Side 1/8

– 1 – AtlasSound.com

Specifications are subject to change without notice.

Owner’s Manual AL2430

Atlas Learn

Amplifier/Receiver

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

AL2430

AtlasSound.com – 2 –

Specifications are subject to change without notice.

Owner’s ManualAL2430

Atlas Learn

Amplifier/Receiver

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this device near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your

safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they

exit from the device.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used

use caution when moving the cart/device combination to avoid injury from tip-over.

13. Unplug this device during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed

to rain or moisture, does not operate normally, or has been dropped.

15. WARNING: To reduce the risk of fire or electric shock, this device should not be exposed to rain or moisture and objects filled with

liquids, such as a vase, should not be placed on this device.

PA Amplifier

Model AA35

Output Rated 35W

Designed and Engineered

by Atlas Sound

Made In CHINA

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ATTENTION

RISQUE DE DECHARGE ELECTRIQUE

-NE PAS OUVRIR.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

The lightning flash with arrowhead symbol within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage “ within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the product.

Table of Contents

Important Safety Instructions .........................................................................................................................................2

Introduction ..................................................................................................................................................................... 4

Features ........................................................................................................................................................................... 4

Applications ..................................................................................................................................................................... 4

AL2430 Receiver / Amplifier Description .......................................................................................................................4

Installation ........................................................................................................................................................................6

Wiring ................................................................................................................................................................................7

AL2430 Block Diagram ....................................................................................................................................................7

Specifications ................................................................................................................................................................ 11

Warranty .........................................................................................................................................................................12

Produkt Specifikationer

Mærke:	Atlas
Kategori:	Modtager
Model:	AL2430
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	100 - 240 V
Bredde:	216 mm
Dybde:	343 mm
Højde:	45 mm
Produktfarve:	Sort
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	6.0 kanaler
Strømkilde type:	Vekselstrøm
Mikrofonindgang:	Ja
DC indgangsspænding:	24 V
klirfaktor (THD):	- %
Antal kanaler:	6 kanaler
Signal/støjforhold:	- dB
Linie ud:	Ja
Forstærker klasse:	A/B
Spidseffekt pr. kanal:	30 W
Højttalere tilslutningstype:	3.5mm / RCA
Output impedans:	8 ohm (Ω)
