Side 1/4

Roma 120 Go

Please read the manual before using the product

USER´S

MANUAL

Roma 120 Go

Speciﬁcations

Model No.

Roma 120 Go

Type

PA System All-in-One Battery Powered

Transducer LF

1 * 6.5" subwoofer, 1" voice coil

Transducer HF

0.8'' dome tweeter

Frequency Response (-6dB)

60 Hz - 18 kHz

Max. SPL (1m, free space)

102 dB

Impedance

4Ohms

Ampli cation ﬁ

Class D with Mp3 Player

Power Output (RMS)

60W

Number of Mixer Channels

Number of Mic Preamps

2-Band Channel EQ

Inputs

2 * XLR / USB input

Outpust

1*XLR line out

Bluetooth

Yes, and support TWS function

Enclosure Material

Polypropylene Plastic

Mounting Options

35mm pole mount, Tilt-back, Floor Monitor, Wall mount

Power Supply

110~240V 50/60Hz

Battery

Rechargeable Lithium--ion battery 6pcs 1500mAh 18650

Roma 120 Go USER´S

MANUAL

1 2

Please read and keep all safety and use instructions. Important Safety Instructions

Refer to the user manual for more information about your Roma 120 Go

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produces heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding-type plug

has two blades and a third grounding prong. The wider blade or third prong is

provided for your safety. If the provided plug does not fit in your outlet, consult an

electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs,

convenience receptacles, and the point where it exits from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

13. Unplug this apparatus during lightning storms or when unused for long periods of

time.

14. Refer all servicing to qualified personnel. Servicing is required when the apparatus

has been damaged in any way such as power-supply cord or plug is damaged,

liquid has been spilled or objects have falleninto the apparatus, the apparatus has

been exposed to rain or moisture, does not operate normally, or has been dropped.

WARNINGS/CAUTIONS:

12. Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer or sold with the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to avoid injury from tip-over.

This symbol on the product means there is uninsulated, dangerous voltage

within the product enclosure that may present a risk of electrical shock.

This symbol on the product means there are important operating and

maintenance instructions in this guide.

Contains small parts which may be a choking hazard. Not suitable for

children under age 3.

This product contains magnetic material. Consult your physician on whether

this might affect your implantable medical device.

1. LCD Display: Mode, fast forward, reverse, single cycle, pause/play/TWS

*BT/TWS pair connecting: select BLUE in MODE on 2 speakers;

Long press TWS button simultaneously to activate it on 2 speakers for pairing Short press TWS

to disconnect pairing

2. USB: Insert the USB into the card slot to play the stored music.

3. SD: Put it in the SD card slot and play the stored music.

4. MP3 Control: Adjust the volume of MP3.

5. Line Output: Use a XLR cable to connect the line-level output to the Channel 1 or 2 input of

a second Roma 120 Go to create a mono, two-loudspeaker setup.

Note: Line Out is post mix.

6. Channel Input: Analog input for connecting microphone and instrument (XLR) cables.

7. MIC/Line Button: Press the button to select your uitar or instrument.

8. Volume Control: Treble Adjust the volume of your microphone, instrument or audio source.

9. Control: Adjust the high-frequency balance of your microphone or instrument.

10. Bass Control: Adjust the low-frequency balance of your microphone or instrument.

11. Master Control: Adjust the overall output level of the speaker system.

12.AC Input: 100-240V AC power input.

13. Power/Signal/Clip Indicator: Displays the input signal status in color.

Green: Power on

Yellow: Signal present

Red: Signal clipping

Note: Reduce the corresponding volume control to prevent signal clipping.

14. Power: Press to switch power ON/OFF. Though the battery will always charge while the

unit is connected to AC power, “Charge Only” enables you to charge your battery more

quickly.

System Setup

Connections and Controls
