Side 1/5

■Introduction

Thank you for purchasing this product. Before using the product, read through

the user manual to ensure that you will use the product correctly. Please keep

this manual for future reference.

■Features

• Modular microphone system comprised of an ES Series capsule, gooseneck

assembly, and power module.

• RGB LEDs built into both the desk stand power module and gooseneck

assembly indicate the on/off status of the microphone.

• The capacitive touch switch can be set to any of three operating modes:

“touch-on/touch-off”, “touch-to-talk” and “touch-to-mute”.

■Safety precautions

Although this product was designed to be used safely, failing to use it correctly

may result in an accident. To ensure safety, observe all warnings and cautions

while using the product.

■Cautions for the product

• Do not subject the product to strong impact to avoid malfunction.

• Do not disassemble, modify or attempt to repair the product.

• Do not handle the product with wet hands to avoid electric shock or injury.

• Do not store the product under direct sunlight, near heating devices or in a

hot, humid or dusty place.

■Notes on use

• Do not swing or pull the product. Doing so may cause disconnection or

damage.

• The circuitry in the microphone takes about 30 seconds to stabilize after power

is supplied. You may hear some audio disturbance during startup.

• The connectors are equipped with a special RFI-shielding mechanism. If you

remove or replace the connector, you may adversely affect the microphone’s RFI

immunity. The Audio-Technica Crimp Tool (ATCT) and shield parts are required to

shorten the cable and reinstall the connector while maintaining the RFI immunity.

• Install the microphone on a flat, unobstructed mounting surface. Make sure

that the sound source is not below the mounting surface.

• Depending on the surface finish of a table, the desk stand power module may

leave marks on the table.

• Do not excessively bend the gooseneck assembly, rotate the ends of the

capsule, or pull on them. Doing so may cause disconnection or malfunction.

• The product is a modular system comprised of a microphone element,

gooseneck assembly and power module. Make sure the parts are firmly

attached before use.

• Do not remove the rubber O-ring on the power module connecting part at the

lower section of the gooseneck assembly.

• When attaching parts, remove the black cap on the capsule connecting part

of the gooseneck assembly. Do not remove the silicone part at the end of

the capsule connecting part.

Silicone part

Do not remove

■Switch settings

To reduce low-frequency ambient noise (such as footsteps or air conditioning

noise), room reverberation, and mechanically coupled vibrations as much as

possible, turn on the low-cut filter switch ( ) on the bottom of the power

module.

ES925C6/DS3

ES925C12/DS3

ES925C15/DS3

ES925C18/DS3

ES925C21/DS3

ES925C24/DS3

User Manual

CARDIOID CONDENSER

MODULAR GOOSENECK MICROPHONE

WITH 3-PIN DESK STAND POWER MODULE

■Assembly

1. • Insert the gooseneck assembly (c) while rotating it into the desk stand

power module (d).

• Tighten until it does not rotate, and use the hex wrench (h) to tighten the

set screw (g) and set the gooseneck assembly in place.

• Connect the capsule (b) to the gooseneck assembly, and attach the

windscreen (a).

* If the parts are not sufficiently tightened together, problems may occur

such as the LED colors of the gooseneck assembly and power module

not matching or sound is not output.

2. Connect the included cable to the connector (e) on the reverse side of the

desk stand power module, and pass the cable through the wire slot (f).

■LED color

1 2 3

OFF RED GREEN

YELLOW

4 5 6 7

BLUE

MAGENTA

CYAN WHITE

■Wiring

1 2

PIN1

(Ground)

PIN2

(Hot)

PIN3

(Cold)
