Estudio.

NA8912_PCE-AC68_v2_QSG.indd 1 1/2/14 4:30:33 PM

Hot Products

RT-AC66U

• 5th generation 802.11ac chipset offers you concurrent

dual-band 2.4GHz/5GHz with up to 1.75Gbps

connection speed

• ASUS AiCloud service: Access, stream, share and sync

les with unlimited storage expansion!

• Gigabit Ethernet ports for the fastest and most reliable

Internet performance

• AiRadar optimizes wireless coverage with detachable

high-powered antennas

• Enjoy the ASUSWRT dashboard UI for three-step setup,

signal monitoring and network application control

• Download Master for wireless data storage and access

to router-connected USB storage devices

• File sharing, printer sharing and 3G sharing via two

multi-functional built-in USB ports

EA-N66

• Powerful dual-band 3x3 Ethernet adapter delivers

extreme 450Mbps Wi-Fi speed

• Selectable 2.4GHz/ 5GHz dual-band reduces Wi-Fi

interference for HD multimedia

• Patented Orthogonal antenna design for best Wi-Fi

coverage

• 3-in-1 function: Ethernet adapter, universal repeater,

and AP mode

• Quick and easy setup with ASUS new UI

Additional Canadian information on RF exposure also can be found at the

following web: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Canada, avis d’Industry Canada (IC)

Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et

RSS-210.

Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas

causer d’interférence et (2) cet appareil doit accepter toute interférence, notamment les

interférences qui peuvent a ecter son fonctionnement.

Informations concernant l’exposition aux fréquences radio (RF)

La puissance de sortie émise par l’appareil de sans l ASUS est inférieure à la limite

d’exposition aux fréquences radio d’Industry Canada (IC). Utilisez l’appareil de sans l ASUS

de façon à minimiser les contacts humains lors du fonctionnement normal.

Ce périphérique a été évalué et démontré conforme aux limites SAR (Speci c Absorption

Rate – Taux d’absorption spéci que) d’IC lorsqu’il est installé dans des produits hôtes

particuliers qui fonctionnent dans des conditions d’exposition à des appareils portables (les

antennes se situent à moins de 20 centimètres du corps d’une personne).

Ce périphérique est homologué pour l’utilisation au Canada. Pour consulter l’entrée

correspondant à l’appareil dans la liste d’équipement radio (REL - Radio Equipment List)

d’Industry Canada rendez-vous sur:

http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng

Pour des informations supplémentaires concernant l’exposition aux RF au Canada

rendezvous sur :http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

REACH

Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of

Chemicals) regulatory framework, we published the chemical substances in our products at

ASUS REACH website at http://csr.asus.com/english/REACH.htm.

DSL-N55U

• Integrated home gateway with independent CPUs for

modem and router

• Dual-band Wi-Fi delivers up to 600Mbps in bandwidth

• 4x Gigabit Ethernet ports provide enhanced wired

network performance

• Auto-detecting ADSL connection with CD/manual-

free setup

• Finest P2P experience via 300,000 concurrent data

sessions

• File sharing, printer sharing and iPad charging using

multi-functional twin USB ports

RT-N56U

• Concurrent Dual-band - two 300Mbps Wireless-N

networks at one time

• Dual-band for lag-free entertainment

• Gigabit Ethernet ports for the fastest and most

reliable Internet performance

• 5X faster Gigabit Internet surng with hardware NAT

• File sharing, printer sharing and 3G sharing via two

multi-functional built-in USB ports

• Powerful online multitasking at up to 300,000 data

sessions

RT-N53

• Concurrent Dual Band - two 300Mbps Wireless-N

networks at one time

• Guest Network Access - Four separated wireless

networks on the 2.4GHzband with customized

security and access restrictions

• Easy Universal Repeater - Extend your Parent AP in

the fastest and most intuitive way

• Clever wall-mount design

• Parental Control - Control your kid's computer time

RT-N66U

• 2.4GHZ and 5GHz concurrent dual-band transmissions

for strong sginal strength and ultra-fast connection rates

up to 900Mbps

• Gigabit Ethernet ports for faster, most reliable Internet

performance

• Download Master for wireless data storage and access

to router-connected USB storage devices

• Expanded wireless coverage with detachable high-

powered antennas

• File sharing, printer sharing, and 3G sharing via two

multi-functional built-in USB ports

• ASUSWRT dashboard UI for easy setup, signal

monitoring, and network application control

Manufacturer ASUSTeK Computer Inc.

Tel: +886-2-2894-3447

Address: 4F, No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN

Authorised

representative

in Europe

ASUS Computer GmbH

Address: HARKORT STR. 21-23, 40880 RATINGEN,

GERMANY

Authorised

distributors in

Turkey

BOGAZICI BIL GISAYAR SAN. VE TIC. A.S.

Tel: +90 212 3311000

Address: AYAZAGA MAH. KEMERBURGAZ CAD. NO.10

AYAZAGA/ISTANBUL

CIZGI Elektronik San. Tic. Ltd. Sti.

Tel: +90 212 3567070

Address: CEMAL SURURI CD. HALIM MERIC IS MERKEZI

No: 15/C D:5-6 34394 MECIDIYEKOY/ ISTANBUL

KOYUNCU ELEKTRONiK BiLGi iSLEM SiST. SAN. VE DIS

TIC. A.S.

Tel: +90 216 5288888

Address: EMEK MAH.ORDU CAD. NO:18, SARIGAZi,

SANCAKTEPE ISTANBUL

AEEE Yönetmeliğine Uygundur.

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

• This device may not cause harmful interference.

• This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

If this device is going to be operated in 5.15 ~ 5.25GHz frequency range, then it is

restricted in indoor environment only.

CAUTION:

Any changes or modications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

Prohibition of Co-location

This device and its antenna(s) must not be co-located or operating in conjunction

with any other antenna or transmitter.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This euipment shhould be installed and operated with

minimum distance 20cm between the radiator and your body.

CE Mark Warning

This is a Class B product, in a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

Operation Channels: Ch1~11 for N. America, Ch1~14 Japan, Ch1~13 Europe (ETSI)

低功率電波輻射性電機管理辦法

(1)「經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自

變更頻率、加大功率或變更原設計之特性及功能」以及(2)「低功率射頻電機之使用不

得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干

擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻

電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾」。

Canada, Industry Canada (IC) Notices

This Class B digital apparatus complies with Canadian ICES-003 and RSS-210.

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference

that may cause undesired operation of the device.

Radio Frequency (RF) Exposure Information

The radiated output power of the ASUS Wireless Device is below the Industry

Canada (IC) radio frequency exposure limits. The ASUS Wireless Device should

be used in such a manner such that the potential for human contact during normal

operation is minimized.

This device has been evaluated for and shown compliant with the IC Specic

Absorption Rate (“SAR”) limits when installed in specic host products operated in

portable exposure conditions (antennas are less than 20 centimeters of a person’s

body).

This device has been certied for use in Canada. Status of the listing in the Industry

Canada’s REL (Radio Equipment List) can be found at the following web address:

http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng

NA8912_PCE-AC68_v2_QSG.indd 2 1/2/14 4:30:40 PM

Produkt Specifikationer

Mærke:	Asus
Kategori:	Netværkskort/adapter
Model:	PCE-AC68
Bredde:	103.3 mm
Dybde:	68.9 mm
Højde:	21 mm
Vægt:	125 g
Opbevaringstemperatur (T-T):	-20 - 65 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
Driftstemperatur (T-T):	0 - 40 °C
Sikkerhedsalgoritmer:	128-bit AES, 64-bit WEP, WPA-PSK, WPA2-PSK
Frekvensområde:	2.4 - 5 GHz
Forbindelsesteknologi:	Trådløs
Certificering:	CE, FCC, IC
Wi-Fi-bånd:	Dual-band (2,4 GHz / 5 GHz)
Netværksstandarder:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Harmoniseret systemkode (HS):	85176990
Værtsgrænseflade:	PCI Express
Grænseflade:	WLAN
Intern:	Ja
Antenne:	Ja
Maksimal dataoverførselshastighed:	1300 Mbit/s
Modulation:	16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Antennestik type:	R-SMA
