Side 1/2

Component Checklist

Mounting Plate

Pole Assembly

VESA Plate

Mounting Plate Cover

Coach Screw (x4)

Nylon Anchor (x4)

M4/5/10 Washer

(x4 each)

Set Screw

M6/8 Spacer (x4)

M4/5 Spacer (x4)

(optional) Security Screw

2.5/3/5mm

Allen Key

Pole Assembly

Mounting Plate Cover

PUSH

Screw Pole Assembly

into Mounting Plate by

twisting top half of the

Pole Assembly only.

Pole

Assembly

Mounting Plate

TWIST

3mm

Allen Key

Set Screw

Insert Set Screw into the

Mounting Plate to lock the

Pole Assembly in position.

Pole Assembly

Mounting Plate

Cover

PUSH

TH-1040-CTS

TH-1040-CTL

IMPORTANT INFORMATION:

Step 1. Check Components

Check you have received all parts against the Component Checklist and Hardware above.

Step 2. Install Mounting Plate

Step 4.

Attach Pole Assembly to Mounting Plate

! IMPORTANT - Install 1040 Ceiling Tilt Mount (Short/Long) as per Installation Instructions.

! This product supports a maximum load of 25kg (55lbs).

! This product supports VESA mounting hole conﬁgurations 75x75mm, 100x100mm, 200x100mm, 200x200mm.

! The manufacturer accepts no responsibility for incorrect installation.

Step 5. Position Mounting Plate Cover

Step 3. Install Mounting Plate Cover

Hardware

Tools Required:

Power drill

•

7mm

(¼”)

drill bit

•

12mm

(½”)

masonry drill bit

•

Phillips head screw driver•

17mm

(

/16”)

Socket Wrench or Shifter

•

Masonry Ceiling

Timber Ceiling

Using the Mounting

Plate

as a template, mark

out

and drill

4x Ø7mm

(¼”)

holes,

Ø12mm

(½”)

for masonry

ceilings,

70mm

(2.75”)

deep.

Nylon Anchor

Mounting Plate

Coach Screw

M10 Washer

False Ceiling Cover

TH-1040-CTSW

TH-1040-CTLW

M4x16/25mm (x4 each)

M5x16/25mm (x4 each)

M6x16/30mm (x4 each)

M8x16/30mm (x4 each)

Display Mounting

Screws

Ceiling Tilt Short Mount / Ceiling Tilt Long Mount

Installation Instructions

Set Screw

Cable

Access Port

No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd.

Due to continuing product development, the manufacturer reserves the right to alter speciﬁcations without noticed. Published 05

.02.16 ©

Step 6. Set Height of Pole

Step 9. Cable Management

Whilst supporting the lower half of Pole

Assembly loosen

the

Socket Cap Screws (x2).

Slide Pole Assembly

to the desired height.

Tighten the Socket Cap

Screws (x2) to set the height.

Step 8. Attach Display to Pole Assembly

Feed cables down the Pole

Assembly through the Cable

Access Port.

Pull cables out from lower

half of the Pole Assembly

and

connect to Display.

Step 10. Height Adjustment

Pole Joint

LOOSEN

TIGHTEN

FIRMLY

Socket Cap

Screw

5mm Allen Key

ADJUST

HEIGHT

Loosen Socket Cap

Screws (x2) on the Donut.

TILT

PAN

Step 7. Attach VESA Plate to Display

TOP

Step 11. Final Adjustment

A. Pan,

Tilt and Rotate

the Display as

required.

If necessary, centralise the

Pole Joint by tightening the

Set Screws (x2) to suit.

2.5mm

Allen Key

VESA plate

Mounting

Screws

B. Slide

the height of the

Donut

as required. Tighten

Socket Cap Screws to lock.

Step 12. Install False Ceiling Cover

PORTRAIT TO

LANDSCAPE

Choose the appropriate

mounting hardware to suit the Display.

Spacers

(optional, for recessed

mounting holes)

B. PUSH

HOOK

(optional) Once Display

is attached, insert

Security Screw using

Phillips-head screwdriver

Security

Screw

Socket Cap

Screw

5mm

Allen Key

VESA Ball Mount

Tension Plate at rear

3mm Allen Key

If necessary tighten the VESA

Ball

Mount by adjusting the

Tension Plate. Using the 3mm

Allen Key adjust screws evenly.

Donut

SLIDE

False Ceiling

Cover

CLICK

Lower Pole

If the Lower Pole hangs below a suspended ceiling, clip the False

Ceiling Cover over the Lower Pole, and push up to the ceiling.

PUSH

Produkt Specifikationer

Mærke:	Atdec
Kategori:	Ikke kategoriseret
Model:	TH-1040-CTL
Produktfarve:	Sort
Panel montering grænseflade:	100 x 100,200 x 100,200 x 200 mm
Monteringstype:	Loft
Hældningsvinkelområde:	-20 - 20 °
Maksimal vægtkapacitet:	25 kg
Montering interface kompatibilitet (min.):	100 x 100 mm
Montering interface kompatibilitet (maks.):	200 x 200 mm
Loftsmontering rørlængde (maks.):	180 cm
Loftsmontering rørlængde (min.):	90 cm
