AVerVision U70+ is a USB powered document camera. It comes with a USB 3.0 port which you can connect to computer.

Package Contents

Optional Accessories

(1)

(2)

(3) (4) (5)

(a)

(1) AVerVision U70+

(2) USB 3.0 cable

(3) Warranty card

(4) Software and Manual CD

(5) USB2.0 adapter (for MAC OS)

(a) Anti-glare sheet

U70+ Parts

(1)

(2)

(3)

(6)

(7)

(5)

(4)

(8)

Parts

(1) Rotate/Camera/LED buttons

 - Rotate the image.

 - Capture a still image.

 - Turn the overhead LED light on/off.

(2) Camera sensor and LED

(3) AF/Zoom in/Zoom out buttons

 - Automatically Adjust the Focus.

 / –Increase/decrease the image magnification.

(4) USB 3.0 port

(5) Camera storage compartment

(6) Flex arm

(7) Built-in Mic

(8) Handle

Connecting the AVerVision U70+ to a Computer /Laptop

[Note] When connecting to a MAC computer, use the USB2.0 adapter to connect to the MAC if you found anomalies in the video

stream.

Folding and Storing

The flex arm design allows you to freely bend the arm and store the camera head in the camera storage compartment. Once you have

properly secured the camera head to the camera storage compartment, you may now carry the AVerVision U70+ from the built-in

handle.

Adjust the camera head gently and DO NOT forcibly twist the camera head back and forth or around. It may break the

camera head off from the flex arm.

General Specification


Sensor

1/3.06”CMOS Sensor

Pixel Count

13M Pixels (4160*3120)

Frame Rate

60 FPS (Max.)

(also depends on computer CPU speed)

TV Lines

1400 (Max)

Output

resolution

4160*3120

3840*2160

1920*1080

1280*1024

1280*720

1024*768

Power

Consumption

4.0 Watt with LED lamp ON at USB3.0

3.3 Watt with LED lamp OFF at USB3.0

2.5 Watt with LED lamp ON at USB2.0

1.8 Watt with LED lamp OFF at USB2.0

Lighting

Lamp Type

LED light

Input/Output

USB

USB3.0 x 1

MIC

Built-in

Optics

Focusing

Auto / Manual

Shooting Area

Max (Large than A3 420*297)

4:3 = 530x396 mm (+/- 10mm) @410mm

high/ 20.8x15.5 inch

16:9=545x305 mm (+/- 10mm) @440mm

high/ 21.4x12.0 inch

5:4=498x397 mm (+/- 10mm) @410mm

high/19.6x15.6 inch

Min

4:3 = 130x96 mm (+/- 10mm) @100mm

high/ 5.1x3.7 inch

16:9=123x69 mm (+/- 10mm) @100mm

high/ 4.8x2.7 inch

5:4=120x96 mm (+/- 10mm) @100mm

high/ 4.7x3.7 inch

Zooming

16X Digital Zoom

Dimension

Operating

233.0 x 312.0 x 468.0mm

9.1 x 12.2 x 18.4 inch

Folded

242.0 x 187.5 x 44.0mm

9.5 x 7.3 x 1.7 inch

Weight

1.7kg(+/-0.1kg) (3.74lbs)

Produkt Specifikationer

Mærke:	AVer
Kategori:	Overheadprojektor
Model:	Vision U70+
Bredde:	233 mm
Dybde:	468 mm
Højde:	312 mm
Vægt:	1700 g
Brugervejledning:	Ja
Produktfarve:	Sort
Strømforsyningstype:	USB
Kabler inkluderet:	USB
Understøttede grafikopløsninger:	4164 x 3112
Videooptagelse:	Ja
Indbygget mikrofon:	Ja
Kompatible operativsystemer:	- Windows 7, 10\n- macOS X 10.14, 10.15\n- Chrome OS 79
Fotoeffekter:	Sort & hvid
Sensortype:	CMOS
Maksimal videoopløsning:	1920 x 1080 pixel
Digital zoom:	16 x
Grænseflade:	USB 3.2 Gen 1 (3.1 Gen 1)
Autofokus:	Ja
Maksimum billedhastighed:	60 fps
Driftsspænding:	5 V
USB-stik type:	Mini-USB
Garantibevis:	Ja
Optisk sensorstørrelse:	1/3.06 "
Zoom kapacitet:	Ja
Lyskilde:	LED
Dimensioner foldet sammen (BxDxH):	242 x 44 x 187.5 mm
Lodret rotationsvinkel:	0 - 270 °
Horisontal rotationsvinkel:	0 - 270 °
Kontinuerlig optagelsestilstand:	Ja
Effektiv sensor opløsning:	13 MP
Driftsstrøm:	0.9 A
Frysning af billede:	Ja
Billedområde (BxD):	420 x 297 mm
Dokument størrelse (maks):	A3
Kommentar:	Ja
