Audibax Detroit 200 Go BT Manual

Audibax Højttaler Detroit 200 Go BT

Læs gratis den danske manual til Audibax Detroit 200 Go BT (4 sider) i kategorien Højttaler. Denne vejledning er vurderet som hjælpsom af 19 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 10 anmeldelser. Har du et spørgsmål om Audibax Detroit 200 Go BT, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/4
Detroit 200 Go BT
Please read the manual before using the product
USER´S
MANUAL
3
Detroit 200 Go BT
Safety Precautions
Do not clean the plastic enclosure with solvents or other chemical based cleaning products.
Do not place heat such as lighting equipment and smoke machines on the speaker cabinet.
Keep the device away from rain and moisture!
Always place the device in a secure manner to prevent the device from causing injury.
Damages caused by the disregard of this user manual are not subject to warranty. The
dealer will not accept liability for any resulting defects or problems.
Additional precautions for amplified devices
The device is designed use in dry conditions only.
Handle the power cord and all connections to the main power with particular caution!
The device should only be connected to 230V AC,50 Hz.
Never handle the power cord or the device when wet, as this could lead to electronic
shock.
Make sure the power-cord is in perfect condition before connecting.
Only handle the power-cord by the plug.
Always insert the power plug last. The power plug must always be interested without force.
Make sure that the power plug is tightly connected with the outlet.
Never let the power cord come into contact with other cables.
Only replace the fuse when the device is disconnected from the main power.
Only use fuses of the same rating and power. The correct fuse value is specified on the rear
panel.
Bluetooth connection
The first time you connect at device to the PA system, press the [MODE] button on the
MP3-player to enter Bluetooth mode, then find the PA system on the device you are
connecting. When using the connected device with Bluetooth, now you only need to switch
to Bluetooth mode on the PA system’s MP3-player—you don’t need to connect the device
again. If you need use the TWS, just push the Pair button after change to Bluetooth mode of
the two speakers. Then connect the Bluetooth with one of them, they will play the music
together.
How to connect two Detroit 200 Go BT speakers
It is possible to connect two Detroit 200 Go BT speakers with a simple XLR(male)-to-XLR(fema-
le)-cable using one speaker as a ‘master’ and another speaker as a ‘slave’.
Connect the female end of the XLR cable to the male ‘mix out’ on the ‘master’
speaker—then connect the 3-pin male end to the female line input on the ‘slave’ speaker.
BATTERY RECHARGE
The speaker has an internal, rechargeable battery capable of up to 6 hours of continuous
audio on a full charge. Even though the speaker may have some charge when first taken
out of the box, we recommend full charging your speaker before using the system. To
charge the battery:
1. Connect the speaker to a power outlet using the included power adapter.
2. Keep it plugged in until the indicator changes to 100%, that’s well charged. The speaker
utilizes a sealed lithium battery. When not in use, the battery will slowly self-discharge. If you
not use the speaker for long time, it should in full charge before storing. Better to charge the
unit every six months if no use. It will be good and longer to use. If the battery is in low
charge, impossible to recharge the battery, but the charge time is 6 hours more.
Detroit 200 Go BT USER´S
MANUAL
1 2
OPERATION Functions
1.SD card slot
2. [TWS Stereo Link] Bluetooth® connection button
3. Display of the built-in media player
4. USB port
5.MP3 Player
6. [MASTER] Rotary control to adjust the overall volume
7. [MUSIC] / [SPEECH] — [BASS BOOST] Rotary control to adjust the bass.
Turn the control to the left to reduce the bass. Turn the control to the right to increase the
bass.
8. [LEVEL]
Rotary control for adjusting the volume of the input signal at the line input
9. [POWER] / [LIMIT] Indicator LEDs for power supply and limiter
[POWER]: The LED lights up green once the unit is powered.
[LIMIT]: The LED lights up green when the signal is clipping. Turn down the control for the
master volume ([MASTER]) until the LED is no longer lit.
10. [LINE | MP3] Input signal switch. Use this button to toggle between external ([LINE] input)
and internal signal source (built-in media player).
When pressed, [MP3] the signal of the internal media player is played. When not pressed,
[LINE] the audio signal of an external audio player is played.
11. [LINE] 3.5 mm mini jack socket to connect an external audio device (CD or MP3 player)
12. [LINE OUT] Line output, designed as XLR output socket, 3-pin
13. [MIC/LINE 1] and [MIC/LINE 2] Mic / line inputs, designed as XLR input socket, 3-pin
14. Mic / line inputs, designed as 1/4" jack socket
15. [MIC] / [LINE] for channel 1 and 2 Toggle switch for the input signal of the respective
channel. Use these buttons to switch between mic and line input.
When pressed, [MIC] the microphone signal is played. When not pressed, [LINE] the line
signal is played.
16. [LEVEL 1] and [LEVEL 2] Rotary control for adjusting the volume of the input signal at the
line input of channel 1 or 2
17. [EFFECT 1] and [EFFECT 2] Rotary control for adjusting the echo effect of the input signal at
the line input of channel 1 or 2
18. IEC chassis plug with fuse holder for the power supply
19. [POWER] On / off switch
①
⑰
③
⑮
⑯
⑬
⑤
④
⑭
②
⑦
⑧
⑩
⑪
⑫
⑨
⑥
⑱ ⑲
MODE
Exchange between: USB/ SD/ BLUETOOTH REMOTE CONTROL
Play/Pause
Repeat
Last
Next

Produkt Specifikationer

Mærke: Audibax
Kategori: Højttaler
Model: Detroit 200 Go BT
