RT-BE58 Go
BE3600 Dual Band WiFi Router
Quick
Start Guide
Hardware Explanations
I/O Ports Overview
LED Lights Overview
DC Power input
USB-C PD Type:
+12V/2A, +9V/2A
Operating Temperature 0~40
o
C Storage 0~70
o
C
Operating Humidity 50~90% Storage 20~90%
Specications:
Prepare your Modem
01
1
Unplug the power of cable / DSL modem. If it has a
battery backup, remove the battery.
5
[App] Launch ASUS Router app and follow the
instructions to complete the setup.
Modem back
Install your Router
02
1
Plug the adapter into the DCIN port.
2
Connect your modem to WAN port at the back side of the router with the
network cable provided.
3
Power on the modem. Plug modem to the power outlet and power on.
Modem back
Check the modem LED lights to ensure the connection is active.
If you are using DSL for internet, you
will need your username / password
from your Internet service provider
(ISP) to properly congure your
router.
Modem front
– Or via web browser
3
[Wired] Connect your PC to LAN port at the back side of the
router using an additional network cable.
[Wireless] Connect to the network with default SSID shown on the product
label on the bottom side of your router “ASUS_XX”.
[Wired / Wireless] Open a web browser.
You will be redirected to the ASUS Setup Wizard. If not, navigate to
http://www.asusrouter.com.
Follow the instructions to complete the setup.
http://www.asusrouter.com
Welcome
Quick Internet Setup
START
– Via app
3
[App] On your iOS or Android mobile device, go to the app store,
search forASUS Router, and download the app.
[App] On your iOS or Android mobile device, tapSettings > Wi-Fi, connect
to the default network SSID shown on the product label on the bottom of
the router. Or scan the code on the product label to connect the default
network SSID.
* XX refers to the last two
digits of MAC address.
You can nd it on the
label on the bottom side
of your router.
Create a New Network
Advanced Settings
Welcome to RT-BE58 Go
LED
2
The LED will light up when the hardware is ready.
USB Type-C (DCIN) port
1 GbE LAN port
2.5 GbE WAN port
Reset button
USB 3.0 Gen1x1 port
E26687
Router Setup Steps
Slide switch
LED indications
Breathing green: Your RT-BE58 Go is starting up
Solid blue (Standby): Your RT-BE58 Go is ready for setup
Solid white: Your RT-BE58 Go has connected to Internet
Solid red: Your RT-BE58 Go has disconnected from Internet
Breathing blue: Your RT-BE58 Go is connecting to a public
WiFi (WISP mode)
Blinking yellow: Your RT-BE58 Go is resetting to factory
defaults
